Marine Applications of Digital Databus Systems

1
Marine Applications of Digital Databus Systems

• Cole Hersee Company

2
Topics

• Brief history of Digital Databus (DDB) technology

• What applications are there for DDB technology in
  the marine market?
• What systems are now available on the market for
  marine applications?
• General purpose
• Focused application
• Details of the Cole Hersee MiniBus Mark II DDB

3
Quick History of DDB

• Automotive/Truck
• Detroit Diesel
• DDEC
• SAE technical paper
• SAE standards
• J1587 message format
• J1708 hardware
• J1938 data link layer

• Marine
• Each marine electronics manufacturers own
  interface
• Interface agreements between manufacturers
• NMEA 0183
• NMEA 2000

4
What can DDBs do on boats?

• Enables engines to talk to panel instruments
• Enables electronics units to talk to each other
• Navigation (Radar, Sat-Nav, LORAN, Depth)
• Auto-pilot
• Communications
• Fly-by-Wire (throttle, shift and steering)
• Electrical system control

5
What types of DDB systems are currently
available for marine?

• General Purpose DDB Systems
• Capable of handling everything
• Focused Application DDB Systems
• Instrumentation
• Power control
• Systems Bridges
• Gateways, a bridge between General Purpose and
  Focused Application DDBs

6
General Purpose DDB Systems

• CAN - SAE J1939 etc, CAN - NMEA 2000, etc. are
  General Purpose systems
• Full Duplex - can talk and listen at the same
  time.
• All devices must understand all messages from all
  other devices, must communicate with each other,
  must recognize new equipment
• So every device needs to contain very intelligent
  (expensive!) microcomputers and associated
  electronics circuitry. A General Purpose DDB
  requires complex software.

7
Focused Application DDB Systems

• Generally lower priority (slow is OK) tasks
• Engines communicating with Instruments
• Switches communicating with power distribution
• Half-Duplex or Simplex (push-to-talk)
• Master/Slave
• Master Traffic Cop
• Master continually polls all units on the DDB
  System
• All communications through the Master

8
Power Control many applicationsnon-intelligent,
non-digital

• Bilge blowers
• Bilge pumps
• Head pump fan
• Live bait well pump
• Fish well pump
• Trim tabs
• Anchor winch
• Windlass
• Accessories

• Navigation lights
• Anchor lights
• Panel lighting
• Interior lighting
• Spreader lights
• Courtesy lights
• Horn
• Windshield wipers
• Motorized hatches

9
Cost of DDBsfor traditional hi-amp electrical
power control

• Super high-speed . Not required
• Large message content . Not required
• Large memory. Not required
• Automatic recognition of equipment type,
• manufacturer, model number, calibration,
• configuration, etc . Not required
• High cost of General Purpose DDB Systems
  Dont need it

10
Cole HerseeMiniBus Mark II

• A closer look at this Focused Application DDB ...

11
Cole Hersee MiniBus Objectives

• Provide complete power control
• Replace conventional power distribution panels
• Provide programmable electronic circuit breakers
• Provide system status feedback to operator
• Improve system reliability
• Reduce system cost
• Eliminate wiring harness from power distribution
  panel to helm other control stations

12
Cole Hersee MiniBusEliminate rats nest wire
harnesses
13
Cole Hersee MiniBus - a Focused
ApplicationHi-Current Power Control DDBThe
building blocks...
14
Reliable Micro-Current Switch
15
48450 Switch Interface Module
16
48408 Power Distribution Module
17
PDM - The Heart of the MiniBus

• Functionally replaces the power distribution
  panel
• Provides 8 outputs, at up to 20A each (100A max)
• Provides Electronic Circuit Breakers for each
  output
• Provides power to all SIMs on the system
• PDMs operate with any input voltage from 9 to 32V
  DC - operates on both 12V 24V systems
• One PDM Master controls the entire system
• PDM Master determines...
• which switch controls which output
• the type of switch action for all switches

18
Master - Slave Polling.
19
MiniBus DDB System

• CH proprietary communications protocol
• RS-485 databus interface Half-Duplex
• System capacity
• Up to 128 separate switching channels
• Up to 16 PDMs
• Up to 8 SIMs
• Data cable length 200ft
• No termination resistor load
• Can be close-looped back to starting unit!

20
MiniBus Mark II PDM Connections
Power
Databus cable
Outputs
21
The PDM

• PDM Master polls SIMs for info, then relays that
  info to the appropriate PDM output
• PDM Master verifies that the output really did
  execute the command (turned output On/Off)
• PDM advises SIM if the command has been
  successfully executed or if a fault is detected.
• PDM outputs all have manually-resettable
  solid-state circuit breakers

22
PDM Outputs

• Eight 20 Amp circuits
• Max 100 Amps per PDM
• Outputs are rated for
• Resistive loads
• Reactive loads (motors, etc.)
• Incandescent lighting (high surge current)

23
Short-circuit overcurrent protection

• Each output functions as a remote
  manually-resettable electronic circuit breaker
• Software algorithm simulates actions of
  conventional fuse or circuit breaker

• Programmable trip currents
• 2.0 Amps
• 3.0 Amps
• 4.0 Amps
• 5.0 Amps
• 7.5 Amps
• 10 Amps
• 15 Amps
• 20 Amps

24
Input - the DSRocker

• Its the human interface
• Its the only thing the user sees
• Its not only the command device,
  its also the acknowledgement device
• Its the users link with what they want to
  happen - and their feedback
• Switches are totally configurable...

25
Switch ConfigurationsOne Switch Model for all
functionsSwitch action is set when the PDM
Master is programmed

• Momentary switch
  On only while switch is depressed
• Toggling switch
  Push On, push Off
• Latching switch
  Top On, bottom Off

26
DSRocker Features

• Ultra-reliable microamp low milliamp switching
• Environmentally sealed
  switch contacts sealed to IPC-67 Standards
• Independent mega-bright LEDs for true function
  indication and night lighting
• Snap-in housing
• Standard large rocker mounting hole
• Available with custom back-lit graphics

27
MiniBus Mark II SIM Connections
Optional audible alarm
Databus cable
To switches
28
The SIM

• In response to polling from the master unit,
  the SIM
• Scans up to 16 switches in 8 DSRockers
• Communicates On/Off status to the PDM via
  the DDB
• In response to acknowledgement info from the
  master unit, the SIM causes LEDs
  in the DSRockers to
• Light ( switch command executed) or
• Blink on-off ( fault detected)

29
MiniBus Mark II Reliability

• Reliability - Major issue in marine applications
• Reliability - Fundamental project objective
• Reliability Proper function when subjected to
• Physical environmental extremes
• Electrical environmental extremes
• Abnormal operating conditions beyond specs.

30
Protection Alarm Modes

• 1. Output direct short circuit protection
• 2. Output over-current protection
• Programmable electronic circuit breaker mode
• 3. No Load alarm

31
Protection Alarm Modes

• 1. Output direct short circuit protection
• 2. Output over-current protection
• 3. No Load alarm
• 4. Thermal Overload alarm shutdown
• Thermal shutdown for each output
• Overall thermal shutdown PDM heat sink monitor
• Selected outputs default On for limp-home mode
• 5. Communications Failure alarm
• Selected outputs default On for limp-home mode

32
Additional Protection

• Communication System Control Electronics
• Loss-Of-Ground protection
• Overvoltage protection
• Reverse Polarity protection
• Transient protection
• DDB lines additionally protected from
  short-circuits to ground or B
• Sealed electronics
• Ignition-proof
• Intrinsically safe
• Environmentally tested to SAE J-1455

33

• MiniBus Software

34
Programming a SIM
35
Programming a slave PDM
36
Programming a PDM Master
37
Hi-Amp Power Switching System

• the switch people
• for over 80 years.
• now your digital switching partner

38
Transitioning to the MiniBus

• Cole Hersee partnering with you on -
• Engineering custom programming
• Production scheduling
• Sales support
• System development
• Implementation planning
• Compliance with applicable industry standards

39
MiniBus

• Simple building-block system
• Rockers SIMs PDMs
• Accessories
• Electronic timers.
• 85A solid-state solenoid.
• Digital conventional switches.
• Expandability!

40
Cole Hersee Timers
41
Cole Hersee Digital Switches
42
Cole Hersee Electronic Solenoids
43
Typical system cost

• Basic 8-output system approx 200
• Reduced rigging time
• Reduced inventory cost (fewer part
  numbers to stock)
• Reduced weight
• Increased flexibility customer features

44
Typical customer applicationsand MiniBus Mark II
installations
45
DDBs
46
(No Transcript)
47
(No Transcript)
48
(No Transcript)
49
(No Transcript)
50
(No Transcript)
51
(No Transcript)
52
Battle-proven!
