Embedded Systems Programming

1
Embedded Systems Programming

• Writing Device Drivers

2
Writing a new device driver

• When writing a device driver you can either
• Create a new, bespoke driver from scratch
• Or
• Port an existing driver
• Generally pick option 2 unless
• The hardware is so new to make porting impossible
• You are really experienced in device driver
  writing
• The driver has to do something really special or
  diffferent

3
Linux Execution Environment
4
Linux Execution Paths

• Execution paths

5
Kernel Modules

• Kernel modules are inserted and unloaded
  dynamically
• Kernel code extensibility at run time
• insmod / lsmod/ rmmod commands. Look at
  /proc/modules
• Kernel and servers can detect and install them
  automatically, for example, cardmgr (pc card
  services manager)
• Modules execute in kernel space
• Access to kernel resources (memory, I/O ports)
  and global variables ( look at /proc/ksyms)
• Export their own visible variables,
  register_symtab ()
• Can implement new kernel services (new system
  calls, policies) or low level drivers (new
  devices, mechanisms)
• Use internal kernel basic interface and can
  interact with other modules (pcmcia memory_cs
  uses generic card services module)
• Need to implement init_module and cleanup_module
  entry points, and specific subsystem functions
  (open, read, write, close, ioctl )

6
include ltlinux/delay.hgt include
ltlinux/module.hgt include ltlinux/ioport.hgt includ
e ltasm/io.hgt include ltasm/arch/io.hgt include
ltasm/arch/hardware.hgt include ltasm/uaccess.hgt de
fine DRIVER_AUTHOR "craig duffy
craig.duffy_at_uwe.ac.uk"define DRIVER_DESC
"FPGA DIO driver" define LED_ADDRESS
0xf2400680 define RGGG 0xf000 static int
fpga_dio_init(void) static int fpga_j
static short unsigned pattern
printk(KERN_ALERT "fpga dio loaded\n")
patternRGGG pattern pattern gtgt 4 for (
fpga_j0 fpga_j ! 16 fpga_j)
printk("pattern x\n",pattern)
udelay(400) writew(pattern,LED_ADDRESS)
pattern pattern gtgt 8 pattern--
pattern pattern ltlt 8 / return
0 static void fpga_dio_exit(void)
printk(KERN_ALERT "fpga dio unloaded\n") modul
e_init(fpga_dio_init)module_exit(fpga_dio_exit)
MODULE_LICENSE("GPL")MODULE_AUTHOR(DRIVER_AUTH
OR)MODULE_DESCRIPTION(DRIVER_DESC)MODULE_SUPPO
RTED_DEVICE("fpga_dio")
7
Linking a module to the kernel (from Rubinis
book)
8
Module programming

• Be careful a kernel fault is fatal to the
  current process and sometimes the whole system
• Modules should support concurrency (support calls
  by different processes). Distinct data
  structures for each process (since the same code
  is executed) to ensure data is not corrupted.
• Driver code must be reentrant keep status in
  local (stack allocated) variables or dynamic
  memory allocation kmalloc / kfree
• This allows the process executing to suspend
  (e.g., wait for pcmcia card interrupt) and other
  processes to execute the same code.
• It is not a good idea to assume your code wont
  be interrupted.
• Sleep_on(wait_queue) or interruptible_sleep_on(wai
  t_queue) to yield the cpu to another process
• /proc/ioports contains information about
  registered ports. /proc/iomem contains info about
  I/O memory

9
Register Capability

• You can register a new device driver from the
  kernel
• int register_chrdev(unsigned int major, const
  char name, struct file_operations fops)
• A negative return value indicates an error, 0 or
  positive indicates success.
• major the major number being requested (a number
  lt 128 or 256).
• name the name of the device (which appears in
  /proc/devices).
• fops a pointer to a global jump table used to
  invoke driver functions.
• Then give to the programs a name by which they
  can request the driver through a device node in
  /dev
• To create a char device node with major 254 and
  minor 0, use
• mknod /dev/memory_common c 254 0
• Minor numbers should be in the range of 0 to 255.

10
Finding a device driver

• Obviously you need to be able to categorise the
  device
• Some Linux categories are not clear
• You can look at other open systems for example
  NetBSD
• This is useful as they may have ported the driver
  themselves
• Get as much reliable information about the device
• Data sheets, tested, stand alone code

11
Example of a Parallel port

• It is quite often useful to use a parallel port
  as an interface to some specialised hardware.
• There are a number of approaches you could take
  to controlling such hardware from Linux
• A simple, low level kernel device driver
• Porting the parallel port package, ppdev,
• Writing a full blown device driver through the
  file system
• Writing a driver through the /procfs interface

12
A simple low level kernel driver

• Under Linux it is always possible to write
  directly to the hardware
• This uses some low level calls to read and write
  data
• inb(), outb(), inw(), outw()
• The areas of memory are maped by the kernel and
  ioremap/iounmap shopuld be used
• Data has to be copied to and from user space unto
  kernel space

13
Problems with low level driver

• It is a good idea to use to test the hardware but
  isnt a long term solution for driver development
• Requires root access to run the kernel
• No file system interface
• Will be very limited functionality
• Cant use the kernel very effectively
• Isnt portable
• Can crash the kernel

14
Porting an existing device

• With the parallel port one can use ppdev
• This give a high level interface into the file
  system through /dev/parport0-n
• Dont need root access
• Can have well structured driver
• Should be ported (in-time) with new kernel
  releases
• Less likely to cause kernel panics

15
Problems with ppdev

• Unless it is a very standard parallel port
  application it is likely to be difficult to get
  the correct level of functionality
• Will require understanding a lot of details of
  parallel port and the driver which wont be
  useful for your app

16
Writing a device driver

• This allows you to create a new device in the
  system
• Uses VFS calls to access the drive
• Can open, read, write and close
• Uses ioctl calls
• Driver can be a module
• Only loaded when needed
• Easier development

17
Problems
