Realtime Damage Assessment Reporting and Mapping

1
Real-time Damage Assessment Reporting and Mapping

• Scott Fabbro

2
Glendale, at the foot of the breathtaking Verdugo
mountains, is the third largest city in Los
Angeles County and spans over 30 square miles. An
ethnically diverse city rich in heritage, natural
beauty and commercial accomplishment, Glendale is
home to nearly 200,000 people.
3
KIVA in the City of Glendale Overview
REQUEST for SERVICE
REMOTE INSPECTOR

• Permit Services
• Planning
• City Clerk

PERMITS

• Neighborhood Services
• City Manager

• Permit Services
• Inspections
• Fire Inspections

IVR
KIVANet
RFSWeb
Internet/ Public Access
Internet/ Public Access
PLUS (GIS Internet Mapping)
KIVA Imaging
LACO Assessor/ DS03 DataQuick

• Report Writers
• Cognos
• KIVAWord
• KIVAPerfect

GIS Mapping
4
LACO Assessor/ DS03 DataQuick

• GIS/LIS Constituency
• Public Works
• Planning
• P.S. Electric
• P.S. Water
• Fire
• Run Maps
• Swift Water Rescue
• EOC
• Fire Boundary
• ATC20 Damaged Structure
• RECON Maps (GPD and GFD)

• COMMON LAYERS
• Parcels/ Properties
• Streets
• Centerline (Thomas Bros)
• Blocks
• Building Footprints
• Orthophotos (Aerial photos)
• Topography (Contour lines)
• Digital Terrain Model (DTM)
• Hydrology
• Vegetation
• Survey Control Network
• Storm Drain System
• Sewer System
• Water System
• Electrical System
• Other Geographies
• Census Tracts
• Fire Districts

5
Disaster Strikes!
6
From Response to Recovery

• Building/ Structural Inspections
• Paper method, the ATC-20
• Easy to gather the data
• Difficult to collate/ summarize it
• Displaced Residents
• Time penalty

7
Our Response/ Recovery Efforts are stymied...

• City
• County
• Operational Area
• State OES
• FEMA

8
How can this be improved?

• Need to get the information from forward
  observers to decision-makers and citizens
  quickly!
• Better coordination among agencies.
• Share information and data more effectively.
• Grave to Cradle
• Can technology help?

9
YES! City Inspectors really use this
A mobile computer runninga Web browser
uses a wireless Internetconnection to access
live data in the computer system in their office
10
Originate ATC20 in Field
Workflow Begins
11
Inspections Can Be Routed to and from the Field
?
