Improved Inference for Unlexicalized Parsing

1
Improved Inference for Unlexicalized Parsing

• Slav Petrov and Dan Klein

2
Unlexicalized Parsing
Petrov et al. 06

• Hierarchical, adaptive refinement

91.2 F1 score on Dev Set (1600 sentences)
3

• 1621 min

4
Coarse-to-Fine Parsing
Goodman 97, CharniakJohnson 05
5
Prune?

• For each chart item Xi,j, compute posterior
  probability

lt threshold
E.g. consider the span 5 to 12
coarse
refined
6

• 1621 min
• 111 min
• (no search error)

7
Multilevel Coarse-to-Fine Parsing
Charniak et al. 06

• Add more rounds of
• pre-parsing
• Grammars coarser
• than X-bar

8
Hierarchical Pruning

• Consider again the span 5 to 12

coarse
split in two
split in four
split in eight
9
Intermediate Grammars
X-BarG0
G
10

• 1621 min
• 111 min
• 35 min
• (no search error)

11
State Drift (DT tag)
12
Projected Grammars
X-BarG0
G
13
Estimating Projected Grammars

• Nonterminals?

NP0
NP1
VP1
VP0
S0
S1
Nonterminals in ?(G)
Nonterminals in G
14
Estimating Projected Grammars

• Rules?

S ? NP VP
S1 ? NP1 VP1 0.20 S1 ? NP1 VP2 0.12 S1 ?
NP2 VP1 0.02 S1 ? NP2 VP2 0.03 S2 ? NP1
VP1 0.11 S2 ? NP1 VP2 0.05 S2 ? NP2 VP1
0.08 S2 ? NP2 VP2 0.12
15
Estimating Projected Grammars
Corazza Satta 06
Estimating Grammars
0.56
16
Calculating Expectations

• Nonterminals
• ck(X) expected counts up to depth k
• Converges within 25 iterations (few seconds)
• Rules

17

• 1621 min
• 111 min
• 35 min
• 15 min
• (no search error)

18
Parsing times
X-BarG0
G
19
Bracket Posteriors
(after G0)
20
Bracket Posteriors (after G1)
21
Bracket Posteriors
(Movie)
(Final Chart)
22
Bracket Posteriors (Best Tree)
23
Parse Selection

• Computing most likely unsplit tree is NP-hard
• Settle for best derivation.
• Rerank n-best list.
• Use alternative objective function.

24
Parse Risk Minimization
Titov Henderson 06

• Expected loss according to our beliefs
• TT true tree
• TP predicted tree
• L loss function (0/1, precision, recall, F1)

• Use n-best candidate list and approximate
• expectation with samples.

25
Reranking Results
26
Dynamic Programming
Matsuzaki et al. 05 Approximate posterior
parse distribution
à la Goodman 98 Maximize number of expected
correct rules
27
Dynamic Programming Results
28
Final Results (Efficiency)

• Berkeley Parser
• 15 min
• 91.2 F-score
• Implemented in Java
• Charniak Johnson 05 Parser
• 19 min
• 90.7 F-score
• Implemented in C

29
Final Results (Accuracy)
30
Conclusions

• Hierarchical coarse-to-fine inference
• Projections
• Marginalization
• Multi-lingual unlexicalized parsing

31
Thank You!

• Parser available at
• http//nlp.cs.berkeley.edu
