CALICE TailCatcherMuon Tracker

1
CALICE Tail-Catcher/Muon Tracker

• Vishnu V. Zutshi
• for
• NIU/NICADD

2
Goals for the TC/Muon System

• Provide a reasonable snapshot of the tail-end of
  the shower for simulation validation
• Prototype detector with high-fidelity to what is
  imagined for a generic LCD
• correcting for leakage
• understanding the impact of coil
• muon reconstruction eflow
• fake rate

3
Erec/Egen 50 GeV p?
4
Tail-catching
5
Multiple Scattering
6
50 GeV p
7
HCal Table
8
HCal TCMT
9
lt90gt Containment
10
Different Hadronic Generators
Intra-nuclear cascade generators need to be
included
11
Rotations
12
(No Transcript)
13
(No Transcript)
14
Design Elements

• Fine section (8 layers)
• 2cm thick steel
• Coarse section (8 layers)
• 10cm thick steel
• 5mm thick, 5cm wide strips
• Tyvek/VM2000 wrapping
• Alternating x-y orientation
• Si-PM photo detection
• Common readout with HCal

15
Fermi-NICADD Extruder
16
Die
17
Separation Grooves
Provides better rigidity
3
1
2
4
5
Epoxy/paint mixture
18
Strips
19
X-talk
20
Glue?
21
Grooving
22
Response
23
Uniformity (small holes)
24
Longitudinal Scan
25
Cassette I
1mm thick steel walls
26
Cassette II
27
Cassette III
28
Absorber and Cart
for their support
Our thanks to

• Good quality steel plates from Fermi scrap
  available (0.75 and 4 inches thick).
• Maximum size for the thicker plates is 1.066m x
  1.2m.
• Cart being designed with about 10 tonne load
  capacity.
• Will have the capability for forward-backward and
  left-right motion.

29
Quality Control I

• Hole Tolerance
• Width and thickness measurements
• Dopant presence
• Attenuation length measurements
• Longitudinal and horizontal scans

30
Quality Control II
31
Quality Control III
32
Summary

• Strip-fiber RD essentially done, we are entering
  construction phase.
• All the scintillator required for the device has
  been produced.
• Assembly of the prototype cassette starts next
  week.
• Aim to have the first layer readout with the test
  beam electronics in Dec.
