myGrid Information Repository

1
myGrid Information Repository

• Arijit Mukherjee
• School of Computing Science
• University of Newcastle

2
Concept

• Based on the myGrid Information Model
• Stores user and provenance data
• Exposed as a service
• Uses ORM technology to map objects onto
  relational databases

3
myGrid Information Model

• Based on the CCLRC Scientific Metadata model
• Encompasses
• Design of eScience experiments
• People and organizations
• Biological and provenance results from
  experiments
• Computational operations involved
• An XML schema conforming to the model defines all
  the types.

4
Info Model eScience experiments
5
Info Model people and organization
6
Info Model Experiment Provenance
7
Info Model Operations
8
mIR Service Interface

• Document oriented based on the info model
  schema
• Rich semantics able to capture any level of
  complexity in the request
• Exposes store/update/get/delete interfaces
• Uses Hibernate to store/access objects to/from
  the underlying store, hides the database access
  complexity, database type, dialect and driver
  issues
• LSIDs are used as identifiers for each data item
  assigned by the myGrid LSID Authority
• mIR grabs base LSIDs for all namespaces during
  startup

9
mIR Generic Query Interface

• Able to send any SQL query to mIR
• Uses slightly modified OGSA-DAI WS-I Tech Preview
  package
• OGSA-DAI abstracts underlying database and driver
  issues
• Able to make 3rd party deliveries (for example to
  URL, files etc.)
• Creates a client side library based on
  Axis-1.2RC3 for other myGrid components
• Returns results in WebRowSet format
• Newer versions would remove Axis problems

10
Taverna Plugins

• MIR-Taverna-Plug-in
• Transparent to the user
• Catches events from workflow enactor
• Packs data elements into documents (conforming to
  info model schema)
• Sends requests to mIR for store/update/get
• MIR Browser
• Launched inside Taverna
• Explorer-like user interface for mIR
• Browses data elements via the mIR service
  interface

11
Myths and facts

• Myth Hibernate increases overhead
• Fact Imagine inserting 10,000 rows explicitly,
  each of which causing updates to several other
  tables, let alone all database dialect, driver
  issues
• Myth OGSA-DAI causes problems, Axis
  incompatibility
• Fact OGSA-DAI follows OMII (currently Axis
  1.2beta) it abstracts database/driver issues,
  allows 3rd party deliveries
• Myth MIR requires initialization, its
  difficult starting to use, user context is
  unnecessary
• Fact You always need some sort of context
  even at ATMs MIR-INIT is a temporary solution
  until some MIR-ADMIN is developed you need just
  a bit of copy-paste to start using it

12
Real Issues

• Info Model does not pose any restrictions on the
  request document, so any level of nesting is
  permitted which in turn leads to
• Performance Issues
• Richness of the information model leads to
  extreme complexity
• Complex request documents affects processing for
  a deep-structured document 50 of the processing
  time goes to database commit as number of
  references grow
• Usage of arrays instead of sets leads to
  processing complexity (code duplication and
  explicit index updates)
• 47 of the total time can be attributed to Axis
  serialization and deserialization for complex
  documents

13
Issues (contd.)

• Usage of 3rd party assigned LSID as ID and
  model complexity together restricts cascaded
  store/update
• MIRBrowser requires considerable changes
• Steps taken to boost performance
• Caching base LSIDs at start-up
• Configuring hibernate only once at start-up
• Start-up cost can be reduced further if the
  service is initialized during container start-up
• De-normalizing certain tables, 23 gain
• Saving data on a PER-WORKFLOW basis (can be set
  to PER-PROCESS within a config file), 54 gain in
  processing, but increases communication costs
• And it does not stop you or slow you down

14
Possible Future Work

• Need feedback from real biologists using it
• Role-based Access (GOLD is investigating)
• Data Security over the wire and uniform myGrid
  security framework
• Distributed Query Processing between various mIR
  instances OGSA-DQP can be used
• Database store/update notifications
• Store large files elsewhere (SRB/XML?), use ref
  in mIR
• Configurable canned-query interface
• Modifications to the information model
• Some simplifications
• Some restrictions
• Some new relationships

15
Thank You

• Questions/Discussions
