Proteomics

1
Proteomics
Astrid Bruckmann IBL, Leiden University
Workshop Transcriptomics and Proteomics in
Zebrafish, Leiden University,13-22 March 2006
2
Why Proteomics?
Genome - Transcriptome
- Proteome
from Graves and Haystead, 2002

• several levels of regulation from gene to
  function
• Proteins are the ultimate operating molecules
  producing the physiological effect
• Proteome the protein complement of a genome

Proteomics large-scale characterization and
functional analysis of
the proteins expressed by a genome
3
Types of proteomics and their application to
biology
from Graves and Haystead, 2002
4
Proteomics - the challenge

• The Proteome is
• - dynamic
• - highly complex
• - relative protein abundances in a cell can
  differ from 105 up to about 1010
• Proteomics aims to analyze the levels and
  structure of all proteins present in a cell or a
  tissue including their post-translational
  modifications
• (Honoré and Østergaard, 2003)
• Proteomics approaches include
• 1) protein identification
• 2) protein quantitation or differential
  analysis
• 3) protein-protein interactions
• 4) post-translational modifications
• 5) structural proteomics

Proteomics is complementary to transcriptomics
and metabolomics, integration of different
-omics data should lead to a more complete
understanding of biological systems at a
molecular level
5
Proteomics - the classical definition
Two-dimensional gelelectrophoresis (2D-PAGE) of
cell lysates
Mass spectrometry

generates global patterns of protein expression
? annotation
?
large-scale visualization of differential
protein expression
Peptide mass fingerprinting for protein
identification

• - High resolution 2D-PAGE first developed in 1975
  (OFarrell and Klose)
• - Combination with biological mass spectrometry
  (1990s)
• - Availability of genome sequences in databases
• ? central role
  in proteomic studies

6
First dimension Isoelectrofocusing (IEF)
strip containing a pH gradient immobilized on
a gel matrix (Garfin et al. 2000)
7
Position of proteins before IEF
Position of proteins after IEF
8
Second dimension SDS-PAGE
MW

• Proteins enter SDS-Polyacrylamide
• gel and are dissolved according to
• their molecular mass
• Postelectrophoretic staining of the
• proteins with
• Coomassie,
• Silver,
• Fluorescent stains (SYPRO Ruby)

9
2D-PAGE based expression proteomics

• Protein expression profiling 1000 proteins
  routinely detectable in a
• 2D-gel ? global changes in the proteome
  readily detectable

• posttranscriptional control mechanisms can
  influence protein expression
• posttranslational modifications of a protein such
  as phosphorylation, glycosylation, processing of
  signal sequences or degradation can be visualized

pI
MW
SYPRO Ruby stained gel
10
Protein identification by peptide mass
fingerprinting
from Graves and Haystead, 2002

• The unknown protein is excised from a gel and
  converted to peptides by the action of a
  specific protease. The mass of the peptides
  produced is then measured in a mass spectrometer.
• (B) The mass spectrum of the unknown protein is
  searched against theoretical mass spectra
  produced by computer-generated cleavage of
  proteins in the database.

11
Mass spectroscopy for protein identification
MALDI-TOF spectrum
MALDI-TOF
Matrix assisted laser desorption/ionisation
time-of-flight
12
Generation of protein expression reference maps

• Link protein information with DNA sequence
  information from the genome projects,
• comprehensive 2D-gel databases constructed for
  different cell types
• Listed at
• WORLD-2DPAGE http//www.expasy.org/ch2d/2d-inde
  x.html

13
2D-PAGE based differential expression proteomics

• 2D-gel electrophoresis combined with mass
  spectrometry to get
• qualitative and quantitative protein
  behavioural data
• Most frequently used method in proteome analysis

from Pandey and Mann, 2000
14
Workflow of differential expression proteomics

• Sample preparation
• Isoelectrofocusing (1.dimension)
• Equilibration incl. reduction, alkylation
• SDS-PAGE (2. dimension)
• Staining
• Imaging
• Spot detection and matching
• Normalization and quantification
• Analysis
• Cutting of selected spots
• Trypsin digestion in-gel
• Identification with mass spectroscopy
• Database comparison

Steps to be practised during the workshop
15
2D-PAGE critical points

• Samples must be run at least in triplicate to
  rule out effects from gel-to-gel
• variation ? statistics
• Standardized procedures needed to obtain a high
  reproducibility of 2D-gels

• Sample preparation as
• simple as possible
• Isoelectrofocusing conditions
• (patience)
• Staining fluorescent stains
• for high sensitivity and high
• linear range of detection

Currently possible to run 12 gels in parallel
16
Difference in-gel 2D-PAGE system (DIGE)

• Proteins are labeled prior to running the first
  dimension with up to three different fluorescent
  cyanide dyes (Unlu et al.1997)
• Allows use of an internal standard in each gel
  which reduces gel-to-gel variation,
• reduces the number of gels to be run
• Adds 500 Da to the protein labelled
• Additional postelectrophoretic staining needed

from Kolkman et al. 2005
17
Limitations and challenges of gel-based approaches

• Dynamic range detectable on 2D-gels 104, protein
  expression levels of a cell can vary between 105
  (yeast) and even 1010(humans)
• ?enrichment or prefractionation strategies
  needed to reach less abundant proteins
• Resolution of 2D-gels has its limits
• ?use narrow pH range gels and combine
• Protein extraction and solubility during IEF can
  be a problem for poorly water-soluble proteins
  e.g. membrane proteins or nuclear proteins
• Challenges for further development in gel-based
  proteomics
• improve sample preparation to be able to
  analyze extreme proteins (extremely basic or
  acidic, extremely small or big, extremely
  hydrophobic),
• sensitivity, dynamic range, automation

18
2D-gel based proteomics the state-of-the-art
versus the challenge
19
Other proteomic approaches

• Liquid chromatography coupled to mass
  spectrometry
• - Shotgun multidimensional protein
  identification technology MudPIT
• (Link et al. 1999)
• - ICAT isotope coded affinity tags (Gygi et
  al. 1999), cysteine biased
• - iTRAQ (Ross et al. 2004) amine specific
  labelling of peptides,
• quantification possible with tandem mass
  spectroscopy
• Peptide and protein arrays (Lueking et al. 1999)
• Yeast two-hybrid system (Fields and Song, 1989)
• Phage display (Zozulya et al. 1999)

20
ICAT for measuring differential protein expression

• ICAT consists of a biotin affinity group, a
  linker region
• that can incorporate heavy (deuterium) or light
  (hydrogen)
• atoms, and a thiol-reactive end group for linkage
  to
• cysteines.
• Proteins are labeled on cysteine residues with
  either the
• light or heavy form of the ICAT reagent. Protein
  samples
• are mixed and digested with a protease. Peptides
  labeled
• with the ICAT reagent can be purified using
  avidin
• chromatography.
• ICAT-labeled peptides can be analyzed by MS to
• quantitate the peak ratios and proteins can be
  identified
• by sequencing the peptides with MS/MS.

from Graves and Haystead, 2002
21
2D-PAGE in functional proteomics

• Typical question
• Identify specific proteins in a cell that undergo
  changes in abundance, localization, or
  modification in response to a specific biological
  condition
• Often combined with complementary techniques
  (protein biochemistry, molecular biology and cell
  physiology)

If - Monitoring quantitative changes in
the biological process of interest
- Quantitatively looking at protein
modifications

Then 2D-gel based proteomics is the
method of choice
22
Zebrafish samples used for 2D-GE Experiment
Phenotypic differences between untreated and
treated zebrafish embryos

• Treatment startet at high oblong stage of
  development
• Samples taken from 70-90 epiboly stage

23
Workflow of Differential Expression Proteomics

• Sample preparation
• Isoelectrofocusing (1.dimension)
• Equilibration incl. reduction, alkylation
• SDS-PAGE (2. dimension)
• Staining
• Imaging
• Spot detection and matching
• Normalization and quantification
• Analysis
• Cutting of selected spots
• Trypsin digestion
• Identification with mass spectroscopy
• Database comparison

Steps to be practised during the workshop
24
2D-Gelelectrophoresis Practical
3 different protein samples from a) untreated
embryos
b) ethanol treated embryos
c)
selenium treated embryos Experiment 1 7cm IPG
strips 3-9 NL Passive rehydration/loading per
sample 4 replicates, 12 strips run at the same
time, has already been done ? Start with
equilibration and proceed to second
dimension Experiment 2 7cm IPG strips 3-9 NL
Passive rehydration/loading per sample 2
replicates, 6 strips to be run 7cm IPG strips
7-10 Anodic cup loading to improve resolution
of basic proteins per sample 2 replicates, 6
strips to be run ?Start with performing first
dimension
25
2D-gel analysis software practical

• -Introduction into the PDQuest software
• package
• -Demonstration of an comparative
• analysis of gels from two different
• sample types (wildtype, mutant)
• -Practising PDQuest analysis of the gels
• run during the workshop
• -Compare
• a)control embryos vs.
• ethanol treated embryos
• b)control embryos vs.
• selenium treated embryos
