The 3rd Generation of Virtualisation: VMware Infrastructure 3

1
The 3rd Generation of VirtualisationVMware
Infrastructure 3

• Danny Claproth
• Channel SE
• dclaproth_at_vmware.com

2
Agenda

• Virtualisation Benefits
• Virtualisation Generations
• VMware Infrastructure 3

3
Tradition x86 Architecture

• Single OS per machine
• Software and hardware tightly coupled
• Multiple applications often conflict
• Underutilized resources introduce real cost into
  the infrastructure

? Old model doesnt work anymore!
4
Virtualized x86 Architecture

• Separate OS and hardware break hardware
  dependencies
• OS and Application as single unit by
  encapsulation
• Strong fault and security isolation
• Standard, HW independent environments can be
  provisioned anywhere
• Flexibility to chose the right OS for the right
  application

5
Yesterdays Virtualisation

• 1st Generation Virtualisation
• Introduced partitioning technology to the x86
  platform
• First x86 hypervisor supporting Dos, Netware,
  Windows and Linux
• Single server management
• Local Storage
• Resource Control for a single physical server
• Runs small workloads

6
Todays Virtualisation

• 2nd Generation Virtualisation
• Central Management for multiple physical servers
• Centralized Storage using the Virtual Machine
  File System (VMFS)
• Introduced the technology to move Running
  Virtual Machines (VMotion)
• Central managed resource control per physical
  server
• Production ready platform with 20.000 customers
• Runs small to medium workloads

7
Introducing the next Generation of Virtualisation

• 3rd Generation Virtualisation
• Aggregates industry-standard (x86) servers into
  a single unified identity
• Uses logical Resource Pools to manage
  consumption
• Provides Service Level Agreements to manage
  groups of Virtual Machines
• Allows central backup protection for ALL Virtual
  Machines
• Delivers failure protection for ALL Virtual
  Machines
• Runs all types of workloads

8
The 3rd Generation Virtualisation Suite

• VMware ESX Server 3.0
• VMware VirtualCenter 2.0
• 4-way vSMP / 16GB Virtual RAM support
• Distributed Virtual Machine File System
• VMware VMotion
• VMware High Availability
• VMware Distributed Resource Scheduling
• VMware Consolidated Backup

9
VMware Infrastructure 3 Customer impact
Simplify Operations
Increase Service Levels
Deploy Pervasively
10
Simplify Operations
11
Align and scale capacity to business needs
Virtual Desktops
BI
CRM
Development
Production
Engineering
Marketing
12
Non-disruptive capacity on demand
13
IncreaseService Levels
14
Automate resource assurance for critical
applications

• Dynamic Balancing
• Continuous Optimization

DRS
15
Automatic availability for all applications
X
16
Transforming availability service levels
Application availability
CONTINUOUS
CLUSTERED
AUTOMATED RESTART
with VMware Infrastructure
UNPROTECTED
100
10
0
Application coverage
17
Backup anytime
BACKUP
BACKUP
BACKUP
BACKUP
BACKUP

• Decouple backup from production VMs
• 20-40 better resource utilization
• Pre-integrated with 3rd party backup products

18
Transforming data protection service levels
ONLINE, OFF-HOST CONTINUOUS
Backup options
ONLINE, OFF-HOST IMAGE
with VMware Infrastructure
ONLINE IMAGE
STANDARD NETWORK BACKUP
UNPROTECTED
100
10
0
Application coverage
19
Deploy Pervasively
20
Freedom of Choice Any OS and workload
WORKLOADS
OPERATING SYSTEMS
NEW
64-bit
16GB
4-way V-SMP
21
Summary

• Dramatic and real cost savings
• VI3 Infrastructure Virtualization Suite
• Simplified operations
• Increased Service levels
• Extended range of supported platforms
• Available now!

22
Questions?
