Hardware Considerations

1
Hardware Considerations

• Chapter 2,3

2
Topics

• Hardware consideration Chapter 2

3
XINU and Router

• Xinu is a small, elegant system that follows a
  hierarchical structure. http//en.wikipedia.org/wi
  ki/Xinu
• Wireless router Access points, wireless
  communication
• WRT54GL Wireless broadband router
• Link
• Embedded Xinu
• Its goal is to port the XINU Operating System to
  the MIPS platform by specifically targeting
  LinkSys WRT54GL routers.
• http//xinu.mscs.mu.edu/

4
WRT54GL Wireless router from Linksys

• Firmware running the operations
• Need to communicate with the firmware
• Load OpenWRT/XINU or other home brewed code into
  the router
• Need basic access through a serial port to the
  firmware
• Need console access to the firmware
• That is the purpose of the hardware update.

5
Project 1 Load Embedded XINU into WRT54GL
wireless router

• We create a little computer out of WR54GL by
  loading embedded XINU in to its RAM.
• Assemble the components needed to add a UART chip
  to the WRT54GL that will enable you to access
  WRT54GL storage and devices.
• Obtain a cross-compiler to compile embedded XINU
  kernel into MIPS code for the CPU on WRT54GL.
• We have downloaded a Linux-based cross-compiler
  that will compile the embedded XINU files and
  generate xinu.boot or variations of this.
• Download embedded xinu tar ball and untar it and
  compile it (gmake) to obtain it to generate the
  xinu.boot
• Lets study the various components of the embedded
  XINU distribution.

6
Once you have downloaded and extracted the xinu
tarball, you will see a basic directory
structure AUTHORS include/ LICENSE README
system/ tty/ compile/ lib/ loader/ shell/ test/
uart/ AUTHORS is a brief history of
contributors to the XINU operating system in it's
varying iterations. compile/ contains the
Makefile and other necessities for building the
XINU system once you have a cross-compiler.
include/ contains all the header files used by
XINU. lib/ contains a folder (libxc/) with a
Makefile and source for the library, as well as a
binary blob which contains the pre-compiled
library. LICENSE is the license under which
this project falls. loader/ contains assembly
files and is where the bootloader will begin
execution of O/S code. README is this document.
shell/ contains the source for all shell
related functions. system/ contains the source
for all system functions such as the nulluser
process (initialize.c) as well as code to set up
a C environment (startup.S). test/ contains a
number of testcases (which can be run using the
shell command testsuite). tty/ contains the
source for the tty driver. uart/ contains the
source for the uart driver.
7
Next steps

• Connect the serial port of the modified hardware
  to the serial port of a host computer with
  xinu.boot code.
• Use a serial communication program (say using a
  Hyperterminal) to configure the serial port of
  the host to the settings 8 data bits, no parity
  bit, and 1 stop bit (8N1) with a speed of 115,200
  bps.
• Use another router to form a local network and
  assign IP addresses to the router and the host
  computer.
• Power up the WRT54GL. If you send cntrlC (break)
  characters from host console, you will see it
  responding with CFEgt (common firmware environment
  for WRT54GL)
• The Broadcom Common Firmware Environment (CFE) is
  a collection of software modules for
  initialization and bootstrap of designs
  incorporating Broadcom MIPS64 processors. Link
• Serial port you created is your means to
  communicate with WRT54GL CFE
• Use a TFTP on the host to make the boot images
  available on the network for XINU to boot.
  (How?)
• ifconfig eth0 auto (obtain ip address for eth0
  of WRT54GL)
• boot -elf host ipxinu.boot (initiate a TFTP
  boot)
• Above two commands are given from CFE command
  line
• Once XINU boots (uploads into the RAM), you will
  see XINU shell.
• Now you can run XINU commands help, ps etc.
• Add a simple C program hello.c to print hello
  world.

8
Hardware Basics

• Von Neumann Architecture
• Hardware interfacing
• Latching recording the appearance of a signal
  for later processing
• Edge vs. level triggering
• Tristate logic high, low, tristated
• Wait state
• System interfaces and buses address, data,
  control
• Universal asynchronous synchronous relay terminal
  (UART) is typically used for parallel to serial
  transfer

9
Standard Interfaces

• MIL-STD-1553B
• Small Computer system interface (SCSI)
• IEEE 1394 firewire

10
MIL-STD-1533B

• Widely used in military and commercial avionics
• Specifies hardware configuration and transmission
  and receipt protocols
• 1533-bus protocol is a master-slave protocol one
  module on the bus acts as a master and others as
  slaves and respond to masters commands.
• Coupling of the devices is such that one device
  failure does not affect the others.
• Master puts out device number followed by the
  packets to that device.
• Also standard provides specification for handling
  of failure of the master.

11
SCSI (Scuzzy)

• Parallel interface to many devices
• SCSI 1, 2, 3, narrow, wide, fast , ultra,
  ultra-2, ultra-160
• SCSI supports daisy chained devices
• SCSI supports Fiber Channel and Firewire besides
  familiar ribbon cable
• Daisy chained devices can communicate
  independently
• Device 0 is the boot device and other devices get
  non-0 id.
• Examples interfaces to hard drive, CDROMs,
  scanners and other peripherals

12
IEEE 1394 Firewire

• Standard specifies very fast external bus that
  supports data transfer rates of up to 400
  megabits per sec. (1394a) and 800 Mbps in 1394b.
• Apple developed the technology
• Can connect up to 63 devices
• Multiple speeds on single bus, thus avoiding
  daisy chaining and peer-peer
• Hot pluggable devices can be added and removed
  when the bus is active
• Two types of transfer asynchronous and
  isochronous
• Isochronous data transfer at predetermined rate
  multimedia applications used in cameras, VCRs,
  televisions, audio devices

13
Memory Technologies

• Ferrite core (dinosaur of memories)
• Semiconductor memory (RAM)
• Fusible link ROM and nonvolatile
• UVROM ultra violet erasable ROM
• EEPROM Electronically erasable PROM
• Flash memory rewritable PROM that uses single
  transistor per bit commonly used in embedded
  real-time applications.
• Ferroelectric RAM 40ns access times, 64 Mbyte
  arrays.

14
Memory organization and map
FFFFFFFF
FFFFFF00
FFFFFE00
FFC00000
E0000F00
E0000000
00000000
15
Input/output

• Programmed input/output an IN instruction will
  transfer data from input device to a CPU
  register. An OUT instruction does the opposite.
• Example to control the speed of a motor
  (controller) connected to system in the device
  space as programmed IO
• LOAD R1, speed
• LOAD R2, motoraddress
• OUT

16
Direct memory access (DMA)

• When using a DMA, access to the computers memory
  is given other devices in the system without CPU
  intervention.
• Lets discuss its circuitry and operation.

17
Memory mapped IO

• Does not require special IN and OUT operation.
• Certain designated locations of memory appear as
  virtual IO ports.
• For controlling the speed of a stepper motor
• LOAD R1, speed
• STORE R1, motor_address
• Where speed is a bit mapped command
• Bit 0 light on
• Bit 1..3 control other devices
• Bit 4..7 stepper motor speed (4 bits for 16
  different speeds)

18
Interrupts

• Interrupts are signals generated to indicate
  exceptional events.
• Internal and external interrupts
• Instruction support for interrupts enable and
  disable interrupts
• Internal CPU handling of interrupts Current
  state including PC is saved and the control is
  transferred to ISR (interrupt service routine).
• What to do when dealing with multiple external
  devices all working asynchronously with the CPU?
• Use a programmed interrupt controller (PIC).

19
Enhancing Performance

• Exploit locality of reference paging heavily
  used cell phones and networked handheld devices
• Cache recent computations, current data set,
  current locality of instructions
• Pipelining used in RISC processors
• Coprocessors for special processing digital
  signal processing (DSP), fast Fourier transforms
  (FFT), etc.

20
Transducers

• Transducers are devices that convert energy from
  one form to another.
• Temperature sensors (or any sensor)
• Accelerometer compression of piezoelectric
  device is exploited to convert the compression of
  an electrical signal.
• Position resolvers
• A/D converters

21
Kernel Device drivers
Servers (application , web , component )
Shell
XWin
Thread lib
ftp
User applications
System call interface
Process, memory, file system, network managers.
Kernel
Device drivers
Hardware/controller
Devices
22
Real-time Kernels

• A process is an abstraction of a running program
  and a logical unit of work scheduled by the
  operating system.
• A thread is a light weight process that
  represents of a flow of control thorough a
  process.
• Real-time operating system must provide these
  specific functions for processes
• Scheduling
• Dispatching
• Intercommunication and synchronization
• Kernel of an operating system provides these
  functions.

23
Simple kernels

• Polled loop Say a kernel needs to process
  packets that are transferred into the DMA and a
  flag is set after transfer
• for()
• if (packet_here)
• process_data()
• packet_here0
• Excellent for handling high-speed data channels,
  a processor is dedicated to handling the data
  channel.
• Disadvantage cannot handle bursts

24
Simple kernels cyclic executives

• Illusion of simultaneity by taking advantage of
  relatively short processes in a continuous loop
• for()
• process_1()
• process_2()
• process_3()
• process_n()
• Different rate structures can be achieved by
  repeating tasks in the list
• for()
• process_1()
• process_2()
• process_3()
• process_3()

25
Cyclic Executives example Interactive games

• Space invaders
• for()
• check_for_keypressed()
• move_aliens()
• check_for_keypressed()
• check_collision()
• check_for_keypressed()
• update_screen()
• check_keypressed() checks for three button
  pressings move tank left or right and fire
  missiles.
• If the schedule is carefully constructed we could
  achieve a very efficient game program with a
  simple kernel as shown above.

26
Finite state automata and Co-routine based kernels

• void process_a(void)
• for()
• switch (state_a)
• case 1 phase_a1()
• case 2 phase_a2()
• .
• case n phase_an()
• void process_b(void)
• for()
• switch (state_b)
• case 1 phase_b1()
• case 2 phase_b2()
• .
• case n phase_bn()

• state_a and state_b are state counters
• Communication between coroutines thru global
  variables
• Example the fanous CICS from IBM Customer
  Information Control System
• IBMs OS/2 uses this in Windows presentation
  management.

27
Interrupt driven systems

• Main program is a simple loop.
• Various tasks in the system are schedules via
  software or hardware interrupts
• Dispatching performed by interrupt handling
  routines.
• Hardware and software interrupts.
• Hardware asynchronous
• Software typically synchronous
• Executing process is suspended, state and context
  saved and control is transferred to ISR
  (interrupt service routine)

28
Interrupt driven systems code example

• void main()
• init()
• while(TRUE)
• void int1(void)
• save (context)
• taks1()
• retore (context)
• void int1(void)
• save (context)
• taks1()
• restore (context)

• Foreground/background systems is a variation of
  this where main does some useful task in the
  background

29
Process scheduling

• Scheduling is a very important function in a
  real-time operating system.
• Two types pre-run-time and run-time
• Pre-run-time scheduling create a feasible
  schedule offline to meet time constraints,
  guarantee execution order of processes, and
  prevents simultaneous accesses to shared
  resources.
• Run-time scheduling allows events to interrupt
  processes, on demand allocation of resources ,
  and used complex run-time mechanisms to meet time
  constraints.

30
Task characteristics of real workload

• Each task Ti is characterized by the following
  temporal parameters
• Precedence constraints specify any tasks need to
  precede other tasks.
• Release or arrival time ri,j jth instance of
  ith task
• Phase Fi release time of first instant of ith
  task
• Response time time between activation and
  completion
• Absolute deadline instant by which task must
  complete
• Relative deadline maximum allowable response
  time
• Period Pi maximum length of intervals between
  the release times of consecutive tasks.
• Execution time the maximum amount of time
  required to complete a instance of the task
  assuming all the resources are available.
• Lets look at some examples next week.

31
Summary

• We studied hardware considerations for embedded
  and real time systems.
• Hardware choices and design of the various
  controllers have significant effect on the
  performance of a RT embedded systems.
