Chapter 6: Process Synchronization

1
Chapter 6 Process Synchronization
2
What is the output?
2 separate runs of the same program
this is some output from dolphins are large
brained mammals the parent thread
this is some output from the parent thread
3
Issue Race Condition

• Definition
• When different computational results (e.g.,
  output, values of variables) occur depending on
  the particular timing and resulting order of
  execution of statements across separate threads
  or processes
• General solution strategy
• Need to ensure that only one process or thread is
  allowed to change a variable or I/O device until
  that process has completed its required sequence
  of operations
• In general, a thread needs to perform some
  sequence of operations on an I/O device or data
  structure to leave it in a consistent state,
  before the next thread can access the I/O device
  or data structure

4
Therac-25

• Between June 1985 and January 1987, some cancer
  patients being treated with radiation were
  injured killed due to faulty software
• Massive overdoses to 6 patients, killing 3
• Software had a race condition associated with
  command screen
• Software was improperly synchronized!!
• See also
• p. 340-341 Quinn (2006), Ethics for the
  Information Age
• Nancy G. Leveson, Clark S. Turner, "An
  Investigation of the Therac-25 Accidents,"
  Computer, vol. 26, no. 7, pp. 18-41, July 1993
• http//doi.ieeecomputersociety.org/10.1109/MC.1993
  .274940

5
Chapter 6 Process Synchronization

• Critical Section (CS) problem
• Partial solutions to CS problem
• Busy waiting
• Semaphores
• Atomicity
• Hardware methods for atomicity
• Multiple CPU systems
• Classic problems
• Bounded buffer, producer-consumer,
  readers-writers, dining philosophers
• Monitors

6
Critical Section Problem
do
entry section
critical section
exit section
remainder section
while (TRUE)
Figure 6.1 General structure of a typical
process Pi
7
Critical Section

• N processes (P1, P2, , PN) are accessing shared
  data (e.g., RAM, or shared files).
• Access typically involves reads and writes to
  data
• The program code where shared data is accessed in
  a process is the critical section of that process
• General Goal ensure that only one of P1, P2, ,
  PN are in their critical sections at any
  particular time
• Can loosen this requirement at times if processes
  are only reading the data
• Main requirements for entry/exit methods (see p.
  220 of text)
• 1) Provide mutual exclusion
• 2) Allow progress
• 3) Have bounded waiting

8
Main requirements for entry/exit methods (see p.
228 of text)

• mutual exclusion
• If process Pi is executing in its critical
  section, then no other process can be executing
  in its critical sections
• progress
• If no process is executing in its critical
  section and some processes wish to enter their
  critical sections, then only those processes that
  are not executing in their remainder sections can
  participate in deciding which will enter its
  critical section next, and this selection cannot
  be postponed indefinitely
• bounded waiting
• There exists a bound, or limit, on the number of
  times that other processes are allowed to enter
  their critical sections after a process has made
  a request to enter its critical section and
  before that request is granted

9
How do we solve the critical section problem?

• Look at two partial solutions, then a full
  solution
• Trying to solve this problem from scratch
• Not utilizing system calls in solutions here
• Just trying to use our usual programming concepts
  to solve this problem
• Assume assignment statements are completed
  atomically
• Consider main requirements
• 1) mutual exclusion 2) progress 3) bounded
  waiting
• Need to also look at other possible problems for
  any particular solution
• Well introduce more general, typical, techniques
  afterwards

10
Partial Solution 1 to Critical Section Problem
// global variable // initialized before threads
start int turn 0 // number of thread that can
enter CS next

• // thread 0
• do
• while (turn ! 0)
• // c. s.
• turn 1
• // remainder code
• while (true)

// thread 1 do while (turn ! 1) // c.
s. turn 0 // remainder code while (true)
Do we have mutual exclusion? Progress? Bounded
waiting?
11
Partial Solution 2 to Critical Section Problem
// initialization// flagi set if thread i
wants access to CSbool flag2 false, false

• // thread 0
• do
• flag0 true
• while (flag1)
• // c. s.
• flag0 false
• // other code
• while (true)

// thread 1 do flag1 true while
(flag0) // c. s. flag1 false //
other code while (true)
Do we have mutual exclusion? Progress? Bounded
waiting?
12
A Full Solution to Critical Section Problem (p.
230)
// initialization // flagi set if thread i
wants access to CS bool flag2 false,
false // number of thread that can enter CS
next int turn 1
// thread 1 do flag1 true turn
0 while (flag0 turn 0) // c.
s. flag1 false // other code while
(true)

• // thread 0
• do
• flag0 true
• turn 1
• while (flag1 turn 1)
• // c. s.
• flag0 false
• // other code
• while (true)

Do we have mutual exclusion? Progress? Bounded
waiting?
13
In Summary

• We have a solution to the critical section
  problem
• However, there are more general, typical solutions

14
Issues with this critical section solution

• Complex code
• Its hard to figure out if the code is correct
• Busy waiting
• Busy wait (aka. polling) In a loop, continuously
  checking the value of variables
• These processes are doing a busy wait until
  allowed into critical section
• Busy waiting is not the same as a process being
  blocked. Why?
• Threads actively take CPU cycles when waiting for
  other threads to exit from critical section

15
Another Busy Waiting Example
16
Busy Wait Loop
17
Complex Code Think About Critical Section (CS)
Problem More Abstractly

• We want two operations
• enter()
• perform operations needed so only current thread
  can access CS
• exit()
• Perform operations to enable other threads to
  access CS

do enter() // CS exit() // other code
while (true)
Further Issue What if we have multiple processes
trying to enter? Or what if we have multiple
critical sections?
18
Introduce a Parameter
do enter(s) // CS exit(s) // other code
while (true)

• enter(s)
• perform operations needed so only current thread
  can access CS
• exit(s)
• Perform operations to enable other threads to
  access CS

(traditionally parameter is called a semaphore)
19
Semaphores With Busy Waiting

• Traditionally
• enter() is called P (or wait)
• exit() is called V (or signal)
• Data type of the parameter is called semaphore
• semaphore (int value)
• Semaphore constructor
• Integer value
• number of processes that can enter critical
  section without waiting often initialized to 1.

• void V(semaphore S)
• Increment S-gtvalue

• void P(semaphore S)
• while (S-gtvalue lt 0)
• Decrement S-gtvalue

Often not a practical implementation Uses a busy
wait
20
Need Atomic Operations

• Need some level of indivisible or atomic
  sequences of operations
• E.g., when an operation runs, it completes
  without another process executing the same code,
  or the same critical section
• In P, we must test decrement value of semaphore
  in one step
• e.g., with semaphore value of 1, dont want two
  processes to test value of S, find that it is gt
  0, and both decrement and value of S
• Plus, increment operation must be atomic

21
Critical Section Solution with (Busy Wait)
Semaphores
semaphore mutex new semaphore(1) //
initialization

• // thread 1
• do
• P(mutex)
• // c. s.
• V(mutex)
• // other code
• while (true)

// thread 2 do P(mutex) // c.
s. V(mutex) // other code while (true)
Does not have bounded waiting there is a race
condition
Do we have mutual exclusion? Progress? Bounded
waiting?
22
Second Issue

• Busy waiting
• Threads actively take CPU cycles when using the
  wait operation to gain access to the critical
  section
• This type of semaphore is called a spin lock
  because the process spins (continually uses CPU)
  while waiting for the semaphore (the lock)
• How can we solve this? That is, how can we not
  use a busy wait to implement semaphores?

23
Semaphores Typical Implementation

• Add a queue of waiting processes to the data
  structure for each semaphore
• semaphore (int value)
• Semaphore constructor
• Integer value
• number of processes that can enter critical
  section without waiting often initialized to 1.
• Data structure includes a queue of waiting
  processes

• void P(semaphore S)
• Decrement S-gtvalue
• If S-gtvalue lt 0, then
• blocks calling process on S-gtqueue

• void V(semaphore S)
• Increment S-gtvalue
• If S-gtvalue lt 0, then
• Wake up a process blocked on S-gtqueue

Semaphore operations (P V) must be executed
atomically
24
Example

• Construct a queue (FIFO) data structure that can
  be used by two threads to access the queue data
  in a synchronized manner
• Code this in C with Semaphores as your
  synchronization mechanism
• i.e., assume you have a Semaphore class, with P
  and V operations
• Use STL queue as your data structure
• It has methods front(), back(), push(), pop(),
  size()

25
(No Transcript)
26
(No Transcript)
27
(No Transcript)
28
(No Transcript)
29
Running Program

• Use the terminal window (Unix) command called
  top to look at the amount of RAM memory usage
  over time
• The amount of RAM continuously increases over time

30
(No Transcript)
31
Result
What is the problem?
32
Resolving the Problem

• There is a race condition
• Because the consumer prints, this slows the
  consumer down
• The producer thus fills up the linked list more
  rapidly than the consumer takes items from the
  linked list
• A reasonable solution is to bound (limit) the
  number of items that can be in the list
• Exercise Try to solve this using semaphores

33
Can solve this with a counting semaphore

• Initialize a semaphore to the number of elements
  in the list
• keep track of the remaining slots to be filled in
  the list
• Call P on Add on this counting semaphore
• when the list has no remaining slots, Add will
  block
• Call V on Remove on this counting semaphore

34
(No Transcript)
35
Hardware Methods for Atomic Instruction Sequences

• Remember that semaphore P V must be executed
  atomically
• But how can we do this?
• Single CPU system
• Turn off interrupts for brief periods
• Not a general solution for critical sections
• But, can be used to implement short critical
  sections (e.g., P V implementation of
  semaphores)
• Why is this OK only for short critical sections?
• May not be suitable for a multiple CPU system
• May have to send message to all other CPUs to
  indicate interrupts are turned off, which may be
  time consuming
• Goal of only turning off interrupts for brief
  periods will likely be violated

36
Multiple CPU systems

• Typically use TestAndSet or Swap instructions
• Enable process to know that it (not another
  process) changed a variable from false to true
• Multiprocessors often implement these
  instructions
• Swap(A, B)
• Atomically swap values of variables A B
• TestAndSet(lock)
• Atomically returns current value of lock and
  changes it to true
• If two of these instructions start to execute
  simultaneously on different CPUs, they will
  execute sequentially in some order across CPUs,
  instruction is atomic
• Use of these instructions for critical sections
  requires a busy wait not a general solution for
  critical sections
• But, can be used to implement atomic P/V for
  semaphores

37
Mutual-Exclusion with Swap (Fig. 6.7)

• // lock initialization occurs once, across all
  processes
• boolean lock false // variable shared amongst
  processes CPUs
• boolean key // variable not shared access by
  this thread only
• // In the following, at most 1 process will have
  key false.
• // If the process has key false, then it can
  access the CS,
• // Otherwise it busy waits until key false.
• do
• key true
• while (key true)
• Swap(lock, key)
• // Critical Section goes here
• lock false // assuming atomic assignment
  across processors
• // Remainder section
• while (1)

The question being asked is Am I the process
that changed lock to true from false?
Can be used to provide mutual exclusion in the CS
of a semaphore
38
Mutual-Exclusion with TestAndSet (Fig. 6.5)

• // lock initialization occurs once, across all
  processes
• boolean lock false // shared amongst processes
• // Process that succeeds in changing lock from
  false to
• // true gains access to the CS.
• // The others busy wait until lock returns to
  false.
• do
• // TestAndSet returns current value of lock
  changes it to true
• while (TestAndSet(lock))
• // Critical section goes here
• lock false // assumed atomic
• // Remainder section
• while (1)

Can be used to provide mutual exclusion in the CS
of a semaphore
39
More Synchronization Examples

• Semaphores
• Bounded buffer
• Readers-writers
• Dining philosophers
• Semaphores using condition variables

40
Classic Problem Bounded Buffer

• One process consuming items from a buffer
• Other process producing items into a buffer
• Need to ensure proper behavior when buffer is
• Full Blocks producer
• Empty Blocks consumer (improvement over previous
  solution)
• Need to provide mutually exclusive access to
  buffer (e.g., queue)
• Can solve with semaphores
• Illustrates some different uses of semaphores
  mutual exclusion, and counting

41
Bounded Buffer Problem
// semaphores data buffer shared across
threads semaphore empty(BUFFER_LENGTH) // number
of empty slots semaphore full(0) // number of
full slots semaphore mutex(1) // mutual
exclusive access to buffer

• // producer thread
• do
• // produce item
• wait(empty)
• wait(mutex)
• // c. s.
• // add item to buffer
• signal(mutex)
• signal(full)
• while (true)

// consumer thread do wait(full) wait(mutex) /
/ c. s. // remove item from buffer signal(mutex)
signal(empty) // consume item while (true)
42
Classic Problem Readers-Writers

• Multiple reader processes accessing data (e.g., a
  file)
• Single writer can be writing file
• Sometimes not just one process in critical
  section!

43
Readers-Writers
// data and semaphores shared across
threads semaphore wrt(1) // 1 writer or gt1
readers semaphore mutex(1) // for test change
of readcount int readcount 0 // number of
readers

• // writer process
• wait(wrt)
• // code to perform
• // writing
• signal(wrt)

// reader process wait(mutex) readcount if
(readcount 1) // first one in? wait(wrt) sign
al(mutex) // code to perform reading wait(mutex)
readcount-- If (readcount 0) // last reader
out? signal(wrt) signal(mutex)
Reader priority solution
44
More Synchronization Abstractions

• Using semaphores can be tricky!
• E.g., the following code can produce a deadlock
• this is highly undesirable!

// initialization shared across
threadssemaphore s(1), q(1)
// thread 1 wait(s) wait(q) signal(s) signal(
q)
// thread 2 wait(q) wait(s) signal(q) signal(
s)
45
More Synchronization Abstraction Monitors

• Automatically ensures only one thread can be
  active within monitor
• One thread has lock on monitor Gain entry by
  calling methods
• Effectively, a synchronized class structure where
  only one thread can be accessing a method on a
  specific object instance at one time
• Condition variables
• Use one of these for each reason you have for
  waiting
• Enable explicit synchronization
• wait and signal operations (different than
  semaphore operations)

46
Monitors Condition Variables

• Wait
• Invoking thread is suspended until another thread
  calls signal on the same condition variable
• Gives up lock on monitor other threads can enter
• Signal (e.g., notify in Java)
• Resumes exactly one suspended process blocked on
  condition
• No effect if no process suspended
• Choice about which process gets to execute
• Resumed process regains lock on monitor when
  signaling method finishes
• Java
• Wait and notify is with respect to an object
• If you call wait or notify within a class you are
  saying this.wait or this.notify, and the wait or
  notify is with respect to this object
• Simplified idea of condition variables
• But, can use Condition interface (as we discussed
  before)

47
General Monitor Syntax

• monitor monitor-name
• // shared variable declarations
• method m1()
• .
• .
• method mN()
• .
• Initialization code ()

Mutual exclusion across methods within the
monitor for particular object instance only a
single thread can be executing a method on the
object
48
wait style

• Usually, do
• while (boolean expression)
• wait()
• Not,
• if (boolean expression)
• wait

49
Example

• Solve the bounded buffer problem using a Monitor
• With the wait and signal Monitor operations

50
(No Transcript)
51
(No Transcript)
52
Example (2)

• Now, use two conditions
• One condition for Adding
• Wait on this condition while the queue is full
• And one condition for Removing
• Wait on this condition while the queue is empty

53
(No Transcript)
54
(No Transcript)
55
(No Transcript)
56
Classic Problem - 3

• Dining-Philosophers
• 5 philosophers, eating rice, only 5 chopsticks
• Pick up one chopstick at a time
• What happens if each philosopher picks up a
  chopstick and tries to get a second?

57
Dining Philosophers Using Monitors

• Observation
• A philosopher only eats when both neighbors are
  not eating
• pickup(i)
• Start to eat only when both neighbors are not
  eating
• putdown(i)
• Enable neighbors to eat if they are hungry

• do
• dp.pickup(i)
• // eat
• dp.putdown(i)
• // think
• while (true)

58
(p. 249 of text)
59
(No Transcript)
60
Example

• Implement semaphores using Monitors
• There is some subtlety to the implementation

61
(No Transcript)
62
(No Transcript)
63
(No Transcript)
64

• Semaphores using Java a little tricky

65
(No Transcript)
66
(No Transcript)
67
(No Transcript)
68
User Space Synchronization Provided by OSs and
Libraries

• Linux (current kernel version)
• POSIX semaphores (shared memory non-shared
  memory)
• futex wait for value at memory address to change
• Windows XP thread synchronization
• provides dispatcher objects
• mutexes (semaphores with value 1), semaphores,
  events (like condition variables), and timers can
  be used with dispatcher objects
• Pthreads
• has conditions and mutexes
