Software Radio Solutions BAE Systems and Pentek

1
Software Radio SolutionsBAE Systems and Pentek
2
Software Radio System Blocks
BAE Systems tuners and receivers complement
Pentek software radio products. BAE tuners offer
both analog IF and digital IF products directly
compatible with Pentek A/D converters and digital
receivers.
WORKSTATION
RECEIVE ANTENNA
DIGITAL
PENTEK DIGITALRECEIVER
BAE SYSTEMS ANALOG RF TUNER or RECEIVER
PENTEK DSP
PENTEK A/D CONVERTER
PENTEK D/A CONV
ANALOG
AUDIO
DISK / TAPE
WORK STATION
NETWORK SWITCH BUS EMBEDDED CONTROLLER
WIRELESS BASESTATION ROUTER
TRANSMIT ANTENNA
ANALOG RF UP CONVERTER
PENTEK D/A CONVERTER
PENTEK DIGITAL UP CONVERTER
PENTEK DSP
PENTEK A/D CONV
AUDIO
DISK / TAPE
3
Analog IF Product Compatibility
BAE tuners and receivers with analog IF outputs
are shown on the left, while Pentek software
radio products with compatible analog inputs are
shown on the right.
BAE Analog Out Receivers Tuners Pentek Analog
Input Products WJ-8604 VHF/UHF
Miniceptor 6402 Dual Chan 250 kHz 16-bit
A/D WJ-8607 VHF/UHF Miniceptor 6410 Dual Chan 10
MHz 16-bit A/D WJ-8609 VHF/UHF
Miniceptor 6420 Dual Chan 20 MHz 14- or 16-bit
A/D WJ-8611 Digital HF/VHF/UHF Receiver 6441 Dual
Chan 41 MHz 12-bit A/D WJ-8621 VHF/UHF
VXIceptor 6465 Dual Chan 65 MHz 12-bit
A/D WJ-8633 VHF/UHF Receiver 6472 Dual Chan 70
MHz 10-bit A/D WJ-8634 VXI HF/VHF/UHF
Receiver 6210 Dual Chan NB Receiver A/D -
VIM-2 SI-8614 VHF/UHF Nanoceptor 6211 Dual Chan
65 MHz 12-bit A/D - VIM-2 WJ-8654 HF/VHF/UHF
Microceptor 6216 Dual Chan WB Receiver A/D -
VIM-2 WJ-8655 Miniature VHF/UHF Receiver 6230 32
Chan NB Receiver, A/D, FPGA - VIM-4 SI- 9111
Direct HF Tuner 6231 16 Chan NB Receiver, A/D,
FPGA - VIM-2 WJ-9119 HF Tuner 6235 Dual Chan WB
Receiver, A/D FPGA - VIM-2 WJ-9117 Dual VME
Tuner 7131 16 Chan Receiver, A/D, FPGA -
PMC WJ-9127 Dual HF Tuner SI-9136 Dual VME
Tuner SI-9137 Dual VME Tuner
4
Analog IF Tuner C40 DSP
Analog IF outputs from BAE Systems tuners can be
digitized by Pentek 64xx series dual channel A/D
converters which drive 8, 16, or 32 channel
narrow band digital receivers with C40 comm port
outputs suitable for C40 processor boards.
PENTEK 2 Channel A/Ds 6U VMEbus 6402 250 kHz
16-bit 6410 10 MHz 16-bit 6420 20 MHz
14-bit 6420 20 MHz 16-bit 6441 41 MHz
12-bit 6465 65 MHz 12-bit 6472 70 MHz 10-bit
BAE SYSTEMS Tuners and Receivers 6U
VMEbus SI-9111 Direct HF SI-9117 Dual
VHF/UHF SI-9136 Dual VHF/UHF SI-9137 Dual
VHF/UHF C-size VXIbus WJ-8621 VHF/UHF
VXIceptor WJ-8633 VHF/UHF Receiver WJ-8634
HF/VHF/UHF SI-9119 HF Tuner SI-9127 Dual HF
Tuner Chassis WJ-8604 VHF/UHF Miniceptor WJ-8607
VHF/UHF Miniceptor WJ-8609 VHF/UHF
Miniceptor WJ-8611 Digital HF/VHF/UHF SI-8614
VHF/UHF Nanoceptor WJ-8654 HF/VHF/UHF µceptor
WJ-8655 Mini VHF/UHF
PENTEK Digital Receivers 6U VMEbus 6508 8 Ch
DDR 6509 8 Ch DDR 6510 8 Ch DDR 6514 16 Ch
DDR 6516 16 Ch DDR 6532 32 Ch DDR
Differential ECL
Analog IF
FPDP
C40 Comm Port
C40 Comm Port
PENTEK C40 Processors 6U VMEbus 4284 Single
C40 4269 Dual C40 4270 Quad C40 4285 Octal C40
5
Analog IF Tuner C6000 / PowerPC
The Model 6223 C40 Comm Port Adapter VIM-2
mezzanine module allows the same A/D and digital
receivers on the previous slide to be attached to
the C6000 and G4 PowerPC processor boards.
PENTEK 2 Channel A/Ds 6U VMEbus 6402 250 kHz
16-bit 6410 10 MHz 16-bit 6420 20 MHz
14-bit 6420 20 MHz 16-bit 6441 41 MHz
12-bit 6465 65 MHz 12-bit 6472 70 MHz 10-bit
BAE SYSTEMS Tuners and Receivers 6U
VMEbus SI-9111 Direct HF SI-9117 Dual
VHF/UHF SI-9136 Dual VHF/UHF SI-9137 Dual
VHF/UHF C-size VXIbus WJ-8621 VHF/UHF
VXIceptor WJ-8633 VHF/UHF Receiver WJ-8634
HF/VHF/UHF SI-9119 HF Tuner SI-9127 Dual HF
Tuner Chassis WJ-8604 VHF/UHF Miniceptor WJ-8607
VHF/UHF Miniceptor WJ-8609 VHF/UHF
Miniceptor WJ-8611 Digital HF/VHF/UHF SI-8614
VHF/UHF Nanoceptor WJ-8654 HF/VHF/UHF µceptor
WJ-8655 Mini VHF/UHF
PENTEK Digital Receivers 6U VMEbus 6508 8 Ch
DDR 6509 8 Ch DDR 6510 8 Ch DDR 6514 16 Ch
DDR 6516 16 Ch DDR 6532 32 Ch DDR
Differential ECL
Analog IF
FPDP
PENTEK VIM Processors 6U VMEbus 4290 Quad
C6201 4291 Quad C6701 4292 Quad C6203 4293 Octal
C6203 4294 Quad G4 PPC
PENTEK VIM-2 Module 6223 Comm Port I/F
VIM
6
Analog IF Tuner C6000 / PowerPC
The same A/D converters can use their FPDP
outputs to connect through the Model 6226 or 6250
FPDP Adapters for delivering A/D data to the
C6000 and G4 PowerPC processor boards. The 6250
features two Xilinx Virtex-II FPGAs.
PENTEK 2 Channel A/Ds 6U VMEbus 6402 250 kHz
16-bit 6410 10 MHz 16-bit 6420 20 MHz
14-bit 6420 20 MHz 16-bit 6441 41 MHz
12-bit 6465 65 MHz 12-bit 6472 70 MHz 10-bit
BAE SYSTEMS Tuners and Receivers 6U
VMEbus SI-9111 Direct HF SI-9117 Dual
VHF/UHF SI-9136 Dual VHF/UHF SI-9137 Dual
VHF/UHF C-size VXIbus WJ-8621 VHF/UHF
VXIceptor WJ-8633 VHF/UHF Receiver WJ-8634
HF/VHF/UHF SI-9119 HF Tuner SI-9127 Dual HF
Tuner Chassis WJ-8604 VHF/UHF Miniceptor WJ-8607
VHF/UHF Miniceptor WJ-8609 VHF/UHF
Miniceptor WJ-8611 Digital HF/VHF/UHF SI-8614
VHF/UHF Nanoceptor WJ-8654 HF/VHF/UHF µceptor
WJ-8655 Mini VHF/UHF
FPDP
Analog IF
FPDP
PENTEK VIM Processors 6U VMEbus 4290 Quad
C6201 4291 Quad C6701 4292 Quad C6203 4293 Octal
C6203 4294 Quad G4 PPC
PENTEK FPDP VIM-2 Modules 6226 Dual
FPDP 6250 Dual FPDP FPGA
VIM
7
Analog IF Tuner Classification System
By adding the Model 6099A Digital Delay Memory to
the previous slide, signals can be classified by
the DSP using the undelayed data. The delay path
allows time for signal classification so that
only signals of interest need to be stored.
PENTEK 2 Channel A/Ds 6U VMEbus 6402 250 kHz
16-bit 6410 10 MHz 16-bit 6420 20 MHz
14-bit 6420 20 MHz 16-bit 6441 41 MHz
12-bit 6465 65 MHz 12-bit
BAE SYSTEMS Tuners and Receivers 6U
VMEbus SI-9111 Direct HF SI-9117 Dual
VHF/UHF SI-9136 Dual VHF/UHF SI-9137 Dual
VHF/UHF C-size VXIbus WJ-8621 VHF/UHF
VXIceptor WJ-8633 VHF/UHF Receiver WJ-8634
HF/VHF/UHF SI-9119 HF Tuner SI-9127 Dual HF
Tuner Chassis WJ-8604 VHF/UHF Miniceptor WJ-8607
VHF/UHF Miniceptor WJ-8609 VHF/UHF
Miniceptor WJ-8611 Digital HF/VHF/UHF SI-8614
VHF/UHF Nanoceptor WJ-8654 HF/VHF/UHF µceptor
WJ-8655 Mini VHF/UHF
PENTEK Delay Memory 6U VMEbus 6099A 512 MBytes
Analog IF
FPDP
FPDP
Undelayed FPDP
Delayed FPDP
PENTEK VIM Processors 6U VMEbus 4290 Quad
C6201 4291 Quad C6701 4292 Quad C6203 4293 Octal
C6203 4294 Quad G4 PPC
PENTEK FPDP VIM Modules 6226 Dual FPDP 6250 Dual
FPDP FPGA
VIM
8
Analog IF Tuner Tracking Receiver
The same system can substitute the Model 6232
32-Channel Receiver VIM-4. Energy detection on
the wideband undelayed signals uses the DDR
bypass path. Delayed signals can then be
de-hopped by pre-tuning the receiver channels.
PENTEK 2 Channel A/Ds 6U VMEbus 6402 250 kHz
16-bit 6410 10 MHz 16-bit 6420 20 MHz
14-bit 6420 20 MHz 16-bit 6441 41 MHz
12-bit 6465 65 MHz 12-bit
BAE SYSTEMS Tuners and Receivers 6U
VMEbus SI-9111 Direct HF SI-9117 Dual
VHF/UHF SI-9136 Dual VHF/UHF SI-9137 Dual
VHF/UHF C-size VXIbus WJ-8621 VHF/UHF
VXIceptor WJ-8633 VHF/UHF Receiver WJ-8634
HF/VHF/UHF SI-9119 HF Tuner SI-9127 Dual HF
Tuner Chassis WJ-8604 VHF/UHF Miniceptor WJ-8607
VHF/UHF Miniceptor WJ-8609 VHF/UHF
Miniceptor WJ-8611 Digital HF/VHF/UHF SI-8614
VHF/UHF Nanoceptor WJ-8654 HF/VHF/UHF µceptor
WJ-8655 Mini VHF/UHF
PENTEK Delay Memory 6U VMEbus 6099A 512 MBytes
Analog IF
FPDP
FPDP
Undelayed FPDP
Delayed FPDP
PENTEK VIM Processors 6U VMEbus 4290 Quad
C6201 4291 Quad C6701 4292 Quad C6203 4293 Octal
C6203 4294 Quad G4 PPC
PENTEK DDR VIM Module 6232 32 CH DDR (DDR
bypass path)
VIM
9
Analog IF Tuner VIM
Penteks VIM mezzanines offer both A/D and DDR
functions in a single module for direct
connection to C6000 and PowerPC processor boards.
These channelized single-slot, 6U sub-systems
contain the entire signal processing chain.
PENTEK A/D and Receiver VIM Mezzanines 6210 2 Ch
65 MHz A/D 6211 2 Ch A/D 2 Ch DDR 6216 2 Ch A/D
2 Ch DDR 6230 4 Ch A/D 32 Ch DDR 6231 2 Ch
A/D 16 Ch DDR 6235 2 Ch A/D 2 Ch DDR
BAE SYSTEMS Tuners and Receivers 6U
VMEbus SI-9111 Direct HF SI-9117 Dual
VHF/UHF SI-9136 Dual VHF/UHF SI-9137 Dual
VHF/UHF C-size VXIbus WJ-8621 VHF/UHF
VXIceptor WJ-8633 VHF/UHF Receiver WJ-8634
HF/VHF/UHF SI-9119 HF Tuner SI-9127 Dual HF
Tuner Chassis WJ-8604 VHF/UHF Miniceptor WJ-8607
VHF/UHF Miniceptor WJ-8609 VHF/UHF
Miniceptor WJ-8611 Digital HF/VHF/UHF SI-8614
VHF/UHF Nanoceptor WJ-8654 HF/VHF/UHF µceptor
WJ-8655 Mini VHF/UHF
PENTEK VIM Processors 6U VMEbus 4290 Quad
C6201 4291 Quad C6701 4292 Quad C6203 4293 Octal
C6203 4294 Quad G4 PPC
Analog IF
VIM
10
Analog IF Tuner PMC
For systems requiring less processing power, the
Model 7131 16-Channel Digital Receiver and A/D
PMC module can be attached to general purpose PMC
processor platforms for VME, CompactPCI and PCI.
BAE SYSTEMS Tuners and Receivers 6U
VMEbus SI-9111 Direct HF SI-9117 Dual
VHF/UHF SI-9136 Dual VHF/UHF SI-9137 Dual
VHF/UHF C-size VXIbus WJ-8621 VHF/UHF
VXIceptor WJ-8633 VHF/UHF Receiver WJ-8634
HF/VHF/UHF SI-9119 HF Tuner SI-9127 Dual HF
Tuner Chassis WJ-8604 VHF/UHF Miniceptor WJ-8607
VHF/UHF Miniceptor WJ-8609 VHF/UHF
Miniceptor WJ-8611 Digital HF/VHF/UHF SI-8614
VHF/UHF Nanoceptor WJ-8654 HF/VHF/UHF µceptor
WJ-8655 Mini VHF/UHF
General Purpose Processor Platforms 6U / 3U
VMEbus 6U / 3U CompactPCI Desktop PCI
PENTEK A/D and Receiver PMC Mezzanines 7131 2 Ch
A/D 16 Ch DDR
Analog IF
PMC
11
Digital IF Product Compatibility
BAE tuners and receivers containing an A/D
converter with differential ECL digital IF
outputs are shown on the left. Pentek software
radio products with compatible differential ECL
digital inputs are shown on the right.
BAE Digital Out Tuners Receivers Pentek Digital
Input Products WJ-9104 Multichannel Digital
Tuner 6509 8 Chan - 2 Input - Comm Port
Out WJ-9107 Wideband Telecom 6514 16 Chan - 2
Input- Comm Port Out 6526 16 Chan - 2 Input -
RACEway Out 6532 32 Chan - 4 Input- Comm Port
Out 4271 4 Channel Narrowband - MIX 4272 2
Chan Narrowband \ 1 Chan Wideband -
MIX 6099A 512 MB Memory Delay Buffer
12
Digital IF Tuner C40
Three Pentek digital receivers with 8, 16, and 32
channels of DDR accept the differential ECL
outputs from BAE tuners. Receiver outputs are
connected to C40 processor boards using front
panel C40 comm ports.
BAE SYSTEMS Tuners and Receivers C-size
VXIbus WJ-9107 Wideband Telecom
Tuner Chassis WJ-9104 Multichannel Digital Tuner
PENTEK C40 Processors 6U VMEbus 4284 Single
C40 4269 Dual C40 4270 Quad C40 4285 Octal C40
PENTEK Digital Receivers 6U VMEbus 6509 8 Ch
DDR 6514 16 Ch DDR 6532 32 Ch DDR
Differential ECL Digital
C40 Comm Ports
13
Digital IF Tuner C6x or PowerPC
The same receivers can be connected to C6000 or
PowerPC processors by using the Model 6223 C40
Comm Port Adapter VIM-2 mezzanine module.
BAE SYSTEMS Tuners and Receivers C-size
VXIbus WJ-9107 Wideband Telecom
Tuner Chassis WJ-9104 Multichannel Digital Tuner
PENTEK Digital Receivers 6U VMEbus 6509 8 Ch
DDR 6514 16 Ch DDR 6532 32 Ch DDR
Differential ECL Digital
C40 Comm Ports
PENTEK VIM Processors 6U VMEbus 4290 Quad
C6201 4291 Quad C6701 4292 Quad C6203 4293 Octal
C6203 4294 Quad G4 PPC
PENTEK VIM-2 Module 6223 Comm Port I/F
VIM
14
Digital IF Tuner RACEway
The Model 6526 RACEway receiver accepts two
differential ECL inputs from BAE tuners and
delivers 16 narrow band receiver channels over
RACEway to RACEway-compatible processor boards
for C40, C6000, or PowerPC.
PENTEK RACEway DSP 6U VMEbus 4285 Octal
C40 4290 Quad C6201 4291 Quad C6701 4292 Quad
C6203 4293 Octal C6203 4294 Quad G4 PPC
BAE SYSTEMS Tuners and Receivers C-size
VXIbus WJ-9107 Wideband Telecom
Tuner Chassis WJ-9104 Multichannel Digital Tuner
Differential ECL Digital
PENTEK Digital Receivers 6U VMEbus 6526 16 Ch DDR
RACEway
15
Digital IF Tuner Classification System
Using the Model 6099A as a ECL-to-FPDP
translator, this system achieves the same signal
classification system described earlier.
BAE SYSTEMS Tuners and Receivers C-size
VXIbus WJ-9107 Wideband Telecom
Tuner Chassis WJ-9104 Multichannel Digital Tuner
Differential ECL Digital
PENTEK ECL to FPDP I/F 6U VMEbus 6099 64 MBytes
PENTEK Delay Memory 6U VMEbus 6099A 512 MBytes
FPDP
FPDP
Undelayed FPDP
Delayed FPDP
PENTEK VIM Processors 6U VMEbus 4290 Quad
C6201 4291 Quad C6701 4292 Quad C6203 4293 Octal
C6203 4294 Quad G4 PPC
PENTEK FPDP VIM Modules 6226 Dual FPDP 6250 Dual
FPDP FPGA
VIM
16
Digital IF Tuner Tracking Receiver
Substitute the Model 6232 32-Channel Digital
Receiver VIM-4 module for energy detection on the
wideband undelayed signals using the DDR bypass
path. Delayed signals can then be de-hopped by
pre-tuning the receiver channels.
BAE SYSTEMS Tuners and Receivers C-size
VXIbus WJ-9107 Wideband Telecom
Tuner Chassis WJ-9104 Multichannel Digital Tuner
Differential ECL Digital
PENTEK ECL to FPDP I/F 6U VMEbus 6099 64 MBytes
PENTEK Delay Memory 6U VMEbus 6099A 512 MBytes
FPDP
FPDP
Undelayed FPDP
Delayed FPDP
PENTEK VIM Processors 6U VMEbus 4290 Quad
C6201 4291 Quad C6701 4292 Quad C6203 4293 Octal
C6203 4294 Quad G4 PPC
PENTEK DDR VIM Module 6232 32 CH DDR (DDR
bypass path)
VIM
17
Quad A/D, 32-Chan Receiver DSP
This channelized receiver sub-system using the
Model 6230 VIM-4 Receiver and Model 4294 Quad G4
PowerPC contains 4 A/D converters, 32 narrow band
digital receivers, two FPGAs, four PowerPCs and
a RACE interface in one VME slot!
18
RACEway Direction Finding System
Multiple receivers tuned to a single source can
send time-stamped RACEway packets across the
RACE fabric to DSPs employing the DF
algorithms. The system is highly scalable for
numbers of channels and DSP processors.
19
Analog IF Tracking Receiver System
Wideband A/D data (red) flows directly to the
PowerPC for FFT energy detection. Digital
receivers are pre-tuned (green) so that when the
delayed A/D data arrives, signals can be
dehopped and delivered for demodulation (blue).
20
Digital IF Tracking Receiver System
This tracking receivers uses the 6250 FPGAs to
compute real time FFTs for energy detection and
tuning of the receivers in the 6232 so that
delayed signals can be de-hopped. RACE joins
the three processors for signal routing.
BAE Systems
WJ-9104 WJ-9107 Tuner
ECL
WJ-9104 WJ-9107 Tuner
ECL
21
For More Information.

• Pentek
• www.pentek.com
• One Park Way, Upper Saddle River, NJ 07458
• Tel [phone]
• Email info_at_pentek.com
• BAE Systems Gaithersburg
• www.signalsurveillance.com
• 700 Quince Orchard Rd, Gaithersburg, MD 20878
• Tel [phone]
• Email info_at_signalsurveillance.com
