Component Integration
3
Component Integration

• While the highly advanced production technologies
  today heavily depend on computer systems,
  especially on their software, the production of
  software today is much like the production of
  hand-crafted goods in the nineteenth century.
• Software development is labor intensive it takes
  too long to build and costs too much.
• Once their development has been completed,
  todays software systems are typically inflexible
  and difficult to repair or to modify.

4

• The highly advanced production technologies today
  is the result of factoring out frequently used
  mechanisms as standard components and trying to
  design systems as compositions with such standard
  components.
• The detail design of each component is not
  referred to in the design of how to assemble
  components.

5

• This chapter gives a brief introduction to
  software components the necessity to reuse
  existing software components, architectures for
  defining and assembling them, frameworks for
  their visual representation and direct
  manipulation, and integration of legacy software
  systems.
• We will also focus on the maintainability of
  composed systems flexible composition structures
  may provide ease of composition, but may result
  in poor maintainability.

6

• Components expose only their interfaces, which is
  usually not sufficient to imagine how to reuse
  them.
• The ways of using each component are not
  independent from its contexts.
• In this chapter, we will also focus on the use of
  sample compositions as representations of
  component contexts.

7
Object Reusability

• Object-oriented programming has opened up two
  ways of reusing existing software.
• One is the reuse of defining codes, and
• the other is the reuse of running object
  instances as components.
• Software development based on either or both of
  these two types of reusing existing software is
  called component-based software development.

8

• The reuse of a code fragment requires knowledge
  both of its original context and of its reuse
  context.
• One mechanism that allows this type of reuse is
  property inheritance.
• This type of reusing codes requires programming
  expertise.
• This type of reuse improves the programming cost
  only by a constant factor it cannot
  significantly improve application development
  performance.

9

• Another mechanism that allows the reuse of codes
  is the definition of a new class as a composite
  class constructed with existing classes.
• For example, the class of technical reports may
  have the following component classes?title,
  author, abstract, chapter, and reference.
• Component classes are just called components.
• The definition of a composite class requires not
  only programming expertise, but also knowledge on
  its components their messages, message formats,
  parameter types, and return value types.

10

• Meme media should exploit the reuse of running
  object instances since they are reused not by
  programmers but by end users who have no
  programming expertise.
• They should be provided with a sufficiently large
  library of components, which should be open for
  future extension by many different component
  providers.

11
Components and Application Linkage

• Some messages invoke methods of components, while
  some others access properties of components. Some
  messages may work as events to components.
• Some component systems such as ActiveX Controls
  and JavaBeans distinguish these different uses of
  messages.
• However, these are all essentially nothing but
  messages.
• The use of such an exposed message of an
  application object by a program to invoke its
  method is called an application linkage between
  the program and the application object.

12
The reuse of components by a program code

• The programmer needs to know a priori the
  interface of each component he or she reuses.

13
Pluggability Placeholders
14
Pluggability component-integration environment

• Disp send message(j) to comp(i) with
  parameters
• Disp message dispatcher

15
The uniplug composition model
16
The uniplug composition model using slots
17

• Disp send message(j) to comp(i) with
  parameters
• You may consider each pair of a component and one
  of its exposed messages as an object. Such an
  object is called a slot. Now the
  above-mentioned component access statement is
  replaced with the following.
• Disp send (comp(i), message(j)) with
  parameters
• This may be further replaced with the following.
• Slot of (comp(i), message(j)) send parameters
• Now the message send is interpreted as a
  message accepted by any slot.
• We may further extend the slots to accept more
  than one standard message, where sendi is the
  i-th message accepted by any of the slots.

18
Standard messages to slots
19
Standard messages to slots

• Slot set value
• Slot gimme

20
Standard messages to slots

• A set message sends a parameter value to a
  slot, while a gimme message requests a return
  value from a slot.
• Our meme media components exploit this model.
• The parameter of a set message and the return
  value of a gimme message may have different
  value types even if they access the same slot.
• The pair of these two value types defines the
  slot type.

21
Systems for component reuse by program codes

• Systems for component reuse by program codes do
  not require component pluggability, and provide
  no standard framework such as component and
  message placeholders for the implicit
  specification of reused components and messages.
• ActiveX and Java including JavaBeans both fall in
  this category.
• JavaBeans however has several component
  integration environment systems such as Java
  Studio from Sun Microsystems, JBuilder from
  Borland, and VisualAge from IBM.
• Java Studio, for example, uses a wiring window to
  define linkages among components, and another
  separate window to define the layout of forms
  corresponding to some components.
• A form is a display object of a component, and
  works as an input/output cell.
• Most component integration environment systems
  separately treat the definition of functional
  linkages among components, and the layout
  definition of input/output forms.

22
Compound Documents and Object Embedding / Linking
View Integration
Object Linking
Object Embedding
23
Generic Components

• A component is more generic if it imposes less
  restriction on components it can be combined
  with.
• Components that do not explicitly specify which
  components to access are more generic than those
  that explicitly specify which components to
  access.
• Components that explicitly specify neither which
  components to access nor which messages to use
  for these accesses are further more generic.

24

• The exploitation of slots with standard
  slot-access messages allows each component to
  implicitly access some slots with explicitly
  specified standard slot-accessing messages.
• This also makes the components sufficiently
  generic.
• The parameter and the return value of such an
  implicit component-access statement may take
  different object types for different combinations
  of place fillers.
• Components that automatically perform necessary
  conversions for different types are more generic
  than those without this function.
• However, this function may introduce too much
  overhead to each component.

25

• Components may have some messages that can be
  accepted by any component.
• Some components may just neglect some of these
  messages after accepting them.
• These messages can be explicitly used in
  programming a component without making this
  component less generic.
• An example of such messages is an update
  message that is used to notify the fact that the
  sender component has just been updated.
• This update message takes no parameters.
• The copy message is another example. It
  replicates each component.
• In a system in which all components have display
  representation, the move message to change
  their location on the display, and the resize
  message to resize them are also examples of such
  messages.

26
(No Transcript)
27
Pluggability of Components

• The pluggability of a composite component in a
  composition depends on how many different plugs
  are used to connect this composite component to
  the remaining.
• The fewer plugs lead to the higher pluggability
  of the composite component.
• The simplest case uses no more than one plug to
  connect a composite component to the remaining.

28
What to reuse, components or sample compositions?

• Components expose only their interfaces, which is
  usually not sufficient for us to imagine how to
  reuse them.
• Many projects on reusable components have failed
  in the past for this specific reason.
• The ways of using each component are not
  independent of its context.
• Various contexts of a component provide
  information about varieties of its use.

29

• Contexts of a component can be presented as
  sample compositions using this component.
• When provided with sample compositions, component
  libraries provide much more information about
  components and the ways to reuse them.
• Furthermore, instead of providing a component
  library, we may provide a library of sample
  compositions.
• Each component in a sample composition may be
  associated with those components that may be
  substituted for the original component in this
  context.
• Here, what are reused are not components but
  sample compositions.

30
Reuses and Maintenance

• The rapid prototyping with components does not
  necessarily lead to the good maintainability of
  the developed applications.
• The maintainability of a composite application
  indicates how easy we can replace each of its
  primitive and composite components with a new
  version or with a different component that has
  similar functionality.

31
Reuses and Maintenance

• A component with more plugs to connect itself to
  the remaining is harder for us to replace with
  another than a component with fewer plugs.
• Compositions with cyclic connections are also
  harder for us to maintain than those without
  cyclic connections.

32

• The simplest case is the acyclic uniplug
  composition model.
• In the acyclic uniplug composition model, pulling
  out a plug always decomposes any composition to
  two independent composite components.
• The reuse of components should take into account
  the ease of future maintenance of whatever is
  composed.
• The acyclic uniplug composition model provides
  each composite application with good
  maintainability.

33

• While all the implicit component accesses are
  performed along the edges of this tree, some
  explicit component accesses with standard
  messages need not be performed along these edges.

• Explicit component accesses independent from
  these edges also make the maintenance of
  composite applications difficult.
• Their maintenance becomes much easier if we
  restrict explicit component accesses to those
  along these edges.
• The acyclic uniplug composition model that
  satisfies this further restriction is called the
  tree composition model.

34

• Because of the simple connection structures among
  components, the tree composition model is likely
  to complicate the data structures of parameters
  and return values that are exchanged between
  components in compositions.
• Components with multiple plugs can rather
  simplify these data structures, but lead to
  spaghetti-like connections and seriously reduce
  the maintainability.
• The complex data structures of connections in the
  tree composition model, when interpreted as the
  semantics of each connection, provide useful
  information for the maintenance of each
  connection.

35

• Some readers may think that the tree composition
  model cannot decompose programs with loops into
  components.
• Actually, it can decompose such programs in a
  restricted but desirable way.
• A single program loop, for example, consists of a
  loop skeleton and a sequence of procedures in
  this loop.
• The tree composition model decomposes such a
  program loop into a single base component that
  represents the loop skeleton and as many child
  components as those procedures.
• The base component has as many slots as the
  number of child components.
• Each child component is connected to the
  corresponding slot of the base component. The
  base component periodically invokes these child
  components in the specified order.
• The tree composition model does not break the
  loop structure of the original program, which is
  desirable from the view point of maintainability.

36
Integration of Legacy Software

• By adding an additional code, any program can be
  wrapped with a new exposed interface through
  which it is accessed, and through which it
  implicitly accesses other components.
• Such an additional code is called a wrapper.
• Components are not necessarily objects defined in
  some object-oriented system. .

37

• Whether the migration of a legacy system into a
  components environment will succeed or not
  depends heavily on whether this legacy program
  allows us to invoke a sufficiently large set of
  its functions from its outside.

38

• Visual components need to interact with user
  operations.
• When a user event is applied to a visual
  component, the event dispatcher detects this
  event and sends a corresponding appropriate
  standard message to this visual component.
• When applied to a wrapped legacy system, such an
  event is handled either by the wrapper or by the
  internal legacy system.
• If the legacy system has no GUI, its wrapper can
  handle all such events.
• Otherwise, some events should be dispatched to
  the GUI of the legacy system.
• The program of the legacy system must be able to
  accept such dispatched events as messages.

39

• Furthermore, the event interpretation by the GUI
  of the legacy system should be consistent to the
  standard event interpretation by visual
  components.
• Otherwise, some inherent direct operations of the
  legacy system may be interpreted as some of the
  standard operations of visual components.
• In such cases, we have to redefine the mapping
  between events and operations of the legacy
  system, which is usually a difficult task.

40

• Furthermore, the migration of a legacy system
  with GUI into a visual component environment
  requires special consideration on its drawing
  function.
• The drawing by a visual component may damage, or
  be damaged by, the drawing by another component,
  which requires each visual component to have the
  capability of redrawing and managing damaged
  areas.
• The required capability is usually more than what
  is required for the GUI of the original legacy
  system.
• This difference should be programmed when we wrap
  this legacy system, which is again usually not an
  easy task.
• An often-used solution to this problem makes the
  legacy draw its display output off the screen,
  and maps this image as a texture onto its visual
  component representation. This solution is
  sometimes called a shadow copy mechanism it
  was used in HP NewWave architecture 8. User
  events on the visual component need to be
  dispatched to the off-the-screen GUI of the
  legacy system.

41
Distributed Component Integration and Web
Technologies

• Systems using objects distributed over a network
  as their components need to use a standard
  protocol for exchange messages among component
  objects.
• They also need a lookup service to find out a
  desired component object from a component
  repository, and to get its reference as a proxy
  object as well as a method to access it through
  the proxy.
• Such a lookup service varies from a naming
  service to a content-addressable lookup service.
• A naming service accepts an object name and
  returns its reference, while a content-addressable
  lookup service accepts a quantification
  condition of desired objects and returns their
  proxies.

42
CORBA (Common Object Request Broker Architecture)

• proposed by OMG (Object Management Group)
• APIs called GIOP (General Inter-ORB Protocol) for
  the communication between CORBA objects using
  ORBs (Object Request Broker)
• IIOP (Internet Inter-ORB protocol) as an
  intermediate protocol to bridge GIOP and TCP
  (Transmission Control Protocol).
• An ORB is a program that enables each distributed
  object to exchange messages with other
  distributed objects.
• CORBA objects may use any language, while each of
  them needs to install a special interface to send
  and receive messages through an ORB.
• Each CORBA object uses two kinds of interface
  codes, i.e., a stub for sending messages going
  through an ORB, and a skeleton for receiving
  messages coming through an ORB.
• The coding of stubs and skeletons uses a special
  language called IDL (Interface Definition
  Language).

43
JavaBeans and EJB

• for Java program components called Beans.
• JavaBeans specifies API between components.
• In Web applications, when a sever-side Java
  servelet receives a client request, it invokes
  the Bean for the requested processing with input
  parameters.
• When the Bean completes its processing, the
  servelet sends back the result to the client.
• EJB (Enterprise JavaBeans) is a specification
  introducing distributed object technologies to
  JavaBeans.
• EJB allows us to invoke components stored in
  different machines through a network.
• Its components are called Enterprise Beans.
• They are classified into two categories. Session
  Beans manage client requests and control the
  processing, while Entity Beans perform database
  processing.

44

• Each EJB client application accesses an EJB
  server, and gets information about registered
  objects using JNDI (Java Naming and Directory
  Interface).
• JNDI provides API to access the naming service
  that manages distributed objects with their
  names.
• Using JNDI, you can invoke any object registered
  in an EJB server without knowing its location.
• Each client application, then, asks an EJB
  container to create a Home object, which is
  responsible for creating and deleting Enterprise
  Bean instances.
• When creating an Enterprise Bean instance, the
  Home object also creates an EJB object that
  mediates the method invocation of the Enterprise
  Bean instance.
• The EJB client application becomes able to invoke
  the methods of this Enterprise Bean through this
  EJB object. The processing result is sent back to
  the client through this EJB object.

45
DCOM (Distributed Component Object Model)

• DCOM (Distributed Component Object Model) is an
  extension of COM to cope with distributed
  objects.
• To use a COM component in a server machine, a
  client uses RPC (Remote Procedure Call) to ask
  the SCM (Service Control Manager) on the server
  machine for the instantiation of the COM
  component and the invocation of this object.
• In DCOM, the communication between a client and a
  COM object on different machines use a proxy at
  the client side and a stub at the server side. A
  proxy converts the COM object ID and parameters
  to the transportation format, while a stub
  reconverts the transportation format data for the
  COM object to understand.
• These two conversions are respectively called the
  marshalling and the unmarshalling.

46
Web services and their integration

• Web Service is a technology for application
  programs distributed over the Internet to
  mutually utilize their services.
• Web Service provides the three mechanisms,
  namely,
• the publication mechanism for each application to
  register itself as a Web service into a registry,

• the inquiry mechanism for a client or a Web
  service to find another registered Web service
  based on its providers name, service name,
  service category, or service interface
  information,
• the binding mechanism for the requesting client
  or Web service to invoke the retrieved Web
  service.

47

• UDDI (Universal Description, Discovery and
  Integration) allows applications to register
  themselves as Web services in a UDDI directory,
  and allows clients or Web services to search a
  UDDI directory for those Web services satisfying
  the requirements.
• UDDI is also a Web service.
• UDDI works as a service broker, while the
  requesting client (or application) and the
  registering application respectively works as a
  service requester and a service provider.
• The registration of a Web service uses WSDL (Web
  Service Description Language) to describe its
  detail information.
• WSDL is an XML-based language to describe, for
  each Web service, the methods and parameters it
  accepts, and its output format.

48

• Clients can invoke a Web service in a different
  machine through a SOAP proxy as if it invokes a
  local program, which is a program to invoke the
  Web service, and to obtain its processing result.

• SOAP (Simple Object Access Protocol) is an XML
  based standard common interface between
  components distributed over the Internet.
• In CORBA and DCOM, components in different
  specifications cannot communicate with each
  other. Therefore, these technologies are mainly
  used in local network environments.
• The interoperation of components distributed over
  the Internet requires a standard common API based
  on both a standard message format and a standard
  RPC protocol over the Internet, which leads to
  the proposal of SOAP.
• SOAP uses XML to represent access requests and
  return value data.
• Each request message in XML format is sent to a
  target component using POST method.
• SOAP allows both COM objects and CORBA objects to
  communicate with each other.

49
The Internet as a platform and universal document
interface

• Microsoft.NET is a new technology to make the
  Internet work as a single platform.
• Microsoft Windows use ActiveX technologies for
  embedding a Windows document in another Windows
  document of a different type.
• Windows applications including Words and Excel
  are ActiveX objects.
• Web documents and applications running on Web
  pages, however, use XML and SOAP technologies
  that are different from ActiveX technologies.
• Microsoft.NET tries to unify these two different
  worlds of applications and documents.

50
The Internet as shared memory spaces for objects

• Sun Microsystems proposed a new technology called
  Jini for various service-providing objects
  distributed over the Internet to dynamically
  organize a federation, or a dynamically defined
  flexible network, of objects.
• Some of these objects may not need to run on
  client computers nor on servers, but may run in
  electronic appliances or other devices connected
  to the Internet by wire or radio.
• The essential function of Jini is its Lookup
  service, which works as a broker between service
  provider objects and client objects.
• Neither of them need to know each other in
  advance.
• Jinis Lookup service organizes participating
  objects into service groups.
• More than one Lookup service can maintain the
  same service group.
• One Lookup service may work as a gateway to
  another Lookup service.

51

• Jini enables each object who wants to participate
  in some service group to discover this group.
• This Discovery process finds a Lookup service
  that manages some objects in this service group,
  and makes this Lookup service return its RMI
  stub, i.e., its proxy to the requester object for
  accessing this Lookup service.
• Through this proxy, the requester object can join
  the desired service group by registering its RMI
  interface instance as its proxy to the found
  Lookup service.
• This process is called a Join process.
• The Lookup service identifies each registered
  proxy with its interface type.
• A newly participating object sends a presence
  announcement packet to the network. This packet
  contains its IP address, its port number, and a
  name list of service groups it wants to
  participate in. This packet is multicast to
  Lookup services in the same domain.

52

• Each Lookup service monitors packets to identify
  each announce packet.
• When a Lookup service finds an announce packet,
  the service searches the name list in the packet
  for a service group that matches with one of its
  service groups.
• If it finds such a service group, the Lookup
  service returns its RMI stub as its reference to
  the sender object of this packet.
• When an object participating in some service
  group accesses its services, this object sends a
  request to the Lookup service, and gets an RMI
  stub, or a proxy, of a desired service object.
• Such a request specifies the interface type.
• This process is called a Lookup process. These
  three processes, a Discovery process, a Join
  process, and a Lookup process, provide a
  distributed mechanism for service provider
  objects and client objects to dynamically
  organize federations to collaborate for specific
  purposes.

53

• Sun Microsystems proposed another new technology
  called JavaSpace for objects on the network.
• A JavaSpace works as a shared memory defined over
  the network for read, write, and take out shared
  objects.
• Objects stored in a JavaSpace are
  content-addressable, i.e., you may read or take
  objects in a JavaSpace by specifying their
  template and some of their attribute values.
• A JavaSpace provides objects on the network with
  a blackboard system such as those used in AI.
• Some objects may define tasks and write them in a
  JavaSpace, while others may search the JavaSpace
  for unfinished tasks that they can process, take
  them to perform, and return the result in the
  JavaSpace.

54

• The idea of such a mechanism originates in Linda
  proposed by David Hillel Gelernder in 1982. His
  Mirror Worlds published in 1991 extends the
  basic idea, and proposed a tuple space, which
  became the basis of a JavaSpace.
• In a tuple space, each entry written in this
  space is a tuple, i.e., a list of attribute-value
  pairs. Objects can issue an SQL like query to a
  tuple space to find desired tuples, read or take
  out these tuples, and write new tuples in a tuple
  space.

55
Distributed object technologies and meme media
components

• Lookup services play the most important roles in
  distributed object environments, especially in
  open environments over the Internet.
• Such environments consist of service providers,
  service brokers, and service requesters.
• Service providers register their services to
  lookup services.
• Service brokers orchestrate more than one service
  to perform sophisticated services. They ask
  lookup services for desired services, and
  register their newly defined composite services
  to lookup services.
• Service requesters simply ask lookup services for
  desired services, and invoke them to perform
  their tasks.

56

• Distributed object technologies assume that all
  these players, i.e., service providers, service
  brokers, and service requesters, are software
  objects.
• Therefore, each lookup service should provide
  methods for software objects to specify what kind
  of services they want to access.
• Some lookup services allow software objects to
  specify services by their names, some others
  allow the specification by their interface.
• Others allow objects to specify services by their
  templates and attribute values.
• Lookup services return a reference to the found
  service, or a proxy of the found service.

57

• In meme media component environments, we assume
  that users manually combine media components
  together to define composite media objects.
• Meme media composition means not only layout
  composition, but also functional composition by
  defining linkage among components.
• Meme media component technologies, therefore,
  focus on an easy direct-manipulation way of
  arranging components on another component as well
  as functionally connecting them together.
• It is a user, not a program, who accesses look up
  services for primitive and/or composite
  components satisfying requirements.
• Different from look up services mainly for
  programs, look up services for humans require
  interactive access facilities for navigation,
  visual definition of queries, and direct
  manipulation for retrieving and registering
  visual components.

58
(No Transcript)
