Xen and the Art of Virtualization

1
Xen and the Art of

Virtualization

• Ian Pratt
• University of Cambridge and Founder of XenSource
  Inc.

Computer Laboratory
2
Outline

• Virtualization overview
• Xen Today 2.0 Overview
• Architecture
• Performance
• Live VM Relocation
• Xen 3.0 Roadmap (Q2 2005)

3
Virtualization Overview

• Single OS image Ensim, Vservers, CKRM
• Group user processes into resource containers
• Hard to get strong isolation
• Full virtualization VMware, VirtualPC
• Run multiple unmodified guest OSes
• Hard to efficiently virtualize x86
• Para-virtualization UML, Xen
• Run multiple guest OSes ported to special arch
• Arch Xen/x86 is very close to normal x86

4
Xen Today 2.0 Features

• Secure isolation between VMs
• Resource control and QoS
• Only guest kernel needs to be ported
• All user-level apps and libraries run unmodified
• Linux 2.4/2.6, NetBSD, FreeBSD, Plan9
• Execution performance is close to native
• Supports the same hardware as Linux x86
• Live Relocation of VMs between Xen nodes

5
Para-Virtualization in Xen

• Arch xen/x86 like x86, but replaces privileged
  instructions with Xen hypercalls
• Avoids binary rewriting and fault trapping
• For Linux 2.6, only arch-dep files modified
• Modify OS to understand virtualised env.
• Wall-clock time vs. virtual processor time
• Xen provides both types of alarm timer
• Expose real resource availability
• Enables OS to optimise behaviour
• MMU virtualisation direct vs. shadow mode

6
I/O Architecture

• Xen IO-Spaces delegate guest OSes protected
  access to specified h/w devices
• Virtual PCI configuration space
• Virtual interrupts
• Devices are virtualised and exported to other VMs
  via Device Channels
• Safe asynchronous shared memory transport
• Backend drivers export to frontend drivers
• Net use normal bridging, routing, iptables
• Block export any blk dev e.g. sda4,loop0,vg3

7
Xen 2.0 Architecture
8
System Performance
1.1
1.0
0.9
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0.0
L
X
V
U
L
X
V
U
L
X
V
U
L
X
V
U
SPEC INT2000 (score)
Linux build time (s)
OSDB-OLTP (tup/s)
SPEC WEB99 (score)
Benchmark suite running on Linux (L), Xen (X),
VMware Workstation (V), and UML (U)
9
TCP results
1.1
1.0
0.9
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0.0
L
X
V
U
L
X
V
U
L
X
V
U
L
X
V
U
Tx, MTU 1500 (Mbps)
Rx, MTU 1500 (Mbps)
Tx, MTU 500 (Mbps)
Rx, MTU 500 (Mbps)
TCP bandwidth on Linux (L), Xen (X), VMWare
Workstation (V), and UML (U)
10
Scalability
1000
800
600
400
200
0
L
X
L
X
L
X
L
X
2
4
8
16
Simultaneous SPEC WEB99 Instances on Linux (L)
and Xen(X)
11
Live VM Relocation

• Why is VM relocation useful?
• Managing a pool of VMs running on a cluster
• Taking nodes down for maintenance
• Load balancing VMs across the cluster
• Why is it a challenge?
• VMs have lots of state
• Some VMs will have soft real-time requirements
• E.g. web servers, databases, game servers
• Can only commit limited resources to migration

12
Rate Limited Migration
13
Quake 3 Server migration
14
Roadmap for Xen 3.0

• SMP guest OSes
• Prototype now working, undergoing tuning
• Required careful design to get good performance
  and retain security guarantees
• Support for Intel VT-x extensions
• Run legacy unmodified OSes
• Other ports x86/64 and ia64 (ppc)
• Both Xen x86/64 and ia64 now boot!

15
Roadmap for Xen 3.0

• Better cluster management tools
• Manage pool of VMs across a set of nodes
• Better tools for QoS control
• New GUI management tool
• Improved hardware compatibility
• Graphics cards, ACPI, APM

16
Research Roadmap 4.0

• Cluster load balancing algorithms
• Exploit properties of live migration
• Software fault tolerance
• Exploit deterministic replay
• System debugging
• Lightweight checkpointing and replay
• VM forking
• Lightweight service replication, isolation
• Secure virtualization
• Multi-level secure Xen

17
Conclusions

• Xen is a complete and robust GPL VMM
• Outstanding performance and scalability
• Excellent resource control and protection
• Live relocation makes seamless migration possible
  for many real-time workloads
• http//xensource.com
• http//xen.sf.net
