Building Blocks

1
Chapter 5

• Building Blocks

2
Greener Communities

• Mixed housing on light, narrow streets
• Abundant open space, with greenways
• Natural surface drainage instead of concrete
• Vegetative shading to reduce urban heat islands

• Granny flats
• Clustered housing
• Restored watersheds, more porous surface area to
  absorb rainwater
• Brownfield site redevelopment

3
Where Americans spend 90 of their time
BUILDINGS
4
Eng Lock Lees typical large building project
process ...

• Take previous successful set of drawings
• Change the box that indicates the name of the
  project
• Submit the drawings to client
• Building is constructed
• Client gripes about discomfort
• Wait for client to stop griping
• Repeat process

5
By skimping on design ...

• Building owner gets
• Costlier equipment
• Higher energy costs
• Less competitive comfortable building
• Tenants get
• Lower productivity
• Higher rent operating costs

6
Green Building Design

• Focus on human comfort and productivity
• Workers want thermal comfort
• Lighting to see what they are doing
• Can hear themselves think
• Working conditions can substantially affect
  employee productivity satisfaction

7
Some Characteristics of Green Buildings

• Site placement for solar gain and deflect of
  unwanted heat or wind
• Improved insulation airtightness
• Superwindows
• Passive heating/cooling systems
• Use of plants

• Daylighting
• Toxicity is designed out
• Local construction materials
• Water conservation reuse
• Energy efficiency
• Power generation

8
Superwindows

• Keep people warm in winter, cool in summer
• Have invisible coatings to allow light but
  reflect heat
• Contain heavy gas fillings to block flow of heat
  noise
• Newest ones maintain comfort between -47 degrees
  115 degrees without heating or cooling
  equipment
• Can be adjusted for various sides of a building

9
Keys to Successful Green Buildings

• Highly integrated design process with diverse
  skills perspectives
• Stakeholders collaborate in a charrette
  process-a short intensive teamwork effort
• Develop synergy between design elements
• To yield big energy resource savings at the
  lowest possible cost

10
U.S. Green Building Councils Leadership in
Energy Environmental Design (LEED)

• A rating system which provides a national
  standard for evaluating and comparing green
  building performance

11
EcoWal-Marts Experimental Eco-Store in Lawrence,
Kansas

• Unique daylighting system installed in one half
  of building, regular fluorescent for the rest
• Higher sales on daylit side
• Workers preferred the daylit side

12
Obstacles to green home construction

• Fragmented regulatory jurisdictions
• Obsolete building codes
• Uninformed building inspectors, home buyers,
  appraisers real estate agents

13
Refrigerators

• Use a sixth of U.S. households electricity
• Most ones in-service now
• Poorly insulated boxes
• Uses so much electricity, the coal burned to
  generate it would full up the inside annually
• Inefficient compressors mounted at the bottom (so
  heat rises up into food compartments)
• Undersized, dust-clogged, fan-cooled condenser
  with leaky air seals internal heaters to prevent
  sweating caused by thin insulation and
  inefficient lights, fans defroster coils that
  generates even more heat

14
EPAs Energy Star Labeled Appliances

• Can save the typical U.S. household about 30 of
  its energy bills
