SENG 521 Software Reliability

1
SENG 521Software Reliability Testing

• Fault Tolerant Software Systems Techniques (Part
  4a)

Department of Electrical Computer Engineering,
University of Calgary B.H. Far (far_at_enel.ucalgary.
ca) http//www.enel.ucalgary.ca/far/Lectures/SENG
521/04a/
2
What Is Fault Tolerance

• A fault-tolerant computing system must be capable
  of providing specified services in the presence
  of a bounded number of failures.
• These failures could occur because of faults
  present in either the components of the system or
  in the systems design.
• Building large computing systems is a complex
  task fault-tolerance requirements could make the
  task even more difficult unless appropriate
  system structuring concepts are utilized.

3
Problems

• The traditional approaches to fault tolerance in
  hardware systems have been based on coping with
  the effects of well-understood failure modes of
  physical components.
• Conventional hardware fault tolerance methods are
  rarely powerful enough to cope with deficiencies
  of design.
• Consequently, most hardware fault tolerance
  techniques cannot be applied in software, where
  almost all faults are design faults.

4
History

• Defensive programming
• Implementing relatively ad hoc methods are used
  to minimize the damage which could arise from the
  damage of presence of residual bugs.
• Dual software technique
• Implementing two distinct versions of the same
  software and executing them. Any discrepancy in
  the outputs of the two versions may trigger an
  alarm.

5
Fault Tolerance Phases /1

• Phase 1 Error detection
• For a fault to be tolerated, it must first be
  detected. Thus the starting point for
  fault-tolerance techniques is observing failures.

• Phase 2 Damage assessment
• It is necessary to assess the extent to which the
  system state has been damaged or corrupted.
• If the delay involved between the manifestation
  of a fault (failure) and the detection of its
  cause (error) is large then it is likely that the
  damage to the system state will be more severe
  than if the latency interval were shorter.

6
Fault Tolerance Phases /2

• Phase 3 Error recovery
• Error recovery techniques must be utilized in
  order to obtain a normal, error-free system
  state.
• There are two different kinds of recovery
  technique.
• Backward recovery technique consists of
  discarding the current (corrupted) state in favor
  of an earlier state Therefore, mechanisms are
  needed to record and store system states.
• Forward recovery technique involves making use of
  the current (corrupted) state to construct an
  error-free state.

7
Fault Tolerance Phases /3

• Phase 4 Fault treatment continued service
• Once recovery has been undertaken, it is
  essential to ensure that the normal operation of
  the system will continue without the fault
  immediately manifesting itself once more.
• The first aspect of fault treatment is to attempt
  to locate the fault.
• Following this, steps can be taken either to
  repair the fault or to reconfigure the rest of
  the system to avoid the fault.

8
Recovery Block Mechanism

• Syntax of a recovery block construct
• ensureltacceptance testgtby P0 else-by P1 else
  fail
• It depicts a software system with 3 components,
  the two procedures P0 (the primary) and P1 (the
  alternative), and the acceptance test.
• The design of the system is the control structure
  implied by the syntax.
• Assume that the acceptance test is perfect (i.e.,
  detects all violations of the specification) then
  the recovery block P1 will tolerate all the
  faults of procedure P0 that could lead to its
  failure.

9
Example

• Fault tolerance phases
• Error detection acceptance test (a Boolean
  expression) is used.
• Damage assessment only the program in execution
  is assumed to be affected.
• Error recovery (backward in this case) consists
  of recovering the state of the executing program
  to that at the beginning of the recovery block.
• Fault treatment the program in execution
  (primary or alternative) is assumed to be faulty,
  so its faults are avoided by executing the next
  alternative (if any).

10
Design Technique /1

• Robust Software Systems (Anderson and Lee 1981,
  etc.)
• Construction of a robust module requires
• Exception handlers for coping with exceptions
  propagated from lower levels and
• Boolean expressions for detecting exceptions
  arising in the module itself, and their exception
  handlers.
• It is often possible (and desirable for the sake
  of simplicity) to map several exceptions onto a
  single handler.

11
Design Technique /2

• Assuming the use of data abstractions (abstract
  data types) in program development.
• The software system is structured into a
  hierarchy of modules represented by an acyclic
  graph.

• Modules are represented by nodes and arrow from a
  node A to node B means that there are one or more
  operations in A that a successful completion of
  that operation depends on the successful
  completion of some operation provided by B in
  other words, B provides certain services to A.

12
Design Technique /3

• A normal chain of events consist of some
  procedure of A making a call on B, and B
  calls a lower level module (say F), this call
  returns normally, and subsequent As call returns
  normally.

13
Design Technique /4

• Exception cases
• A call from B to a lower level module returns
  an exception and this is passed to A
• A call from B to a lower level module returns
  an exception but B has exception handlers that
  can handle this and provides a normal service to
  A
• A Boolean expression in B - inserted specifically
  for detecting an error (exception) - evaluates to
  false. This is handled by either of
• Exception is masked, in which case B will
  return normally to A
• An exceptional return is obtained by A

14
Notation

• A procedure P, besides the normal return, also
  provides an exceptional return E
• procedure P(--) signals E
• The invoker of P can define the exceptional
  continuation to be some operation H which is
  called the handler of E
• P(--) E ? H
• In P the following constructs can be inserted
• T? .. signal E (1)
• OL? .. signal E (2)
• (1) represents an exception is detected by a run
  time test T.
• (2) represents the case when invocation of an
  operation 'O' results in an exceptional return L
  which in turn could lead to the signaling of
  exception E.
• When an exception is signaled using construct (1)
  or (2), the control passes to the handler of that
  exception (H).

15
Example Expected Events

• Design of a procedure P which adds three positive
  integers.
• The procedure uses operation ' ' and an
  overflow signal exception 'OV'.
• procedure P (var i,j,kinteger) signals OW
• begin
• iij OV ? signal OW
• iik OV ? ii-j signal OW
• end
• An important aspect of exception handling
  clean-up operation
• If all the procedures of a module follow this
  strategy, we get a module with the following
  highly desirable property
• Either the module produces results that reflect
  the desired normal service to the caller, or no
  results are produced and an exceptional return is
  obtained by the caller.

16
Unexpected Events /1

• The execution of P does not terminate.
• A lower level exception is detected for which
  there is no exception handler in P.
• The execution of P terminates normally (the
  invoker obtains a normal return) but the results
  produced by P are not in accordance with the
  specification.
• Situations (1) and (2) will eventually cause a
  failure of the module situation (3) represents
  the case where the module has failed but this
  event has not yet been detected by the system.

17
Unexpected Events /2

• To cope with such cases, we can employ a default
  exception handler
• procedure P (--) signals E
• begin
• end? "default handler"
• The control goes to this handler during the
  execution of P whenever an exception is detected
  for which there is no handler.

18
Unexpected Events /3

• Case (1) It is possible to start a timer
  concurrently with the invocation of P the time
  out exception will then be handled by the
  default handler.
• Case (2) All the lower level exceptions with no
  programmed handlers will similarly be handled by
  the default handler.
• Case (3) Make use of run time checks to detect
  possible violations of specifications to minimize
  the danger of undetected failures.

19
Unexpected Events /4

• What strategy should be adopted by the default
  handler?
• The simplest thing to do is to undo any
  side-effects produced by the procedure and to
  signal a fail exception.
• When the invoker receives a fail exception, it
  means that the called module has failed to
  provide the specified service.

20
Design Guidelines

• For a given module, carefully analyze the cases
  that could prevent the module from providing the
  desired normal services.
• Make use of exception handlers either to mask the
  effects of such undesired, but expected,
  exceptions or to signal an appropriate exception
  to the caller of the module.
• Make use of default exception handlers or
  recovery blocks to obtain a measure of tolerance
  against design faults.

21
Discussion

• The capability of tolerating design faults rests
  largely on the coverage of run-time checks
  (i.e. acceptance tests) for detecting errors.
• Often, it is not possible to check completely
  within a procedure that the results produced have
  been according to the specification (e.g. for a
  routine that sorts its input, the check that the
  output has been sorted would be as complex as the
  routine itself).
• Hence run-time checks are often limited to
  checking certain critical aspects of the
  specification.
• This means that the possibility of undetected
  failures cannot be ruled out entirely.
