Random walks and analysis of algorithms in cryptography

1
Random walks and analysis of algorithms in
cryptography

• Ilya Mironov
• Stanford University

2
Talk overview

• Cryptanalysis
• RC4 stream cipher
• card shuffling
• brute force attack
• Broadcast encryption
• analysis
• optimization
• Other work

3
Talk overview

• Cryptanalysis
• RC4 stream cipher
• card shuffling
• brute force attack
• Broadcast encryption
• analysis
• optimization
• Other work

4
RC4 stream cipher

• RC stands for Rons Code, designed in 1987 by
  Ron Rivest.
• Several design goals
• speed
• support of 8-bit architecture
• simplicity (to circumvent export regulations)

5
Abridged history of alleged RC4

• 1994 leaked to cypherpunks mailing list
• 1995 - first weakness (USENET post)
• 1996 appeared in Applied Cryptography by
  B. Schneier as alleged RC4
• 1997 first published analysis
• MS theses 3
• PhD thesis 1

6
Usage

• SSL/TLS
• Windows, Lotus Notes, Oracle, etc.
• Cellular Digital Packet Data
• OpenBSD pseudo-random number generator

7
Encryption
key
000111101010110101
state
?
plain text plain text

cipher text cipher t
8
Decryption
key
000111101010110101
state
?
cipher text cipher t

plain text plain text
9
Security Requirement

• Indistinguishability from a perfect source of
  randomness
• given part of the output stream, it is
• impossible to distinguish it from a
• random string

10
Second byte MS01

• Second byte of RC4 output is 0 with twice the
  expected probability

11
Related key attack FMS01

• Wireless Equivalent Privacy protocol (part of
  802.11b standard)
• Using keys with known prefixes - BAD

IV1, key ? IV1, 0010101010 IV2, key ? IV2,
1010110001 IV3, key ? IV3, 0101010111 IV4, key ?
IV4, 1010101010
key
12
Recommendation

• Discard the first 256 bytes of RC4 output RSA,
  MS
• Is this enough?

13
RC4 internal state

• Permutation S on 256 bytes
• Two indices i, j
• log2 (256! ? 256) ? 1700 bits

21 123 134 24 91 218 13 250 138 53
14
Key scheduling algorithm

• (all arithmetic is mod 256)
• for i 0 to 255
• Si i
• j 0
• for i 0 to 255
• j j Si keyi
• swap (Si, Sj)

15
Pseudo-random number generator

• i 0
• j 0
• repeat
• i i 1
• j j Si
• swap (Si, Sj)
• output (S Si Sj )

16
Both RC4s routines

• for i 0 to 255
• Si i
• j 0
• for i 0 to 255
• j j Si keyi
• swap (Si, Sj)
• i, j 0
• repeat
• i i 1
• j j Si
• swap (Si, Sj)
• output (S Si Sj )

key scheduling
pseudo-random number generator
17
Both RC4s routines

• for i 0 to 255
• Si i
• j 0
• for i 0 to 255
• j j Si keyi
• swap (Si, Sj)
• i 0
• repeat
• i i 1
• j j Si
• swap (Si, Sj)

key scheduling
j random (256)
, j
pseudo-random number generator
j random (256)
18
Both RC4s routines

• for i 0 to 255
• Si i
• j random (256)
• swap (Si, Sj)

key scheduling
for i 0 to 255
i 0 repeat i i 1 j random
(256) swap (Si, Sj)
pseudo-random number generator
19
Idealization of RC4
for i 0 to 255 Si i i 0 repeat
i i 1 j random (256) swap (Si,
Sj)
20
Idealization of RC4
for i 0 to n - 1 Si i i 0 repeat
i i 1 j random (n) swap (Si,
Sj)
21
Talk overview

• Cryptanalysis
• RC4 stream cipher
• card shuffling
• brute force attack
• Broadcast encryption
• analysis
• optimization
• Other work

22
Exchange shuffle

• RC4 card shuffling

i
i
i
i
i


random j
When i n - 1 the permutation is random
not
23
Perfect shuffling

• The textbook algorithm to shuffle cards

swap( Si, Sj)
i
i
i
i
i


random j
When i n - 1 the permutation is perfectly
random
24
Why is it not random?

• n! does not divide nn
• Sign of the permutation
• the sign changes each time with
• probability 1-1/n
• Positions of individual cards are predictable

25
First byte of RC4 output

• The first byte, SS1SS1, is biased

26
Distinguisher

• Less than 2,000 to recognize a non-random output
  with 10 error

27
Mixing time

• The permutation becomes more and more random.

nonrandomness
time
28
Variation distance

• Variation distance between two distributions, P
  and Q on S
• d(P,Q)½ ?s?S P(s)-Q(s)

variation distance
time
29
The end of the beginning of RC4

• What is the sufficient number of swaps for the
  permutation to become random?

Find t such that d(Pt, U) lt ?
30
Card shuffling

• To shuffle 52 cards
• - 7 riffle shuffles
• 100 random transpositions
• 30,000 adjacent transpositions
• - exchange (RC4) shuffles?

31
Lower bound

• Sign of the permutation
• after t rounds sign can be predicted with
  probability e-2t

32
Upper bound

• Checking argument
• initially all cards are unchecked
• check Si if
• - either ij
• - or Sj is checked
• keep doing until all cards are checked

33
Checking argument
i

j
34
Checking argument
i

j
j
Si is indistinguishable from other checked cards
35
Checking argument

• It takes ?(n log n) steps to check all cards.
• It gives an upper bound.

36
Mixing time

• at least
• ? (n)
• at most
• O (n log n)

37
What if n 256?

• Optimistically (go with the lower bound)
• mixes in 4?256 steps
• Conservatively (use the upper bound)
• mixes in 16?256 steps

38
New development

• E. Mossel, A. Sinclair, Y. Peres (Berkeley)
• the upper bound is tight
• mixing time T(n log n)
• Distinguisher
• look at the cards from the left half

39
Talk overview

• Cryptanalysis
• RC4 stream cipher
• card shuffling
• brute force attack
• Broadcast encryption
• optimization
• analysis
• Other work

40
Backtracking

• j S1
• t S1 Sj
• output St
• j j S2
• t S2 Sj
• output St
• j j S3
• t S3 Sj
• output St

41
Backtracking
S1

• j S1
• t S1 Sj
• output St
• j j S2
• t S2 Sj
• output St
• j j S3
• t S3 Sj
• output St

42
Backtracking
S1

• j S1
• t S1 Sj
• output St
• j j S2
• t S2 Sj
• output St
• j j S3
• t S3 Sj
• output St

Sj
43
Backtracking
S1

• j S1
• t S1 Sj
• output St
• j j S2
• t S2 Sj
• output St
• j j S3
• t S3 Sj
• output St

Sj
S2
44
Backtracking
S1

• j S1
• t S1 Sj
• output St
• j j S2
• t S2 Sj
• output St
• j j S3
• t S3 Sj
• output St

Sj
S2
Sj
45
Backtracking
S1

• j S1
• t S1 Sj
• output St
• j j S2
• t S2 Sj
• output St
• j j S3
• t S3 Sj
• output St

Sj
S2
Sj
S3
46
Backtracking
S1

• j S1
• t S1 Sj
• output St
• j j S2
• t S2 Sj
• output St
• j j S3
• t S3 Sj
• output St

Sj
S2
Sj
S3
Sj
47
Backtracking
S1

• j S1
• t S1 Sj
• output St
• j j S2
• t S2 Sj
• output St
• j j S3
• t S3 Sj
• output St

Sj
S2
Sj
S3
48
Backtracking
S1

• j S1
• t S1 Sj
• output St
• j j S2
• t S2 Sj
• output St
• j j S3
• t S3 Sj
• output St

Sj
S2
Sj
S3
Sj
49
Backtracking
S1

• j S1
• t S1 Sj
• output St
• j j S2
• t S2 Sj
• output St
• j j S3
• t S3 Sj
• output St

Sj
S2
Sj
S3
50
Backtracking
S1

• j S1
• t S1 Sj
• output St
• j j S2
• t S2 Sj
• output St
• j j S3
• t S3 Sj
• output St

Sj
S2
Sj
S3
Sj
51
Cost of backtracking

• Keep guessing until there is a critical mass
  100 entries
• Each guess is 8 bits, which multiplies the
  running time by 28
• Estimated running time 2800 (for comparison
  there are 2200 particles in the universe)

52
Improvement
S1

• j S1
• t S1 Sj
• output St
• j j S2
• t S2 Sj
• output St
• j j S3
• t S3 Sj
• output St

S2
S3
53
Running time of improved algorithm

• Much more intricate analysis of an unbalanced
  tree
• Estimated less than 2600

54
Why is it interesting?

• What about short RC4 64-byte permutation?
• internal state has size 300 bits
• 64-byte RC4 is secure against the old attack,
  borderline under the new attack

55
Talk overview

• Cryptanalysis
• RC4 stream cipher
• card shuffling
• brute force attack
• Broadcast encryption
• analysis
• optimization
• Other work

56
Broadcast encryption
source
k
k
k
k
k
k
k
k
k
k
receivers
? Very little overhead
? One rogue user compromises the whole system
57
Broadcast encryption
source
k1, k2, k3, k4, k5,, kn
k1
k2
k3
k4
k5
k6
k7
kn

receivers
broadcast Ek1,k, Ek2,k,, Ekn,k, Ek,M
58
Broadcast encryption
source
k1, k2, k3, k4, k5,, kn
k1
k2
k3
k4
k5
k6
k7
kn

receivers
? Simple user revocation
? Too many keys
59
Subset-cover framework (Naor-Naor-Lotspiech01)
S1
S7
S8
S6
S2
60
Subset-cover framework (Naor-Naor-Lotspiech01)
k3
k5
receiver u knows keys
k4
S1
S7
S8
S6
S2
61
Key distribution

• Based on some formal characteristic e.g., DVDs
  serial number
• Using some real-life descriptors
• Microsoft employees
• researchers
• California state residents
• PhDs

62
Broadcast using subset cover
S10
S1
S8
S6
S3
S5
header uses k1, k3, k5, k6, k8, k10
63
Subtree difference
All receivers are associated with the leaves of a
full binary tree
k0
k00
k01
k00
k01
k11
64
Subtree differences
special set Si,j
i
j
65
Subtree difference
66
Subtree difference
67
Subtree difference
68
Subtree difference
69
Subtree difference
70
Subtree difference
71
Subtree difference
72
Subtree difference
73
Greedy algorithm

• Easy greedy algorithm for constructing a subtree
  cover for any set of revoked users

74
Greedy algorithm

• Find a node such that both of its children have
  exactly one revoked descendant

75
Greedy algorithm

• Add (at most) two sets to the cover

76
Greedy algorithm

• Revoke the entire subtree

77
Greedy algorithm

• Could be less than two sets

78
Analysis of this algorithm

• R - number of revoked users
• C number of sets in the cover
• C 2R-1
• averaged over sets of fixed size NNL01
• EC 1.38R
• simulation experiments give NNL01
• EC 1.25R

79
Analysis of this algorithm

• R - number of revoked users
• C number of sets in the cover
• If a user is revoked with probability p1
• EC 1.24511 ER

80
Exact formula
where
81
Mellin transform
82
Asymptotic
EC/ER
1.24511
p
83
Asymptotic
EC/ER
1.2451134
3log2 4/3
1.2451114
p
84
Talk overview

• Cryptanalysis
• RC4 stream cipher
• card shuffling
• brute force attack
• Broadcast encryption
• analysis
• optimization
• Other work

85
Halevy-Shamir scheme

• Noticed that subtree differences are decomposable

86
Halevy-Shamir scheme

• Fewer special sets reduce memory requirement on
  receivers

87
Improvement

• For practical parameters save additionally 20
  compared to the Halevy-Shamir scheme
• This is joint work with N. Alon, D. Halevy, A.
  Shamir

88
Talk overview

• Cryptanalysis
• RC4 stream cipher
• card shuffling
• brute force attack
• Broadcast encryption
• analysis
• optimization
• Other work

89
Other work

• New classes of hash functions and analysis of a
  construction for hash functions Eurocrypt01
• Crypto and game theory in peer-to-peer
  filesharing networks EC01, FC02
• Construction of short signatures based on
  discrete logarithm CT-RSA03
