Bonded Asphalt Concrete Friction Course

1
Bonded Asphalt Concrete Friction Course
2
Where are BFCs used?

• Over PCC or asphalt pavements
• 50 of projects over PCC, 50 over asphalt
• Preventive maintenance
• Ex Protecting joints, sealing the pavement
• Corrective maintenance
• Ex Frictional characteristics
• Surface for new pavements
• Ex Perpetual pavement, sacrificial surface, Curb
  Gutter areas for Cities Counties

3
A Little History. . .

• 1988 - First Trial in France
• 1992 - Introduced in U.S
• 1992 - Projects in TX AL
• 1993 - Projects in NJ PA
• 1993-97 - Projects in Northeast
• 1998 - Process adapted spread throughout U.S.

4
States with Bonded Friction Course Surfaces
Over 125,000,000 yd2 in U.S.
5
FDOT UF Evaluation of Thick Open Graded and
Bonded Friction Courses for Florida

• 2002 US 27, Highlands County
• 6.2 Mile Section to study Raveling, Rutting,
  Cracking Permeability.
• Modified binders improve tensile strength
• The presence of a bonded polymer-modified tack
  coat appears to improve both the cracking and
  rutting resistance of friction course mixtures.

6
Who has used it in Florida?

• Counties
• Alachua County
• Bay County
• Escambia County
• Hillsborough County
• Lake County
• Okaloosa County
• Orange County
• State DOTs
• Districts 1,2,5,7 have used BACFC
• District 2 I-10 project bid in July
• Turnpike project bids in July 08
• Districts 1,2,4 have projects in design

Kings Avenue, Hillsborough County 2003
7
Why Polymer Modified Emulsion?

• Controls migration into mix
• Superior bonding
• Allows 1-inch or less lifts without delamination
• Seals existing pavement
• Prevents water intrusion

8
What are the Application Rates?

• Emulsion membrane
• 0.13 - 0.3 gal/yd2
• Typically 0.20 gal/yd2
• BFC hot mix asphalt overlay
• FC-5 Mix

9
The Process
The emulsion membrane wicks up around the HMA
aggregates
The emulsion cures, bonding the mix pavement
10
The Process
Click to run video clip
11
Spray Bar distributing Emulsion Membrane
12
HMA Applied Directly Behind Spray Bar
13
Uniform Coating of Emulsion Membrane
14
Roller Directly Behind Spray Paver
15
Roller Operator Directly Behind Spray Paver
16
Paving System - Equipment
17
Midland Paver
18
RoadTec Paver
19
Vogele Paver
20
Spray Paver Features

• Ultrathin mat,
• 60-100 ft/min
• No traffic on emulsion
• Uniform application of emulsion

21
Pavement Preparation

• Clean pavement
• Seal existing cracks ¼ inch
• Dont overfill
• Fill surface deformities ½ inch deep
• Protect manhole covers, drains, etc.
• Standard Paving Procedures

22
BFC Features

• Fast paving, 4-6 lane miles/day
• Quick release to traffic
• thin lift with emulsion membrane cools quickly
• Bonds to existing
• pavement
• 4X binder vs tack
• Cost effective (life
• cycle cost)
• 2-3 additional years

US 281 San Antonio, TX after 12 years
23
Bonded Friction CourseSurface Over Reconstruction

• I-35, north of Albert Lea, MN
• Seals and protects construction joints

Cracks forming in unprotected construction joint
on adjacent highway without BFC
Centerline construction joint protected by BFC
seal
I-35 after 2½ years
24
Night Paving
San Antonio, Texas
25
I-20/59 Birmingham, AL160,000 ADT
After 3 years
Before surfacing
26
Other Benefits

• Protects pavement
• Seals out water
• Resists wear rutting
• Thin lift retains clearances, curbs
• Fast construction reduces user delays
• Night construction
• Lower life cycle costs

27
What Support does SemMaterials Offer?

• Technical Marketing Support
• Field Engineering On-Site
• Mix Design Support
• Pre-Con Meetings / Quality Workshops
• Workshops to Educate on the Process
• Facilitate/ Support Contractors wanting to enter
  the Spray Applied Business

28
Where?Site Selection Guidelines over Asphalt
Pavements

• Structurally sound pavement
• Rut depth
• Minor to moderate severity transverse
  longitudinal cracking
• Minor to moderate severity patches bleeding
• Raveling polished aggregate to high severity

29
Where?Site Selection Guidelines over PCC

• Structurally sound pavement
• Low severity D cracking
• Minor to moderate transverse longitudinal
  cracking
• Minor to moderate severity corner breaks
• Minor to moderate severity joint spalling
• Map cracking
• Faulting
• No blowups, water bleeding or pumping

I-40 North Carolina
30
Project SelectionPoor Candidates
High severity alligator cracking
High severity block cracking
High severity D cracking
Rutting
31
Other BFC Mixes

• Process open to other mix types
• PFC - Permeable/porous friction course (TX)
• Wet process crumb rubber open graded mixes (FL)
• FC-5 PG 76-22 (FL)
• Terminal blend crumb rubber open graded and gap
  graded mixes (CA)

32
Summary
33
Thank you.
Stephan Romanchak Account Manager sromanchak_at_semgr
ouplp.com Cell 727-748-5310
Jeff Butt Account Manager jbutt_at_semgrouplp.com Cel
l 813-777-4181
Robert Basgall Account Manager rbasgall_at_semgrouplp
.com
Ivann Harnish Field Engineer iharnish_at_semgrouplp.c
om
SR 26 Gainesville, FL
