Component Testing: Part I

1
Component Testing Part I

• Ednaldo Dilorenzo de Souza Filho
• ednaldo.filho_at_cesar.org.br

2
Summary

• Introduction
• Fundaments of Testing
• Software Testability
• Test Case Projects
• Environment Testing, Architecture and Specialized
  Applications
• Software Test Strategies
• Component Testing

3
Introduction

• Testing is an important process to support
  assurance
• As software becomes more pervasive and is used
  more often to perform critical tasks, it will be
  required to be of higher quality
• Because testing requires the execution of the
  software, it is often called dynamic analysis
  Harrold
• Testing consists in compare the outputs from the
  executions with expected results to identify
  those test cases on which the software failed
• Testing cannot show the absence of faults, if can
  show only their presence.

4
Fundaments of Testing

• Testing goals
• Find faults in a software program
• A good test case have a high probability to find
  errors
• A good test process should find errors
• Testing fundamentals
• Testing should be connected with client
  requirements
• Testing should be planned before testing
  execution
• Isolation of suspected components
• Testing should start in individual components
• Complete testing is imposible
• Testing shouldnt be executed for developers

5
Software Testability

• Software Testability means how easy the software
  is for testing PRESS
• There are lots of characteristics of a testable
  software
• Operability
• Observables
• Controllability
• Decouplability
• Simplicity
• Stability
• Understandably

6
Software Testability

• How to design for software testability and how to
  measure the degree to which you have achieve it?
• Software testability is the process of
  investigate where software faults are and how to
  execute Voas
• Testability provide some guidance for testing
• Testability can give you confidence of
  correctness in fewer tests

7
Software Testability Design for Testability

• Testabilitys goal is to assess software
  accurately enough to demonstrate whether or not
  it has high quality
• There are two ways to reduce the number of
  required tests
• Select tests that have a great ability to reveal
  faults
• Design software that has a greater ability to
  fail when faults do exist (design for
  testability)
• There are several criteria on program design
• More of the code must be exercised for each
  input
• Programs must contain constructs that are likely
  to cause the state of the program to become
  incorrect if the constructs are themselves
  incorrect
• Programs must be able to propagate incorrect
  states into software failures

8
Software Testability Design for Testability

• Information Loss
• Implicit Information Loss
• Explicit Information Loss
• Design Heuristics
• Specification Decomposition
• Minimizations of variation reuse
• Analysis

9
Software Testability Sensitive Analysis

• Sensitive Analysis quantifies behavioral
  information about the likelihood that faults are
  hiding Voas
• Repeatedly executes the original program and
  mutations of its source code and data states
  using two assumptions
• Single-fault assumption
• Simple-fault assumption
• The specific purpose of sensitivity analysis is
  to provide information that suggests how small
  the programs smallest faults are likely to be
• The strength of sensitivity analysis is that your
  prediction is based on observed effects from
  actual faults
• The weakness is that the faults injected and
  observed are only a small set from what might be
  an infinite class of faults

10
Software Testability Sensitive Analysis

• Execution Analysis
• Infection Analysis
• Propagation Analysis
• Implementation

11
Test Case Projects

• Main goal of Test Projects is having a great
  probability of finding faults in software
• Hitachi Software, has attained such a high
  quality software that only 0.02 percent of all
  bugs in software program emerge at users site
  Yamaura

12
Test Case Projects

• Documenting Test Cases - Benefits
• Designing test cases gives you a chance to
  analyze the specification from a different angle
• You can repeat the same test cases
• Somebody else can execute the test cases for you
• You can easily validate the quality of the test
  cases
• You can estimate the quality of the target
  software early on
• Schedule, Cost, and Personnel
• An average project might apportion 12 months
  spend 2 months in testing by quality assurance
  team
• The test-case density
• A project with 100,000 LOC needs approximately
  10,000 test cases 1,000 per programmer

13
Test Case Projects

• Steps for Debugging and Testing
• Design a set of test cases
• Check the test cases
• Do code inspection based on the test cases
• Do machine debugging based on the test cases
• Collect quality-related data during debugging
• Analyze the data during debugging

14
Test Case Projects

• Main ways of testing a software
• White-box Testing
• Basic Way Testing
• Graph Flow Notation
• Cyclomatic Complexity
• Test Case Derivation
• Graph Matrix
• Control Structure Testing
• Condition Testing
• Data Flow Testing
• Cycle Testing
• Black-box Testing
• Graph Based Testing Method
• Partition Equivalence
• Comparison Testing
• Orthogonal Matrix Testing

15
Environment Testing, Architecture and Specialized
Applications

• GUI Testing
• Client/Server Architecture Testing
• Documentation and Help Devices Testing
• Real Time Systems Testing

16
Software Test Strategies

• Integration of test case projects methods in well
  planed steps, resulting in a good software
  construction
• It should be sufficiently flexible for holding
  test method and hard for holding planning and
  management
• A software strategy should execute low and high
  level tests

17
Software Test Strategies

• A Strategic Approach for Testing Software
• Verification and Validation
• Verification means the activities that assure the
  software implements a function correctly
• Software Test Organization
• Software developers should test execute only unit
  tests
• Independent test group (ITG) is responsible for
  execute destructive tests in the software
  integration
• Software developers should be available for
  correcting systems faults
• A Software Testing Strategy
• Unit Test
• Integration Test
• Validation Test
• System Test

18
Software Test Strategies

• A Strategic Approach for Testing Software
• Testing Completion Criterions
• When the test phase is finished?
• Based on Statistical Criterions PRESS

f(t) (1/p) lnl0 pt 1
19
Software Test Strategies

• Strategically Aspects
• Specify product requirements in a quantifiable
  way before test
• Show test goals in a clear way
• Understand users software and develop a profile
  for each user category
• Develop a test plan that emphasize a fast cycle
  test
• Build a robust software projected for testing
  itself
• Use effective technical formal revisions as a
  filter before testing
• Conduct technical formal revisions for evaluate a
  test strategy and test cases
• Develop an approach for improve the test process

20
Software Test Strategies

• Unit Test
• Used for testing software components separately
• It uses white-box test for exercising code lines
• Test cases should be planned with the expected
  results for comparison

21
Software Test Strategies

• Integration Test
• If separated components work, why should I make
  integration tests?
• Loosing data through an interface
• A module should have a not expected effect
• Top-Down Integration
• Bottom-up Integration
• Regression Test
• Smoke Test

22
Software Test Strategies

• Top-Down Integration
• First-In-Depth Integration
• First-In-Width Integration
• The main control module is used first for
  testing
• The next modules are being added
• Tests are being executed while components are
  added
• Regression tests can be executed for assure new
  errors are not added

23
Software Test Strategies

• Bottom-up Integration
• Atomic modules are added before in the system
• Components are being placed when low level
  components are tested

24
Software Test Strategies

• Regression Test
• All components added in the software may cause
  errors in components added before
• Regression test strategy test components tested
  before to assure new components didnt affected
  it
• Some tools can be used for execute regression
  test
• It should be separated in modules
• Analyzing Regression Test Selection Techniques
  Rothernel
• Regression Test Selection for Fault Detection
• Framework for Analyzing Regression Test Selection
  Techniques
• Inclusiveness
• Precision
• Efficiency
• Generality
• Tradeoffs

25
Software Test Strategies

• Analyzing Regression Test Selection Techniques
• An Analysis of Regression Test Selection
  Techniques

26
Software Test Strategies

• Analyzing Regression Test Selection Techniques
• An Analysis of Regression Test Selection
  Techniques

27
Software Test Strategies

• Analyzing Regression Test Selection Techniques
• An Analysis of Regression Test Selection
  Techniques

28
Software Test Strategies

• Smoke Test
• Used in software products developed fast
• Modules built by components are tested
• Modules are integrated and tested daily
• Integration risk
• Final product quality
• Errors diagnose are simplified
• Easy progress evaluation

29
Software Test Strategies

• Validation Tests
• Started just after integration tests
• Used for verify results based on requirements of
  the system
• An important element in validation test is called
  configuration revision
• Customer should validate requirements using
  system
• Alfa tests are tests executed in the user
  environment in the developer presence
• Beta tests are executed by the user without
  developers presence
• Validation, Verification, and Testing Diversity
  Rules Kitchenham
• Practical Problems with Operational Testing
• It assumes that the most frequently occurring
  operations will have the highest manifestation of
  faults
• Transition situations are often the most complete
  error-prone

30
Software Test Strategies

• Validation, Verification, and Testing Diversity
  Rules Kitchenham
• Testing Critical Function
• Critical functions have extremely severe
  consequences if they fail
• This leads to a problem with identifying the
  reliability of the system as a whole
• The product reliability can be defined in terms
  of failure in a given period of time
• For critical functions, you are likely to obtain
  a measure of reliability related of failure on
  demand
• The Need For Non-Execution-Based Testing
• You can only ignore nonoperational testing if
• All faults found by execution testing have
  exactly the same cost to debug and correct
• All faults can be detected, and
• The relative size of faults is constant across
  different operations for all time

31
Software Test Strategies

• Validation, Verification, and Testing Diversity
  Rules Kitchenham
• Diminishing Returns
• Operational test becomes less and less useful for
  fault detection when it have been removed faults
  from the most commonly used functions
• A systems engineer should mix some techniques,
  including
• Additional testing boundary and transition
  conditions and of critical functions
• Design inspections and reviews to identify
  specification and design faults early in
  development process
• Proofs for functions whose correct outcome cannot
  otherwise be verified, and
• Operational testing for those initial tests aimed
  at identifying the largest faults and assessing
  reliability.

32
Software Test Strategies

• System Test
• Should exercise the system as a whole for find
  errors
• Recovery Test
• Enforce the system to fail
• Verify the system recovery
• Security Test
• Verify if hackers can affect the system
• Testers should try to obtain secure data from the
  system
• Stress Test
• Execute system in a way it should require almost
  all resources
• Sensibility Test
• Try to find data that the system fail
• Performance Test
• For systems need to provide performance
  requirements
• Executed with Stress Test

33
Software Test Strategies

• Debugging
• Process started after the tester find an error
  and try to remove it
• Relation between a fault and its cause
• Two possible results
• The cause is found and corrected
• The cause is not found
• Why debugging is so difficult?
• Error and cause geographically remote
• Error can disappear when another error was
  corrected
• Error can be caused by non-error
• Error can be cause by an human mistake
• Error can be a time problem
• Error can be difficult to be found
• Error can be caused by distributed reasons
• Error can be found in a component

34
Component Testing

• Testing Component-Based Software A Cautionary
  Tale Weyuker
• The Ariane 5 Lesson
• In June 1996, during the maiden voyage of the
  Ariane 5 launch vehicle, the launcher veered off
  course and exploded less than one minute after
  take-off
• The explosion resulted from insufficiently tested
  software reused from Ariane 4 launcher
• Testing Newly Developed Software
• Unit Testing
• Integration Testing
• System Testing

35
Component Testing

• Testing Component-Based Software A Cautionary
  Tale Weyuker
• Problems with systems built from reusable
  components
• Performance problems
• Fitting selected components together
• Absence of low-level understanding
• Developing a component for a particular project
  with no expectation of reuse, testing proceed as
  usual
• Significant additional testing should be done for
  changing priority
• Modify or not the source code?
• Facilitating Reusable Component Testing
• Associate a person or a team for maintaining each
  component
• Add software specification
• Add test suite
• Add pointers between the specification and parts
  of the test suite

36
Component Testing

• Third-Party Testing and the Quality of Software
  Components Councill
• 10 contribuitors devoted 70 person-hour to
  developing a definition of component
• Ariane Project
• Certification business introduced a Maturity
  Model focused on large organizations
• 99 percent of all US businesses are small
  businesses
• Producers provide the developing and testing
  procedures, purchasers or their agents conduct
  second-party testing and independent testing
  organizations perform third-party testing

37
References

• PRESS Pressman, Roger S., Engenharia de
  Software, 5 Ed., Rio de Janeiro, MacGraw-Hill,
  2002.
• Councill William T. Councill, Third-Part
  Testing and the Quality of Software Components,
  IEEE Software, Quality Time, July 1999.
• Adams Tom Adams, Functionally Effective
  Functional Testing Primer, IEEE Software,
  bookshelf, September 1995.
• Rothermel G. Rothermel and M. J. Harrold,
  Analyzing Refression Test Selection Techniques,
  IEEE Transactions of Software Engineering, Vol.
  22, N 8, August 1996.
• Stocks P. Stocks and D. Carrington, A Framework
  for Specification-Based Testing, IEEE
  Transactions on Software Engineering, Vol. 22, N
  11, November 1996.
• Harrold M. J. Harrold, Testing a Roadmap,
  College of Computing, Georgia Institute
  Technology, 2000.

38
References

• Franki P. G. Franki and R. G. Hamlet,
  Evaluating Testing Methods by Delivered
  Reliability, IEEE Transactions on Software
  Engineering, Vol. 24, N 8, August 1998.
• Kitchenham B. Kitchenham and S. Linkman,
  Validation, Verification, and Testing Diversity
  Rules, IEEE Software, August 1998.
• Voas J. M. Voas and K. W. Miller, Software
  Testability The New Verification, IEEE Software,
  May 1995.
• Yamaura T. Yamaura, How to Design Practical
  Test Cases, IEEE Software, December 1998.
• Weyuker E. J. Weyuker, Testing Component-Based
  Software A Cautionary Tale, IEEE Software,
  October 1998.
