Implementing Reflective Access Control in SQL

1
Implementing Reflective Access Control in SQL

• Lars E. Olson1, Carl A. Gunter1, William
  R. Cook2, and Marianne Winslett1
• 1University of Illinois at Urbana-Champaign
• 2University of Texas

2
Outline

• Motivation for RDBAC
• Transaction Datalog (TD) as a Logical Basis and
  Policy Language
• Implementation Architecture and Description
• Evaluation

3
Introduction
Bob
Carol
David
Alice
Database
4
ACM-Based Access Control
5
ACM-Based Access Control
6
ACM-Based Access Control
Sales_Employees
Bob
Sales
Sales Rep
Sales
Carol
Manager
7
ACM Weaknesses

• Complicated policies can be awkward to define
• Every employee can access their own records
• Every employee can view the name and position of
  every other employee in their department

8
Motivation

• ACMs describe extent, rather than intent
• Decision support data is often already in the
  database
• Redundancy
• Possibility of update anomalies

9
Reflective Database Access Control

• Solution access policies should contain queries
• Not limited to read-only operations
• Policies not assumed to be omniscient
• Is this a secure solution? (CCS 08)
• Is this a practical solution? (DBSec 09)

10
System Architecture
Individual User-defined Policies
TD Policy
Policy Compiler
Schema metadata
SQL1999 Recursive View Definitions
Database
User queries normally
11
Transaction Datalog

• Datalog extended with assertion and retraction
  semantics
• Inference process extended to track modifications
• Concurrency and atomicity
• Implicit rollback on failure

12
TD as a Policy Language

• Running example restrict and audit sensitive
  accesses
• view.emp(User, Name, SSN, Salary, Dept, Pos) -
• view.emp('alice', User, _, _, 'hr', _),
• view.emp('alice', Name, SSN, Salary, Dept, Pos),
• view.ins.auditLog('alice', User, Name, cur_time).

13
Compilation to SQL Views

• Off-the-shelf SQL databases benefit from years of
  query optimization research
• Datalog, SQL roughly equivalent
• User ID provided by CURRENT_USER system variable
• Recursion requires SQL1999
• Assertions and retractions
• SQL syntax does not permit insert or delete
  within select statement
• Execution ordering is significant

14
Side-Effects Within Queries

• Ideally, part of the language
• Transaction control
• Variable bindings
• In practice, executed as UDF
• Execution ordering depends on query plan
• Executing UDF(s) last
• Forbids policies with mid-execution side-effects
• Requires separate connection setup in DBs that do
  not support side-effects

15
Compilation Process (1st Pass)
view.emp(User, Name, SSN, Salary, Dept, Pos)
- view.emp('alice', User, _, _, 'hr',
_), view.emp('alice', Name, SSN, Salary, Dept,
Pos), view.ins.auditLog('alice', User, Name,
cur_time).
with view_emp as ( ... union all select e1.Name
as User, e2.Name as Name, ..., e2.Pos as
Pos, 1 as Assert_flag, e1.Name as
Assert_param1, e2.Name as Assert_param2 from
view_emp e1, view_emp e2 where e1.Dept 'hr'
and e1.Name 'alice' and e2.Name
'alice' union all ...) select distinct User,
Name, ..., Pos from view_emp where Assert_flag
0 or (Assert_flag 1 and assert_auditLog(Assert_p
aram1, Assert_param2) ! 0)
function assert_auditLog (_at_User varchar, _at_Name
varchar) ...
Schema User, Name, SSN, Salary, Dept,
Pos, Assert_flag, Assert_param1, Assert_param2
16
Compilation Process (2nd Pass)
view.emp(User, Name, SSN, Salary, Dept, Pos)
- view.emp('alice', User, _, _, 'hr',
_), view.emp('alice', Name, SSN, Salary, Dept,
Pos), view.ins.auditLog('alice', User, Name,
cur_time).
function assert_auditLog (_at_User varchar, _at_Name
varchar) ...
with view_emp as ( ... union all select e1.Name
as User, e2.Name as Name, ..., e2.Pos as
Pos, 1 as Assert_flag, e1.Name as
Assert_param1, e2.Name as Assert_param2 from
view_emp e1, view_emp e2 where e1.Dept 'hr'
and e1.Name 'alice' and e2.Name
'alice' union all ...) select distinct User,
Name, ..., Pos from view_emp where Assert_flag
0 or (Assert_flag 1 and assert_auditLog(Assert_p
aram1, Assert_param2) ! 0)
Schema User, Name, SSN, Salary, Dept,
Pos, Assert_flag, Assert_param1, Assert_param2
17
Compilation Process (cont.)

• Filter on user

create view view_emp_public as select Name, ...,
Pos from view_emp where User
CURRENT_USER grant select on view_emp_public to
public
18
Optimizations

• Recursive views are expensive!
• Use predicate unfolding
• view.emp('alice', Name, SSN, Salary, Dept, Pos)
  -
• emp(Name, SSN, Salary, Dept, Pos).
• allows us to rewrite
• view.emp('alice', User, _, _, 'hr', _)
• to
• emp(User, _, _, 'hr', _)

19
Optimizations (cont.)

• union all is expensive (although not as bad as
  recursion)
• Build query dynamically
• Pre-compute portions of rule
• If rule doesnt apply, we can eliminate a union
• Simulated with stored procedure

20
Evaluation

• Baseline
• Custom-defined views
• ACM-based enforcement
• Two baselines for side-effect queries
• No side-effect
• Side-effect UDF called within view
• Compiled views
• Unoptimized, with recursion
• Optimized with predicate unfolding
• Simulated optimization with predicate unfolding
  and union all elimination

21
Timing Results (fixed DB size)
22
Timing Results (fixed query)
23
Future Research Possibilities

• Further DB integration
• Automatic checks for safety
• Implementation of pre-computing optimization
• Improvements to TD
• Aggregation
• Negation
• Atomic update policies

24
Work on RDBAC

• Olson, Gunter, Madhusudan, A Framework for
  Reflective Database Access Control Policies, CCS
  2008
• Under review case study for medical database,
  formal policy analysis
• Research lab web page http//seclab.uiuc.edu/

25
Related Work

• Bonner, Transaction Datalog A Compositional
  Language for Transaction Programming, LNCS 1998
• Oracle Corporation, Oracle Virtual Private
  Database, Technical report, 2005
• Draxler, Accessing Relational and Higher
  Databases Through Database Set Predicates in
  Logic Programming Languages, PhD thesis, Zürich
  University, 1991
• Bossi, Cocco, Dulli, A Method for Specializing
  Logic Programs, TOPLAS 1990

26
Conclusion

• RDBAC allows more robust access control.
• Compilation of TD rules to SQL views implements
  RDBAC with current database technology.
• Performance cost of compiled views is low and can
  yet be improved.

27
Timing Results (fixed DB size and query)
28
Timing Results Franchise Scenario (fixed DB size)
