Americas EvergladesConstruction Symposium and
Exhibition
3A/3B Seepage Management Area Presented By
Brown Caldwell Rod Ghioto
2
3A/3B Seepage Management Area

• Project Location
• From I-75 South past Broward/Miami-Dade line
• WCA 3A and 3B to West US-27 to East

3
3A/3B Seepage Management Area

• Project Features (North)
• Levee and canal improvements along US-27 borrow
  canal (4 miles)
• Existing structure improvements
• Improvement to FPL maintenance road (3 miles,
  raise 1 ft)
• Melaleuca removal (130 acres)

4
3A/3B Seepage Management Area

• Project Features (Middle)
• Levee and canal improvements along US-27 borrow
  canal (8 miles)
• Levees protecting properties within FPL-owned
  land
• Holly Lakes MHP Protection Levee System with
  levee, canal and pump station (60 CFS)
• Bishop/Nixon isolation with soil treatment
• Existing structure improvements (gates)
• Improvement to FPL maintenance road (4 miles,
  raise 1 ft)
• 2 Access bridges from US-27
• Recreational area and pedestrian bridge across
  C-11)
• Melaleuca removal (500 acres)

5
3A/3B Seepage Management Area

• Project Features (South)
• Levee and canal improvements along US-27 borrow
  canal (4 miles)
• Jones Trailer Park Protection Levee System with
  levee, canal and pump station (10 CFS)
• Existing structure improvements (gates)
• Improvement to FPL maintenance road (3 miles,
  raise 1 ft)
• Access bridges from US-27
• Melaleuca removal (500 acres)

6
3A/3B Seepage Management Area

• Approximate Excavation Volumes
• 3A
• 570,000 cy muck
• 1,010,000 cy rock
• 3B
• 400,000 cy muck
• 600,000 cy rock
• Other
• 75,000-100,000 cy other materials around pump
  stations

7
3A/3B Seepage Management Area

• Typical borrow canal and levee layout

8
3A/3B Seepage Management Area

• Holly Lakes pump station layout

9
3A/3B Seepage Management Area

• Schedule
• Bid and Award April-July 2008
• Construction August 2008 December 2010

10
3A/3B Seepage Management Area

• Budget
