Specification and Analysis of CRYPTON V1.0

1
Specification and Analysis of CRYPTON V1.0

• Chae Hoon Lim
• Future Systems, Inc.

2
Contents

• Design history
• Basic building blocks
• Encryption/decryption
• Key Scheduling
• Security/efficiency analysis
• Conclusion

3
Design Objectives

• An efficient and secure block cipher
• Security
• security bounds high enough to defeat various
  existing attacks such as differential and linear
  cryptanalysis.
• A large safety margin for the future
• Efficiency
• high performance in software on large
  microprocessors
• efficient implementation on low-cost 8-bit
  microprocessors
• very high speed in hardware low hardware
  complexity
• Simplicity

4
Design Choices

• Feistel vs Substitution-Permutation Network (SPN)
• Feistel more cryptanalytic experience, fewer
  constraints in round function design poor
  parallelism
• SPN more parallelism, more hardware-efficient
  more constraints in round function design
• Choice from two alternative designs
• design based on Feistel much like Twofish
• ? SALTIS (unpublished)
• design based on SPN used the global structure of
  Square
• final decision SPN-type cipher ? CRYPTON

5
Main Features

• secure against existing attacks
• a simple, fine-grained design easy to
  implement/analyze
• symmetry in encryption and decryption
• high performance on most CPU architectures
• fast key scheduling much faster than one-block
  encryption
• efficient hardware implementation low complexity
• high degree of parallelism ? very high speed in
  hardware can achieve several Gbits/sec using
  about 30000 gates

6
CRYPTON v1.0 Motivations / Changes

• Original AES proposal (CRYPTON v0.5)
• at almost final stage of design, but not
  complete
• Motivations to revision
• key scheduling was under examination for
  modification.
• somewhat weak S-boxes decided to replace S-boxes
  with stronger ones in this opportunity.
• Tried to keep changes minimal no substantial
  redesign
• Changes
• Key scheduling strengthened (overall structure
  unchanged).
• New 8 x 8 Sboxes (2 S-boxes --gt 4 S-boxes).

7
High-level Structure of CRYPTON
8
Notation

• Data representation in 4 x 4 byte array

A0 A1 A2 A3
A (A3, A2, A1, A0)t
a03 a02 a01 a00 a13 a12 a11 a10 a23 a22
a21 a20 a33 a32 a31 a30

9
Basic Building Blocks

• Components of Round Transformation
• Byte-wise Substitution ?
• Column-wise Bit Permutation ?
• Column-to-Row Transposition ?
• Key Xoring ?
• Round Transformation ?
• Even rounds ?eK ?K o ? o ?e o ?e
• Odd rounds ?oK ?K o ? o ?o o ?o

10
Encryption/Decryption

• Round keys
• i-th round encryption Kei Ke 4ij(0 ? j ?
  3)
• i-th round decryption Kdi Kd 4ij(0 ? j ?
  3)
• ?e ? o ?e o ?, ?o ? o ?o o ?
• Kdi ?e(Ke i) for even i, ?o(Kei) for odd i.
• Encryption EK
• Decryption DK
• same as encryption except for using Kd instead
  of Ke.

11
Byte-wise Substitution ?

• Odd rounds
• Even rounds

S0
S1
S2
S3
S0
S1
S2
S3
S1
S0
S2
S3
S1
S0
S2
S3
S1
S0
S2
S3
S1
S0
S2
S3
S1
S0
S2
S3
S1
S0
S2
S3
Even rounds
Odd rounds
12
Column-wise Bit Permutation ? (1)
?1 ?0 ?3 ?2
?3 ?2 ?1 ?0
Odd rounds
Even rounds
13
Column-wise Bit Permutation ? (2)

• m0 0xfc, m1 0xf3, m2 0xcf, m3 0x3f
• for 4-byte column vectors a and b, b ?0(a) is
  defined by

14
Column-to-Row Transposition ? / Key Add ?

• Transposition B ?(A) ? bij aji
• Key addition
• B ?K(A) ? Bi Ai ? Ki for i0,1,2,3.

a03
a02
a01
a00
a00
a30
a10
a20
?
a13
a12
a11
a10
a01
a31
a11
a21
a23
a22
a21
a20
a02
a32
a12
a22
a33
a32
a31
a30
a03
a33
a13
a23
15
Key Scheduling (1)

• Overall structure two-step generation
• ? facilitate low-level implementations

User Key (032bytes)
?
?
Expanded Keys (32bytes)
Decryption Transform
Encryption Round Keys
Decryption Round Keys
16
Key Scheduling (2)

• Already planned at the beginning
• Known weakness 232 weak keys for 256-bit key
• found by J. Borst and S. Vaudenay independently.
• due to regular patterns preserved in both round
  key generation and round transformation
• Changes
• major changes made in round key generation
• used distinct round constants
• used 2/6-bit byte rotation and word-wise rotation
• Consequence believed secure against most known
  key schedule weaknesses

17
Diffusion Property of ? (1)

• Achieve diffusion order 4
• ? at least 4 active bytes on average per round
• Minimum diffusion set ? ?x ? ?y
• 0x01,0x02, 0x03, 0x04, 0x08, 0x0c, 0x10, 0x20,
  0x30, 0x40, 0x80, 0xc0
• ? 0x11, 0x12, 0x13, 0x21, 0x22, 0x23, 0x31,
  0x32, 0x33, 0x44, 0x48, 0x4c,
• 0x84, 0x88, 0x8c, 0xc4, 0xc8, 0xcc

18
Diffusion Property of ?i (2)

• Ij a set of input vectors of diffusion order 4
  under ?i with j nonzero bytes
• No.minimum diffusion vectors 48486048 204

19
Minimum Diffusion Patterns by ? o ?
Type-1
Type-2
Type-3
Type-4
Round 1
Round 2
Round 3
Round 4
20
Differential/Linear Prob. for n?n S-box S

• S-box differential prob.
• ?x / ?y input/output differences, resp.
• S-box linear prob.
• ?x / ?y input/output selection vectors, resp.

21
S-box Construction (1)

• One 8x8 involution S-box S ? 4 S-boxes Si

ROL7
ROL5
S
S
S
S
ROL1
ROL3
S2
S3
S0
S1
22
S-box Construction (2)

• Design criteria for S-boxes
• should be efficiently implementable in hardware
  logic and on low-cost smart cards.
• The prob. of differential and linear
  characteristics should be as small as possible.
• High prob. I/O differences/selection vectors in S
  should have as high Hamming weights as possible.
• The number of such pairs in all Sis should be as
  small as possible when restricted to ?.

23
The S-box S Search Model
P1-1
P0
Left rotate by n bits
Bit Permutation
Inverse Bit Permutation
ROLn
ROLn
P0-1
P1
24
The Selected S-box S
Input x
x7 x6 x5 x4 x3 x2
x1 x0
P1
P0
4-bit P-boxes
z7 z6 z5 z4 z3 z2
z1 z0
z7 z6 z5 z4 z3 z2
z1 z0
Linear involution
z4 z0 z3 z7 z5 z1
z2 z6
z2 z5
z7 z0
w3 w2 w1 w0 w7 w6
w5 w4
P0-1
P1-1
Inverse P-boxes
Output y
y3 y2 y1 y0 y7 y6
y5 y4
25
Differential/Linear Char. of S-boxes (1)

• Previous S-boxes too many high prob. I/O pairs
• The new S-boxes
• Pr(DC) ? 10/256 2-4.68 for only 7 pairs
• Pr(LC) ? (32/128)2 2-4 for only 6 pairs
• High prob. char. sum of Hamming weights is at
  least 4, on average ? 8.

26
Differential/Linear Char. of S-boxes (2)

• Observarion
• min. 4 active bytes/round only for byte values in
  ?
• for such values, max. entry in distr. tables 6
  / 24
• Pr(DC) ? 6/256 2-5.42
• Pr(LC) ? (24/128)2 2-4.83

27
Differential/Linear Cryptanalysis - Bounds

• Observations
• Min. No. of active S-boxes up to 8 rounds 32
• Suppose that all such active S-boxes have
• Pr(DC) 2-5.42 and Pr(LC) 2-4.83.
• Overall char.prob.of DC/LC up to 8 rounds
• pC8 ? (2-5.42)32 2-173.3
• pL8 ? (2-4.83)32 2-154.6
• Differential, linear hull/multiple linear
  approx.
• may increase the probabilities by a constant
  factor.

28
Differential/Linear Cryptanalysis - Simulation

• Partial exhaustive search over the minimum
  diffusion set
• theoretically breakable up to 7 rounds

29
Variants/Extensions of DC/LC

• Variants of DC
• truncated/higher-order differentials,
• impossible differentials a number of impossible
  differentials up to 4 rounds none for more than
  5 rounds
• Variants of LC
• nonlinear approximations, generalized LC,
  partitioning cryptanalysis

30
Other Possible Attacks

• interpolation attacks no simple algebraic
  description
• dedicated SQUARE attacks
• the best known attack up to 6 rounds
• cant be extended to more round versions
• Side-channel cryptanalysis
• timing attacks
• differential fault analysis
• differential power analysis
• Key schedule cryptanalysis
• weak keys, semi-weak keys, equivalent keys
• simple relations, related keys

31
Software Efficiency

• 32-bit ?Ps same as the previous version
• Pentium Pro 200 MHz, Windows 95, MSVC 5.0
• UltraSparc 167 MHz, Solaris 2.5, GNU C
• 8-bit ?Ps 256 byte ROM, 52 byte RAM a little
  bit slower than the previous version

32
Hardware Efficiency

• Gate array implementation of 2-round iterative
  version
• VHDL description logic synthesis using Synopsys
  HYUNDAIs 0.35 micron gate array library
• Simulation results

33
Conclusion

• Advantages
• strong security against various known attacks
  (with at least 3-round safety margin)
• symmetry in encryption and decryption
• uniformly fast on various architectures in
  software
• efficiently implementable in hardware
• high degree of parallelism very high speed in
  hardware
• Remarks
• can be freely used royalty-free
• welcome any comments/analysis reports
