Quantifying Patterns of Biological Diversity using Vertebrate Habitat Models

1
Quantifying Patterns of Biological Diversity
using Vertebrate Habitat Models

• Frank A. La Sorte

2
Acknowledgements

• Southwest Regional Gap Analysis Project Bruce
  C. Thompson, Kenneth G. Boykin, Scott Schrader,
  Robert A. Deitner.
• New Mexico Cooperative Fish and Wildlife Research
  Unit, New Mexico State University.

3
Justification

• We require tools to quantify large scale patterns
  of biological diversity
• provide information for decision making on large
  scale environmental issues
• Adequately documenting these patterns is
  inherently difficult
• tremendous ecological complexity
• lack of time and resources

4
Justification (continued)

• Trade off
• document large scale patterns quickly with
  limited precision, accuracy, generality, and
  predictability
• Gap analysis presents regional patterns of
  vertebrate habitat associations within their
  estimated ranges
• However, it lacks well defined methods for
• quantifying diversity
• decision making

5
Objectives

• Concept of Ecological Diversity
• Dimensions and Components
• Quantifying Diversity Patterns within Gap
  Analysis
• Richness, Evenness, Distinctness
• Example 1996 New Mexico Gap Data
• New Mexico
• Tularosa Basin
• Applications for Decision Making

6
Limitations

• Models are subjective, non-probabilistic, and
  static
• Accuracy unknown
• Level of error propagation unknown
• Variables highly correlated
• Qualitative (presence/absence)
• Limited to vertebrates
• Varying perceptions of scale by species
• Habitat is scale dependent
• No intra- and interspecific factors
• Ignores size and spatial arrangement of patches

7
Ecological Diversity

• Units
• Grain
• Extent
• Diversity patterns
• Richness
• Evenness
• Taxonomic distinctness
• Landscape patterns
• Time

8
Diversity Patterns
9
Vertebrate Habitat Models

• Large scale biological and abiotic features, that
  can be represented cartographically, found within
  the estimated range of a species
• Combined with Boolean AND operators to create a
  binary grid (presence/absence)

10
Gap Richness

• Definition quantity of vertebrate habitats
  within a unit area
• Sum all vertebrate habitat models

11
Richness

• Does not predict presence, persistence, fitness,
  habitat quality, or biodiversity
• Interpretation of richness hotspots problematic
• Not consistent across taxa
• Scale dependent
• Biased towards marginal populations

12
Gap Evenness

• Definition How evenly vertebrate habitat is
  distributed within a taxonomic level in a unit
  area
• Species as the unit of evenness
• Summarize evenness trend with principle component
  analysis

13
Evenness Metrics

• Non-ordered or scalar metrics
• Ordered metrics
• Information theory (Rényi, Hill)
• Cumulative measures (Lorenz curve)

14
Lorenz Curve
Lorenz Curve (0, 0) (1/s, p1) (2/s, p1
p2)(s-1/s, p1 p2 ps-1) (1, 1) Where the
proportions are ranked p1lt p2ltlt ps for s
groups Gini Coefficient (Area between the
Lorenz Curve and the line of equality) x 2
15
Lorenz Curve
16
Gap Taxonomic Distinctness

• Definition How taxonomically distinct vertebrate
  habitat is within a unit area
• Measured as the average taxonomic path length for
  each cell based upon a weighting factor (Clarke
  Warwick 1998)

• Path length weights (?)

Average path length
17
Example New Mexico

• NM GAP 1996
• 100 x 100 m cells
• 346 vertebrate species
• 20 Orders
• 55 Families
• 195 Genera

18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
Example Tularosa Basin
Alamogordo
White Sands National Monument
Sacramento Mountains
9,369.2 km2
23
Richness
Taxonomic distinctness
Evenness
Order
Family
24
Correlation Matrix
25
Application to decision making

• Provides more detailed information on the
  patterns of diversity
• multivariate nature of diversity
• Use a combination of diversity components with
  other variables to
• more accurately represent gaps
• contrast sites based upon some criteria
• locate sites with desired characteristics

26
Decision Making

• Assist in directing policy, research, management,
  and conservation efforts more efficiently
• Should not be the sole source of information
• Should be interpreted cautiously and honestly
