Title: Prospective Review Ready, Set, GO


1
Prospective Review Ready, Set, GO!
  • June 2006

2
5Ws and ROOT CAUSE
  • Apparent Five Root
  • Cause WHYs Cause

3
Proactive/Prospective QI
  • REACTIVE quality
  • Focus on bad apples after the fact
  • Downstream correcting system failures
  • Goal- be appropriate
  • Episodic effort
  • Meet minimum standards
  • PROACTIVE quality
  • Focus on improvements in future ahead
  • Upstream identify improvement potential
  • Goal - to be better
  • Continuous effort
  • Exceed expectations produce excellent results

4
Cause-Effect Diagram
  • Team members contribute and learn

5
Root Cause
Didnt complete project on time
Resources unavailable when needed
Took too long to hire Project Manager
Lack of specifics given to Human Resources Dept
Root Cause
No formal process for submitting job opening
6
An interesting comparison
  • Aviation
  • Needs more than stick rudder skills to ensure
    safe reliable flights
  • Crew Resource Management (CRM)
  • started in mid-70s for aviators that lacked
    the right stuff to manage aircrews effectively
  • NASA research linked accidents to failures of
    command, communication crew coordination
  • Medicine
  • Physicians, nurses, pharmacists technnologists
    educated and trained in separate silos
  • Mastering intricacies of team behaviour is
    different from mastering textbook knowledge
  • A predominant focus on knowledge acquisition does
    not prepare one for rapid paced clinical
    environments, distractions, hand-offs
    uncertainty

7
Further Drill Down
  • Aviation
  • Preoccupation with minor mechanical problems
  • Failure to set priorities
  • Failure to delegate tasks/responsibilities
  • Inadequate leadership
  • Inadequate monitoring
  • Failure to use available data
  • Failure to communicate
  • Ruffel Smith, 1979
  • Lauber, 1993
  • Operating Room
  • Failure to brief own team/other team of plans for
    operation
  • Failure to speak up inform team of workload or
    patient problems
  • Failure to establish clear leadership
  • Conflicts over course of action
  • Failure to debrief actions provide training to
    peri-operative staff
  • Helmreich Merritt, 1998

8
Prospective Review /Analysis
  • CCHSA Patient Safety goal to create a culture of
    safety
  • Beginning 2006, CCHSA expects one patient safety
    related prospective analysis process per year
  • Effective implementation of improvements
    changes is mandated

9
What will CCHSA expect?
  • Select a high risk process or activity
  • Proactively analyze the process or activity
  • Identify ways to improve the process make the
    activity safer
  • The intent is to prevent adverse events

10
What would be high risk?
  • Medication use
  • Operative procedures
  • Patient/Client identification
  • Blood administration
  • Care to high risk populations
  • Admission/Discharge/Transfer
  • Adverse events during service delivery

11
Prospective Analysis
  • Linked with risk management
  • Integrated risk management focus
  • Identification of new opportunities for
    improvement of risk practices
  • Prevention of risk
  • Minimizing losses (traditional RM focus)
  • The aim is for better understanding,
    communication, management of risk and improved
    decision making

12
Prospective Review
TOOLS TECHNIQUES
  • Failure Modes Effects Analysis
  • Errors of Omission (James Reason)
  • Simulation
  • Fault Tree Analysis
  • Hazard Analysis
  • Worst Case Analysis
  • Hazard Analysis Critical Control Points

13
What is FMEA?
  • FMEA is an acronym for Failure Modes and Effects
    Analysis
  • FMEA focuses on when and how a system will fail
    not IF it will fail
  • Methodology of FMEA
  • Identify the potential failure of a system and
    its effects
  • Assess the failures to determine actions that
    would eliminate the chance of occurrence
  • Document the potential failures

14
FMEA basic concepts
  • Root Failure Impact on
  • Cause Mode Client(s)

15
FMEA review
  • Steps in the process (map/flowchart)
  • Failure modes what could go wrong?
  • Failure causes why would failure happen?
  • Failure effects what would be the
  • consequences
    of each failure?

16
FMEA
  • Assign a Risk Priority Number (RPN) for each
    step, each failure mode the entire process
  • RPN is a number 1-10 to define the level of
    likelihood of occurrence, likelihood of detection
    and for severity
  • RPN is calculated by multiplying the numbers
    together. Failure modes with the highest RPN is
    the likely focus for improvement.

17
FMEA Flow Chart
Assign a label to each process or system component
List the function of each component
List potential failure modes
Describe effects of the failures
Determine failure severity
Determine probability of failure
Determine detection rate of failure
Assign RPN
Take action to reduce the highest risk
18
FMEA risk concepts
  • OCCURRENCE probability that failure will occur
  • SEVERITY of failure consequence for clients
  • DETECTION risk that cause of failure will pass
    through undetected

19
FAILURE MODE and EFFECT ANALYSIS
  • What it is
  • Failure mode and effect analysis is a tool that
    examines potential product or process failures,
    evaluates risk priorities, and helps determine
    remedial actions to avoid identified problems.
    The spreadsheet format allows easy review of the
    analysis.
  • When to use it
  • Failure mode and effect analysis is primarily a
    quality planning tool. It is useful in developing
    features and goals for both products and
    processes, in identifying critical
    product/process factors and designing
    countermeasures to potential problems, in
    establishing controls to prevent process errors,
    and in prioritizing process subunits to ensure
    reliability.

20
FAILURE MODE and EFFECT ANALYSIS -2
  • How to use it
  • Create a nine-column spreadsheet. Label the
    columns as indicated in the example below Mode
    of Failure, Cause of Failure, Effect of Failure,
    Frequency of Occurrence, Degree of Severity,
    Chance of Detection, Risk Priority, Action, and
    Validation.
  • Use brainstorming to identify all possible modes
    of failure. List each mode on a separate line in
    column 1.
  • Identify all possible causes of failure for each
    mode. Use brainstorming to create a list of these
    causes and add them in column 2.

21
FAILURE MODE and EFFECT ANALYSIS -3
  • Determine the likely effect of each failure. In
    column 3, identify the potential impact of
    failures on the customer, the product, or the
    process.
  • Create a table of assigned values. For columns 4,
    5, and 6, develop a consensus table of relative
    values for assumed frequency of occurrence, the
    severity of the failure for the customer, and the
    likelihood of detecting the problem.
  • Record appropriate values in columns 4, 5, and 6.
    Using the table of assigned values, develop a
    consensus score for frequency of occurrence, the
    severity of the failure, and the chance of
    detection for each cause of failure.

22
FAILURE MODE and EFFECT ANALYSIS -4
  • Calculate the risk factor for each cause of
    failure. For each cause of failure, multiply the
    numbers in columns 4, 5, and 6. Record the
    product in column 7.
  • Identify a remedy for critical failure modes.
    Concentrate on the small number of failure causes
    that can dramatically impact the product/process,
    and design actions that will significantly reduce
    the level of failure.
  • Validate each action/remedy. Design a method of
    verifying that the remedy is in place and is used.

23
Limitation of FMEA
  • Deals with one failure mode at a time
  • Adverse events are usually multiple failures and
    pre-existing hazards

24
Errors Omissions Assessment (James
Reason)
  • James Reason (NHS) developed a Errors and
    Omissions model
  • Think of it as simplified FMEA
  • Leaving out necessary steps/tasks is the most
    common human error type

25
Errors Omissions Assessment (James
Reason)
  • Tasks most likely to allow omissions are termed
    affordances. Reason outline 8 affordances
  • High information (reliance on short term memory)
  • Isolation
  • Recursive (repeated procedural steps)
  • Following (steps that follow main task)
  • Hidden ( item to be acted on is not obvious)
  • Interrupt (steps after unexpected interrupt)
  • Departure (from standard procedure)
  • Poor signals (weak, noisy or ambiguous)

26
(No Transcript)
27
Errors Omissions ASSESSMENT (J. Reason)
28
REMINDERS the five Cs
  • Once the task analysis if completed, the
    affordances are specified
  • REMINDERS
  • Conspicuous catch the providers attention at the
    critical time
  • Contiguous- positioned close in time space to
    the service location
  • Context- information about where when to
    remember
  • Content Provide information regarding what has
    to be done
  • Count Allow the provider to count off the
    number of discrete tasks that need to be done

29
Simulation
  • Used in clinical education of health
    professionals
  • Amplify real life experiences with guided
    experiences that evoke or replicate aspects in an
    interactive manner
  • Useful especially in error prone, high risk or
    unusual situations
  • Used to develop professionals skills without
    harming the patient
  • Developing team skills
  • Teach interaction skills using standardized
    approaches
  • Can be applied to testing of emergency
    preparedness plans, strike and job action plans,
    Pandemic flu plans

30
Benefits of Simulation
  • Safety
  • Improved efficiency in high cost clinical
    settings
  • Scheduling availability
  • Optimal conditions for learning
    learner-centered
  • Crawl -walk -run
  • Objective and immediate feedback
  • Integration of multiple skills
  • Useful as assessment tool

31
SIMULATION the KEYSTONE
  • By reducing errors during technically challenging
    procedures (surgery, interventions, etc)
  • Errors are reduced by improved
  • training with a focus on error identification
  • Simulation technologies have a proven record in
    improving safety through decreased uncertainty

32
Simulation
  • Simulatons are only a tool, and must be
    integrated into a comprehensive approach
  • Only through stringent validation of simulatons
    and their curricula will it be possible to have
    acceptance by the training and regulation bodies
  • It is not Build it and they will come
  • but validate it and they will come.

33
Fault Tree Analysis
  • What it is
  • Fault tree analysis is a graphical representation
    of the major faults or critical failures
    associated with a product, the causes for the
    faults, and potential countermeasures. The tool
    helps identify areas of concern for new product
    design or for improvement of existing products.
    It also helps identify corrective actions to
    correct or mitigate problems.
  • When to use it
  • Fault tree analysis is useful both in designing
    new products/services or in dealing with
    identified problems in existing
    products/services. In the quality planning
    process, the analysis can be used to optimize
    process features and goals and to design for
    critical factors and human error. As part of
    process improvement, it can be used to help
    identify root causes of trouble and to design
    remedies and countermeasures.

34
Fault trees are built using gates and events
(blocks).
  • OR gate
  • AND gate

35
Fault Tree Analysis - 2
  • How to use it
  • Select a component for analysis. Draw a box at
    the top of the diagram and list the component
    inside.
  • Identify critical failures or faults related to
    the component. Using Failure Mode and Effect
    Analysis is a good way to identify faults during
    quality planning. For quality improvement, faults
    may be identified through Brainstorming or as the
    output of Cause and Effect Analysis.
  • Identify causes for each fault. List all
    applicable causes for faults in ovals below the
    fault. Connect the ovals to the appropriate fault
    box.

36
Fault Tree Analysis - 3
  • Work toward a root cause. Continue identifying
    causes for each fault until you reach a root or
    controllable cause.
  • Identify countermeasures for each root cause. Use
    Brainstorming or a modified version of Force
    Field Analysis to develop actions to counteract
    the root cause of each critical failure. Create
    boxes for each countermeasure, draw the boxes
    below the appropriate root cause, and link the
    countermeasure and cause.

37
Hazard Analysis
  • Identify health safety hazards (OHS)
  • Evaluating hazards associated with specific jobs,
    tasks, machine tools
  • Prioritizing hazards in terms of risk posed
  • Describing methods to control hazards implement
    corrective actions
  • Explaining practical hazard controls
  • Documenting detailed, safe work job practices,
    incorporating hazard analysis into each

38
Worst Case Analysis
  • Used in design of circuits, devices equipment
    (BIOMEDICAL)
  • Worst case is simulated by taking all variables
    to -2 sigma or -3 sigma worst case values
  • Tend to be overly pessimistic
  • Useful as a fast check

39
Hazard Analysis Critical Control
Points
  • Developed as a food safety program
  • Principle 1 - Conduct a Hazard Analysis
  • Principle 2 - Determine Critical Control Points
  • (CCPs)
  • Principle 3 - Establish Critical Limits
  • Principle 4 - Establish Monitoring Procedures
  • Principle 5 - Establish Corrective Actions
  • Principle 6 - Establish Verification Procedures
  • Principle 7 - Establish Record Keeping and
  • Documentation
    Procedures

40
Hazard Analysis Critical Control
Points
  • HACCP Principle 1 - Conduct a Hazard Analysis
  • develop a list of hazards which are of such
    significance that they are reasonably likely to
    cause injury or illness if not effectively
    controlled. This process involves two stages 1)
    hazard identification and 2) hazard evaluation.
    During the first stage, a list is developed of
    the potential biological, chemical or physical
    hazards that may be introduced, increased, or
    controlled at each step in the production
    process.
  • HACCP Principle 2 - Determine Critical Control
    Points (CCPs)
  • CCP is a step which control can be applied and is
    essential to prevent or eliminate a food safety
    hazard or reduce it to an acceptable level.
    Examples of CCP's may include thermal processing,
    chilling, testing ingredients for chemical
    residues, product formulation control, and
    testing product for metal contamination.

41
Hazard Analysis Critical Control
Points-2
  • HACCP Principle 3 - Establish Critical Limits
  • A critical limit is a maximum and/or minimum
    value to which a biological, chemical or physical
    parameter must be controlled at a CCP to prevent,
    eliminate or reduce to an acceptable level of
    occurrence of a food safety hazard. A critical
    limit is used to distinguish between safe and
    unsafe operating conditions at a CCP. Critical
    limits should not be confused with operational
    limits which are established for reasons other
    than food safety. Critical limits must be
    scientifically based. The critical limits and
    criteria for food safety may be derived from
    sources such as regulatory standards and
    guidelines, literature surveys, experimental
    results, and experts.

42
Hazard Analysis Critical Control
Points-3
  • HACCP Principle 4 - Establish Monitoring
    Procedures
  • Monitoring is a planned sequence of observations
    or measurements to assess whether a CCP is under
    control and to produce an accurate record for
    future use in verification. Monitoring serves
    three main purposes.
  • First, monitoring is essential to food safety
    management in that it facilitates tracking of the
    operation. If monitoring indicates that there is
    a trend towards loss of control, then action can
    be taken to bring the process back into control
    before a deviation from a critical limit occurs.
  • Second, monitoring is used to determine when
    there is a loss of control and a deviation occurs
    at a CCP. When a deviation occurs, an appropriate
    corrective action must be taken.
  • Third, it provides written documentation for use
    in verification. Ideally, monitoring should be
    continuous, which is possible with many types of
    physical and chemical methods (ie, temperature or
    pH levels). Most monitoring procedures need to be
    rapid because they relate to on-line "real time"
    processes and there will be no time for lengthy
    analytical testing. Personnel who are responsible
    for the monitoring process are often associated
    with production.

43
Hazard Analysis Critical Control
Points-4
  • HACCP Principle 5 - Establish Corrective Actions
  • Where there is a deviation from established
    critical limits, corrective actions are
    necessary. An important purpose of corrective
    actions is to prevent foods which may be
    hazardous from reaching customers. Therefore,
    corrective actions should include the following
    elements 1) determine and correct the cause of
    non-compliance b) determine the disposition of
    non-compliant product and c) record the
    corrective actions that have been taken. Specific
    corrective actions should be developed in advance
    for each CCP and included in the HACCP plan. As a
    minimum, the HACCP plan should specify what is
    done when a deviation occurs, who is responsible
    for implementing the corrective actions, and that
    a record will be developed and maintained of the
    actions taken.

44
Hazard Analysis Critical Control
Points-5
  • HACCP Principle 6 - Establish Verification
    Procedures
  • Verification is defined as those activities,
    other than monitoring, that determine the
    validity of the HACCP plan and that the system is
    operating according to the plan. One aspect of
    verification is evaluating whether the facility's
    HACCP system is functioning according to the
    HACCP plan. Rather than relying on end product
    testing, firms should rely on frequent reviews of
    their HACCP plan, verification that the plan is
    being correctly followed, and review of CCP
    monitoring and corrective action records. Another
    important aspect of verification is the initial
    validation of the HACCP plan to determine that
    the plan is scientifically and technically sound,
    that all hazards have been identified and that if
    the HACCP plan is properly implemented these
    hazards will be effectively controlled.
  • Information needed for validation of the HACCP
    plan often include
  • 1) expert advise and scientific studies and
  • 2) in-plant observations, measurements, and
    evaluations.

45
Hazard Analysis Critical Control
Points-6
  • HACCP Principle 7 - Establish Record Keeping and
    Documentation Procedures
  • Generally, the records maintained for the HACCP
    systems should include the following
  • 1. A summary of the hazard analysis, including
    the rationale for determining hazards control
    measures.
  • 2. The HACCP Plan
  • Listing of the HACCP team and assigned
    responsibilities
  • Description of the food, its
    distribution, intended use and consumer
  • Verified flow diagram
  • HACCP Plan Summary Table that includes
    information for
  • Steps in the process that are CCP's
  • The hazards of concern
  • Critical limits
  • Monitoring
  • Corrective actions
  • Verification procedures and schedule
  • Record keeping procedures
  • 3. Support documentation such as validation
    records.
  • 4. Records that are generated during the
    operation of the plan.

46
CRITICAL CONTROL POINTS
  • ACKOFF a system of related elements forming a
    complex whole with a common aim
  • BATALDEN MOHR health care is a system made up
    of inter-related processes
  • JAMES each healthcare process consists of a
    small number of sub processes
  • CCPs are embedded in each process

47
Prospective Review
TOOLS TECHNIQUES
  • Failure Modes Effects Analysis
  • Errors of Omission (James Reason)
  • Simulation- Emergency Preparedness, Strike
    Contingency Plan, Pandemic Outbreak Plan
  • Fault Tree Analysis
  • Hazard Analysis OHS
  • Worst Case Analysis - Biomedical
  • Hazard Analysis Critical Control Points Food
    Services
  • Black- less complex
    Red- most complex

48
Proactive Approaches-- Prospective Review
  • Errors must be accepted as evidence of systems
    flaws, not character flaws

  • -Dr. Lucien Leape
Write a Comment
User Comments (0)
About PowerShow.com
