Probabilistic Logic Learning

1
Probabilistic Logic Learning
Advanced Link Mining
15.01.04

• Ramya Ramakrishnan

2
Overview

• Statistical Predicate Invention
• Probabilistic Classification and Clustering
• Identitity Uncertainity
• - Experimental Results
• Reference

3
Link Mining

• Hypertext and link mining combines techniques
  from ILP with statistical learning algorithms
  construct features from related documents
• Learned link-based model distribution over link
  and content attributes, which may be correlated
  based on the links between them needs a complex
  classification algorithm for relational learning
• Record linkage a link mining task which is used
  for identity uncertainity in link mining,
  important to take into account not only the
  similarity between objects based on attributes
  but also based on their links

4
Statistical Predicate Invention

• Hypertext classifier is the combination of
• - statistical text learning method
• - relational rule learner
• Well suited in hypertext domains
• - word frequencies
• - hyperlinks
• Applied to tasks that involve learning
• - classes of pages
• - particular relations
• - locating a particular class of information

5
Motivation

• Documents related to one another by hyperlinks
• - sources of evidence found in neighbouring
  pages and hyperlinks
• Feature set is needed
• - text classifiers have feature spaces of
  hundreds or thousands of words

6
Approaches to Hypertext Learning

• Naive Bayes Algorithm - for text classification
• FOIL for relational learning
• Evaluate this combined algorithm on tasks
• - learning definition of page classes
• - learning definitions of relations between
  pages
• - learning to locate a particular type of
  information within pages

7
Naive Bayes

• Represent documents using bag-of-words
  representation
• Feature vector consists of one feature for each
  word
• - can be either boolean or continuous (some
  measure of frequency of the word)
• Position of the words does not matter
• Also occurence of a given word in a document is
  independent of all other words in the document

8
Naive Bayes

• Use some type os feature selection method
• Dropping un-informative words that occur on a
  stop list
• Dropping words that occur fewer than a specified
  number in the training set
• Ranking words by a measure such as their mutual
  information with the class variable, and then
  dropping low ranked words
• Stemming process of heuristically reducing
  words to their root form
• - for eg, the words compute, computers and
  computing would be stemmed to comput

9
Relational Text Learning

• Enable learned classifiers
• - to represent the relationships among documents
• - to represent the information about the
  occurence of words in documents
• Problem representation for our relational
  learning tasks consist of
• - link_to(Hyperlink,Page,Page)
• - has_word(Page)
• - has_anchor_word(Hyperlink)
• - has_neighbourhood_word(Hyperlink)
• - all_words_capitalized(Hyperlink)
• - has_alphanumeric_word(Hyperlink)

10
Relational Rule Learning

• describe the graph structure of the Web
• for word occurences in pages and hyperlinks
• has_word, has_anchor_word, has_neighbourhood_word
  predicates provide a bag-of-words representation

11
Combination

• Able to learn predicates that characterizes pages
  or hyperlinks by their word statistics
• Able to represent the graph structure of the Web
  thereby it can represent the word statistics of
  neighbouring pages and hyperlinks
• FOIL also employ the bag-of-words representation
• Two properties -
• 1. Will not be dependent on the presence or
  absence of specific key words statistical
  classifiers in its learned rules consider the
  weighted eveidence of many words
• 2. Can perform feature selection in a more
  directed manner

12

• Involves using the relational learner to
  represent the graph structure, the statistical
  learner to characterize the edges and nodes of
  the graph.
• FOIL-PILFS (FOIL with Predicate Invention for
  Large Feature Spaces) basically a FOIL
  augmented with a predicate-invention method
• Predicates invented are statistical classifiers
  applied to some textual description of pages,
  hyperlinks or components
• Assumption is that each constant in the problem
  domain has a type, and that each type may have
  one or more associated document collections
• Each document of the given type maps to a unique
  document in each associated collection
• Invents new predicates at each step of the search
  for a clause

13

• Next step is to assemble the training set for the
  Naive Bayes learner
• Learner should mainly focus on the
  characteristics that are common to many of the
  documents in the training set, instead of
  focusing on the characteristics of a few
  instances that occur many times in the training
  set
• Our method should determine the vocabulary to be
  used by Naive Bayes
• Do not necessarily want to allow Naive Bayes to
  use all of the words that occur in the training
  set as features

14

• So first each word wi that occurs in the
  predicates training set
• will be ranked
• Given this ranking, we take the vocabulary for
  the Naive Bayes classifier to be the n top ranked
  words, where n is determined by
• n e ? m
• m the number of instances in the predictes
  training set
• e a parameter (set to 0.05 for the
  experiments)
• Make the dimensionality (feature set size) of the
  predicate learning task to be small
• - when a predicate is found that fits in the
  training set well, it will generalize to new
  instances of the target class.
• Also the class priors has to be set in the Naive
  Bayes classifier

15
Summary

• Hybrid relational/statistical approach learning
  in hypertext domains
• This approach is applicable to learning tasks
  other than those that involve hypertext
• Well suited for domains that involve both
  relational structure and potentially large
  feature spaces

16
Probabilistic Classification and Clustering

• Best described by relational models
• Capture probabilistic dependencies between
  related instances
• Assume that data instances are independent and
  identically distributed(IID)
• Classification and clustering approaches have
  been designed for such IID data, where each data
  instance is a fixed length vector of attibute
  values
• Real world data sets are richer in structure
• IID assumption is violated for two papers written
  by the same author or two papers linked by
  citation, which are likely to have the same topic

17
Classification

• Iterative classification iteratively assigning
  labels to test instances the classifier is
  confident about, and using these labels to
  classify related instances
• FOIL-HUBS for classifying web pages
• None of them produces a single coherent model of
  the correlations between different related
  instances
• hence a purely procedural method is produced,
  where the results of different classification
  steps or algorithms are combined without a
  unifying principle

18
Clustering

• Emphasis is on dyadic data, such as word document
  co-occurence, document citations, web links and
  gene expresion data
• Here the clustering is viewed for one or two
  types of instances with a single relation between
  them
• But we have to model richer structures present in
  many real world domains
• Identify for each instance type, sub-populations
  of instances that are similar to both their
  attributes and their relations to other instances

19
PRM

• Extend Bayesian networks to a relational setting
• Language that allows to capture probabilistic
  dependencies between related instances
• Accomodate the entire spectrum between purely
  supervised classification and purely unsupervised
  clustering
• Can learn from data where some instances have a
  class label and other do not
• Transductive learning setting, where we use the
  test data, without the labels, in the trainign
  phase
• EM algorithm for learning such PRMs with latent
  variables from a relational database

20
Models for relational data

• Data instances are assumed to be IID samples
• Each instance belongs to exactly one of ? classes
  or clusters
• PRM is a template for a probability distribution
  over a relational database of a given schema
• Probabilistic Model -
• - Quantitative part of the PRM specifies the
  parameterization of the model
• - given a set of parents for an attribute ,
  define a local probability model by associating
  with it a CPD (conditional probability
  distribution)

21
Aggregates

• Many possible choices of aggregation operator to
  allow dependencies on a set of variables
• Mode aggregate which computes the most common
  value of its parents but not very sensitive to
  te distribution of values of its parents
• Stochastic mode aggregate will define a set of
  distribution but the aggregate is a weighted
  average of these distributions where the weight
  of vi is the frequency of this value
• Viewed as a randomized selector node

22
IMDB
Actor
Director
C
C
Gender
Movie
Role
C
Rating
Genre
Votes
Credit Order
Year
MPAA Rating
23
CORA
Author
C
Cited
Wrote
Paper
Topic
Word N
Word 1
Word 2
24
Summary

• Growing interest in learning methods to exploit
  the relational structure of the domain
• Here we construct clusters based on relational
  information
• - Since instances are not independent,
  information about some instances can be used to
  reach conclusions about others
• Main problem is the model selection when domain
  expertise is lacking, use techniques in Bayesian
  networks, allowing the learning algorithm to
  select the model structure that best suits the
  data

25
Identity Uncertainity

• objects are not labeled with unique identifiers
• those identifiers are not perceived perfectly
• May or may not correspond to the same object
• Citation Matching which citations correspond to
  the same publication
• Relational Probability Model
• Markov chain Monte Carlo method

26
Citation Matching

• Existence of a set of objects and their
  properties and relations, given a collection of
  raw perceptual data
• When two observations describe the same object
  combined to develop a complete description of the
  object
• Objects carry unique identifiers seldomly so
  identity uncertainity is ubiquitous
• Lashkari et al 94 Collaborative Interface
  Agents, Yezdi Lashkari, Max Metral, and Pattie
  Maes, Proceedings of the Twelfth national
  Conference On Artificial Inteligence, MIT Press,
  Cambridge, MA, 1994.
• Metral M. Lashkari, Y. and P. Maes.
  Collaborative Interface Agents. In Conference of
  the American Asociation for Artificial
  Intelligence, Seattle, WA, August 1994.

27
Identity Uncertainity

• Record linkage matching up records in two
  files, might be required when merging two
  databases
• Probability model developed by Cohen et al
  model the database as a combination of some
  original records and some number of erroneous
  versions
• Data Association Assigning new obeservations to
  existing trajectories when multiple objects are
  tracked
• Citeseer best example
• - System groups citations based on some greedy
  agglomerative clustering which is based on text
  similarity

28
RPM

• Consists of
• set ? of classes
• set I of named instances
• set A of complex attributes denoting functional
  relations
• set B of simple attributes denoting functions
• set of conditional probability models P(BPaB)
  for the simple attributes
• Number uncertainity
• Same-as statement
• RPMs include the unique names assumption
• Express the RPM as an Bayesian network

29
RPMs for citations
Citation.obsAuthorsi.author same-as Citation.pap
er.authorsi
30
Bayesian Network equivalent to the RPM
A12. (fnames)
A12. surname
A13. surname
A11. (fnames)
A12. fnames
A13. fnames
A11. fnames
D12. (fnames)
D12. surname
A13. (fnames)
A11. surname
D11. (fnames)
D13. surname
D12. fnames
D13. fnames
D11. fnames
A13. (fnames)
D11. surname
C1. (authors)
P1. title
C1. parse
C1. obsTitle
C1. text
P1. pubtype
31
Bayesian Network equivalent to the RPM
A22. (fnames)
A22. surname
A23. surname
A21. (fnames)
A22. fnames
A23. fnames
A21. fnames
D22. (fnames)
D22. surname
A23. (fnames)
A21. surname
D21. (fnames)
D23. surname
D22. fnames
D23. fnames
D21. fnames
A23. (fnames)
D21. surname
C2. (authors)
P2. title
C2. parse
C2. obsTitle
C2. text
P2. pubtype
32
Identity uncertainity

• Assignment i mapping of terms in the language
  to objects in the world
• For eg. if P1 and P2 are the only terms and they
  co-refer then
• i is P1,P2
• If P1 and P2 do not co-refer, then i is P1,
  P2
• Probability model for the space of extended
  possible worlds is P(i ) can be re-written as
  P(i C ) of all the classes C ? C
• Here two cases are distinguished -
• - for some classes, unique names assumption
  remains appropriate P(i Citation) to be 1.0
• - for classes such as Paper and Author,
  elements are subject to identity uncertainity
• P( i C,k,m ) that maps k named instances to m
  distinct objects

33
Inference

• The model grows from a single Bayesian network to
  a colletcion of networks approximated by Markov
  chain Monte Carlo
• Markov chain Monte Carlo - Approximating an
  expectation over some distribution p (?)
• Citation Matching Algorithm -
• - uses a factored q function to propose, first,
  a change to i, and then, values for all the
  hidden attributes of all the objects affected by
  that change
• Scaling up acknowledged flaws of MCMC algorithm
  is it often fails to scale so an efficient
  algorithm is used to preprocess a large dataset
  and fragment it into many smaller, overlapping
  set of elements that have a non-zero probability
  of matching

34
Experimental Results
Results on four citeseer data sets, for the text
matching and MCMC algorithms
35
Reference

• S. Slattery and M. Craven. Combining Statistical
  and Relational Methods for Learning in Hypertext
  Domains. In Proceedings of the 8th International
  Conference on Inductive Logic Programming.
  Springer-Verlag, 1998.
• B. Taskar, E. Segal and D. Koller. Probabilistic
  Classification and Clustering in Relational Data.
  In Proceedings of IJCAI - 01, 2001.
• H. Pasula, B. Marthi, B. Milch, S. Russell, and
  I.. Shpitser. Identity Uncertainity and Citation
  Matching. In Advances in Neural Information
  Processing Systems 15 (NIPS 2002). MIT Press,
  2003.
