VIROLOGY

1
VIROLOGY
Margaret.Hunt_at_uscmed.sc.edu 733-3293 Building 2,
B-4 (office), B16(lab)
2
OUTLINE

• introduction to viruses
• structure and classification
• basic virology
• clinical virology

3
VIROLOGY

• different structure
• different method of replication
• implications for
• diagnosis
• treatment
• prevention

4
CONTROL METHODS

• INVOLVE KNOWLEDGE OF
• RESERVOIRS
• MODE OF TRANSMISSION
• METHODS TO INACTIVATE VIRUS OF INTEREST
• VACCINES
• ANTI-VIRAL DRUGS
• DEVELOPMENT OF DRUG RESISTANCE

5
EMERGING VIRAL DISEASES

• Some North American examples
• HIV/AIDS
• Hantavirus pulmonary syndrome (HPS)
• West Nile encephalitis (WNV)
• Severe acute respiratory syndrome (SARS)
• Monkey pox
• Human metapneumovirus
• 2009 H1N1 pandemic influenza

6
Consequences of viral infections

• 50 of all absenteeism
• Children
• 7 or more viral infections per year that
  involve a visit to a physician

7
Consequences of viral infections

• Suffering, followed by recovery
• Persistent disease
• Fatal disease
• Congenital disease
• Contributory factor in cancer
• Contributory factor in other diseases

8
SOME ARE ASYMPTOMATIC!
9
VIRUSES CAN BE USEFUL

• VACCINE DEVELOPMENT
• GENE THERAPY
• TOOLS TO INVESTIGATE HOST CELLS

10
WHAT ARE VIRUSES?
A PIECE OF BAD NEWS WRAPPED UP IN A PROTEIN
11
WHAT ARE VIRUSES?

• NUCLEIC ACID GENOME
• DNA OR RNA
• PROTEIN COAT
• PROTECTION, ENTRY
• LIPID ENVELOPE IN SOME VIRUSES
• SMALL
• (20-400nm)
• OBLIGATE INTRACELLULAR PARASITES

12
Virus particle virion
White, DO and Fenner, FJ. Medical Virology, 4th
Ed. 1994
13
Koneman et al. Color Atlas and Textbook of
Microbiology 5th Ed. 1997
14
The arenavirus family appears to accidentally
package ribosomes, but these appear to play no
role in protein synthesis.
15
CONSEQUENCES

• HEAVILY PARASITIC ON HOST CELL
• NO BROAD RANGE ANTIBIOTICS
• NEED TO LOOK FOR WEAK LINK

16
HOST RANGE

• MAY BE WIDE OR NARROW
• MAY BE INSECT/ANIMAL, INSECT/PLANT
• DO NOT CROSS EUCARYOTE / PROCARYOTE BOUNDARY

17
FACTORS AFFECTING HOST RANGE - CELL SURFACE
RECEPTORS
CYTOPLASM
18
FACTORS AFFECTING HOST RANGE

• CELL SURFACE RECEPTORS

• AVAILABILITY OF REPLICATION MACHINERY
• ABILITY TO GET OUT OF CELL AND SPREAD
• HOST ANTI-VIRAL RESPONSE

19
VIRAL STRUCTURE SOME TERMINOLOGY

• virus particle virion
• protein which coats the genome capsid
• capsid usually symmetrical
• capsid genome nucleocapsid
• may have an envelope

20
ICOSAHEDRAL SYMMETRY

• 20 faces
• 12 vertices

http//www.tulane.edu/dmsander/WWW/Video/Video.ht
ml
21
ICOSAHEDRAL SYMMETRY
22
ICOSAHEDRAL SYMMETRY
NUCLEIC ACID IS INSIDE
23
ICOSAHEDRAL SYMMETRY
24
ICOSAHEDRAL SYMMETRY
PENTON (pentamer)
25
(No Transcript)
26
(No Transcript)
27
ICOSAHEDRAL SYMMETRY
PENTON
28
(No Transcript)
29
(No Transcript)
30
Adenovirus
31
(No Transcript)
32
(No Transcript)
33
Adenovirus
34
herpesvirus capsid (membrane removed)
http//www.bocklabs.wisc.edu/Herpesvirus.html
35
polypeptides
capsomers
36
ICOSAHEDRAL SYMMETRY
37
rhinovirus
Jean-Yves Sgro http//www.bocklabs.wisc.edu/multim
edia.html
38
SYMMETRY OF NUCLEOCAPSID

• ICOSAHEDRAL
• HELICAL

39
TOBACCO MOSAIC VIRUS
nucleic acid
protein
adapted from Klug and Caspar Adv. Virus Res.
7225
40
(No Transcript)
41
Helical symmetry

• Length controlled by nucleic acid
• Helix may be stiff or flexible

42
(No Transcript)
43
(No Transcript)
44
COMPLEX SYMMETRY
surface view
cross section
POXVIRUS FAMILY
White, DO and Fenner, FJ. Medical Virology, 4th
Ed. 1994
45
ENVELOPE

• OBTAINED BY BUDDING THROUGH A CELLULAR MEMBRANE
  (except poxviruses)
• POSSIBILITY OF EXITING CELL WITHOUT KILLING IT
• CONTAINS AT LEAST ONE VIRALLY CODED PROTEIN

46
CYTOPLASM
47
ENVELOPE

• OBTAINED BY BUDDING THROUGH A CELLULAR MEMBRANE
  (except poxviruses)
• POSSIBILITY OF EXITING CELL WITHOUT KILLING IT
• CONTAINS AT LEAST ONE VIRALLY CODED PROTEIN
• ATTACHMENT PROTEIN
• LOSS OF ENVELOPE RESULTS IN LOSS OF INFECTIVITY

48
ENVELOPE
49
5 BASIC TYPES OF VIRAL STRUCTURE
nucleocapsid
icosahedral nucleocapsid
lipid bilayer
ENVELOPED ICOSAHEDRAL
ICOSAHEDRAL
helical nucleocapsid
COMPLEX
nucleocapsid
lipid bilayer
glycoprotein spikes peplomers
HELICAL
ENVELOPED HELICAL
Adapted from Schaechter et al., Mechanisms of
Microbial Disease
50
UNCONVENTIONAL AGENTS

• VIROIDS
• RNA only
• Small genome
• Do not code for protein
• So far, only known viroids are in plants

• hepatitis delta virus (agent)
• - some viroid, some virus features

51
UNCONVENTIONAL AGENTS

• PRIONS
• protein only?
• do not contain any nucleic acid?

52
LIVING OR DEAD?
53
CLASSIFICATION

• BASIC STRUCTURE AND MOLECULAR BIOLOGY
• particularly important as diagnostic and
  therapeutic abilities expand

54
CLASSIFICATION

• NUCLEIC ACID
• CAPSID
• PRESENCE OF ENVELOPE
• REPLICATION STRATEGY

55
CLASSIFICATION NUCLEIC ACID

• RNA or DNA
• segmented or non-segmented
• linear or circular
• single-stranded or double-stranded
• if single-stranded RNA
• is genome mRNA () sense or complementary to mRNA
  (-) sense

56
CLASSIFICATION CAPSID

• symmetry
• icosahedral, helical, complex
• number of capsomers if icosahedral
• enveloped or non-enveloped

57
CLASSIFICATION

• REPLICATION STRATEGY

58
DNA VIRUSES
DOUBLE STRANDED
SINGLE STRANDED
COMPLEX
NON-ENVELOPED
ENVELOPED
PARVOVIRIDAE
POXVIRIDAE
ENVELOPED
NON-ENVELOPED
HERPESVIRIDAE
HEPADNAVIRIDAE
CIRCULAR
LINEAR
All families shown are icosahedral except for
poxviruses
PAPILLOMAVIRIDAE POLYOMAVIRIDAE (formerly grouped
together as the PAPOVAVIRIDAE)
ADENOVIRIDAE
Modified from Volk et al., Essentials of Medical
Microbiology, 4th Ed. 1991
59
RNA VIRUSES
SINGLE STRANDED
SINGLE STRANDED
DOUBLE STRANDED
positive sense
negative sense
ENVELOPED
NONENVELOPED
ENVELOPED
NONENVELOPED
HELICAL
ICOSAHEDRAL
HELICAL
ICOSAHEDRAL
ICOSAHEDRAL
ORTHOMYXOVIRIDAE
FLAVIVIRIDAE
CORONAVIRIDAE
PICORNAVIRIDAE
REOVIRIDAE
PARAMYXOVIRIDAE
TOGAVIRIDAE
CALICIVIRIDAE ASTROVIRIDAE
RHABDOVIRIDAE
RETROVIRIDAE
FILOVIRIDAE
BUNYAVIRIDAE
ARENAVIRIDAE
Modified from Volk et al., Essentials of Medical
Microbiology, 4th Ed. 1991
60
BASIC STEPS IN VIRAL LIFE CYCLE

• ADSORPTION
• PENETRATION
• UNCOATING AND ECLIPSE
• SYNTHESIS OF VIRAL NUCLEIC ACID AND PROTEIN
• ASSEMBLY (maturation)
• RELEASE

61
ADSORPTION
62
ADSORPTION

• TEMPERATURE INDEPENDENT
• REQUIRES VIRAL ATTACHMENT PROTEIN
• CELLULAR RECEPTORS

63
PENETRATION - ENVELOPED VIRUSES

• FUSION WITH PLASMA MEMBRANE
• ENTRY VIA ENDOSOMES

64
PENETRATION
herpesviruses, paramyxoviruses, HIV
65
PENETRATION - ENVELOPED VIRUSES

• FUSION WITH PLASMA MEMBRANE
• ENTRY VIA ENDOSOMES, FUSION WITH ACIDIC ENDOSOME
  MEMBRANE

66
(No Transcript)
67
(No Transcript)
68
PENETRATION - ENVELOPED VIRUSES
from Schaechter et al, Mechanisms of Microbial
Disease, 3rd ed, 1998
69
VIRUS UPTAKE VIA ENDOSOMES

• CALLED
• VIROPEXIS / ENDOCYTOSIS / PINOCYTOSIS

70
PENETRATIONNON-ENVELOPED VIRUSES
71
PENETRATIONNON-ENVELOPED VIRUSES
entry directly across plasma membrane
72
(No Transcript)
73
UNCOATING

• NEED TO MAKE GENOME AVAILABLE
• ONCE UNCOATING OCCURS, ENTER ECLIPSE PHASE
• ECLIPSE PHASE LASTS UNTIL FIRST NEW VIRUS
  PARTICLE FORMED

74
SYNTHESIS OF VIRAL NUCLEIC ACID AND PROTEIN

• MANY STRATEGIES
• NUCLEIC ACID MAY BE MADE IN NUCLEUS OR CYTOPLASM
• PROTEIN SYNTHESIS IS ALWAYS IN THE CYTOPLASM

75
ASSEMBLY AND MATURATION

• NUCLEUS
• CYTOPLASM
• AT MEMBRANE

76
smallpox virus cytoplasmic assembly and maturation
F. A. Murphy, School of Veterinary Medicine,
University of California, Davis.
http//www.vetnet.ucdavis.edu/fam_graphics/downloa
d.html
77
RELEASE

• LYSIS
• BUDDING THROUGH PLASMA MEMBRANE
• NOT EVERY RELEASED VIRION IS INFECTIOUS

78
HIV budding and maturation
Hsiung, GD et al., Diagnostic Virology 1994 p204
(D. Medina)
79
HIV mature form
Briggs JA et al. Structure. (2006) 1415-20
80
DEFINITIONS - VIRAL PROTEINS

• STRUCTURAL PROTEINS
• ALL PROTEINS IN A MATURE VIRION
• NON-STRUCTURAL PROTEINS
• VIRALLY CODED PROTEINS WHICH ARE NOT PACKAGED IN
  THE VIRION

81
EFFECTS ON HOST

• MAY INHIBIT HOST DNA, RNA OR PROTEIN SYNTHESIS
• DETAILS AND MECHANISM VARY

82
CYTOPATHIC EFFECT

• ANY DETECTABLE CHANGES IN THE HOST CELL
• MORPHOLOGICAL CHANGES

83
uninfected
HIV infected
HIV infected (at higher magnifcation)
Hockley et al. J Gen Virol 692455-2469
84
CYTOPATHIC EFFECT

• ANY DETECTABLE CHANGES IN THE HOST CELL
• MORPHOLOGICAL CHANGES
• DEATH
• APOPTOSIS
• INDEFINITE GROWTH

85
(No Transcript)
86
(No Transcript)
87
tissue culture cells
epithelial
epithelioid
fibroblastic
slides from CDC
88
epithelial cells - adenovirus
uninfected
early infection
late infection
slides from CDC
89
epithelial cells - respiratory syncytial virus
uninfected
respiratory syncytial virus
slides from CDC
90
fibroblastic cells - herpes simplex virus
uninfected
early infection
late infection
slides from CDC
91
fibroblastic cells - poliovirus
uninfected
early infection
late infection
slides from CDC
92
PLAQUE ASSAY
PLAQUE ASSAY
93
PLAQUE ASSAY
PLAQUE ASSAY
94
(No Transcript)
95
Diluted 10 fold
Diluted 100 fold
Diluted 1000 fold
96
PLAQUE FORMING UNIT

• P.F.U.
• pfu

97
SOME POINTS TO REMEMBER

• INFECTIVITY
• NOT EVERY RELEASED PARTICLE IS INFECTIOUS

• ASSAYS
• detect every particle (e.g. electron microscope)
• detect infectious particles only (e.g. plaque
  assay)

98
GLOSSARY
