Scalable Distributed Stream Processing

1
Scalable Distributed Stream Processing

• Presented by Ming Jiang

2
Centralized stream processing review
3
Situation when distributed

• A distributed federation of participating nodes
  in different administrative domains
• Collaboration between different domains required

4
Two complementary efforts for the situation

• Aurora
• intra-participant distribution
• Medusa
• inter-participant distribution

5
Three pieces to be shard

• Aurora
• An overlay network of communication
• Algorithms for high-availability

6
Three architectural issues

• Communications
• Load sharing
• High availability in the presence of failure

7
Communications

• Naming (participants, entity-name)
• Routing
• 1. a data source or an administrator registers a
  schema and a stream
• 2. When DS produce an event, labels

8
Communications

• Message Transport
• multiplexing all the message streams on a single
  TCP connection
• Remote definition process migration is too
  complicated

9
Load Management

• Repartitioning Aurora Networks, based on loads
  and resources
• Box Sliding
• Box Splitting

10
Box Sliding

• Takes a box on the edge of a sub-network on one
  machine and shifts it to its neighbor.

upstream box sliding
11
Box Splitting

• Create a copy of a box that is intended to run on
  second machine, to offload
• Need a filter as router

12
Box splitting
Tumble
Merge Box splitting has to be
transparent
13
Box splitting

• If predicate in filter is Blt3

A machine 1,2,3,4,7
B machine 5,6
?
A machine
B machine
final result after merge
14
Key partitioning Challenges

• Choosing what to offload
• Choosing what to split
• Choosing filters
• Others

15
High Availability
Utilize the push-based nature
16
Failure detection and Recovery

• 1. periodically send heartbeat msgs to upstream
  neighbors
• 2. if any server does not reply for pre-defined
  time, we assume it failed
• 3. initiate recovery phase, emulating the process
  of failed server
• (load shedding can be used)

17

• Thank you!
