Network and Virtualization

1

• Network and Virtualization

2
Dual Port Gigabit Ethernet

• Intel 82575EB Zoar Controller
• Dual RJ45 Connectors
• 1Gb/s per port
• PCI-e x4, Low Profile, Standard Form Factor
• Intel I/OAT
• Jumbo Frames support up to 9.5KB packets
• VMDq for Virtualized Environments
• iSCSI Boot support
• Wake On LAN (WOL)
• PXE support
• Low Power (Targeted 5W)
• RoHS Compliant 6/6
• OS Supported Linux, Windows, VMWare
• Compatible MBs All MBs with PCI-e x4 slot or
  above
• Compatible Servers All servers with PCI-e
  expansion slot

3
Quad Port Gigabit Ethernet

• Dual Intel 82571EB (Ophir) Dual-port Controllers
• Ensure priority performance on each port without
  bus sharing
• Four RJ45 Connectors (1Gb/port)
• I/OAT
• Accelerates I/O with higher throughput and lower
  CPU utilization
• Virtualization
• Provides the platform with port density required
  for virtualized environments
• PXE (Pre-boot Execution Environment)
• WOL (Port A Only)
• PROSet Utility
• Network Teaming
• RoHS Compliant 6/6
• OS Supported Windows, Linux, Netware, FreeBSD,
  VMWare
• Compatible MBs UIO MBs such as X7DWN, X7DWA-N,
  X7DBU, X7DAL-E, PDSMU, H8DMU, etc.
• Compatible Servers UIO servers such as 6015WU,
  6015B-U, 5015M-U, 2021M-U, etc.

4
10Gb Ethernet Cards

• Intel 10Gb 82598EB (Oplin) Dual-port Controller
• Dual CX4 Connectors
• PCI-e x8 (Gen2 compatible)
• I/OAT
• Accelerates I/O with higher throughput and lower
  CPU utilization
• Low Latency Interrupt
• I/O Virtualization
• Provides the platform with port density required
  for virtualized environments
• Low Power (Max 6.5W)
• iSCSI Boot
• RoHS Compliant 6/6
• Cables Supported CX4 copper based (up to 15m) or
  Intel Connects Cable (up to 100m)

AOC-UTG-i2 (UIO)
AOC-STG-i2 (Standard)
5
Dual Port Infiniband

• Mellanox ConnectX DDR MT25408A0-FCC-GI Controller
• Dual CX4 Connectors
• 20Gb/s per port
• PCI-e x8 2.0, UIO Form Factor
• Low Latency, 1.2us MPI ping latency
• TCP/UDP/IP stateless offload
• CPU offload of transport operations
• Hardware-based I/O virtualization
• RDMA, Send/Receive semantics
• RoHS Compliant 5/6
• OS Supported Novell, Redhat, Windows, Fedora
• Cables Supported CX4 copper based - up to 20m
  for 10Gb/s or 10m for 20Gb/s
• Compatible MBs UIO MBs such as X7DWN, X7DWA-N,
  X7DBU, X7DAL-E, PDSMU, H8DMU, etc.
• Compatible Servers UIO servers such as 6015WU,
  6015B-U, 5015M-U, 2021M-U, etc.
• Samples 2/08 Production 3/08

6
Layer 3 1/10 Gigabit Switch

• Layer 3 Switch
• 24 ports 1Gbit ports
• 24 x 1000BASE-T
• 4 x SFP
• Up to 4 x 10Gbit ports
• Up to 2 x stack ports
• Support VRRP, BGP routing

7
VMDq (Virtual Machine Device Queues)
???? VMDq
??? VMDq
8

9
????????? VMDq

• ??? ????????? VMDq
• Intel PRO/1000 PT
• Intel PRO/1000 PF
• Intel PRO/1000 MT
• Intel PRO/1000 MF
• Intel PRO/10Gbe

• ???? ????????? VMDq!!!
• Intel 82575 Gigabit
• Intel 82598 10 Gigabit
• Supermicro Gigabit Ethernet
• Supermicro 10Gbit Ethernet
• Intel Gigabit ET/EF
• Intel 10 Gigabit AT/AF/CX4/XF

10
Supermicro VMWare

• ??????? Supermicro ? ??????????? ??????
  ????????????? VMWare ESX/ESXi
• ????????????????? ?? VMWare ESXi
