Title: Patterns for access control


1
Patterns for access control
  • E.B. Fernandez

2
Access control models
  • An access control model defines who can access
    what and in what manner in a system
  • Some secure design methodologies start from use
    cases and from them a conceptual model is
    developed. Security constraints are then defined
    in the conceptual model. The most important
    constraints are related to access control

3
Many access control models
  • There are many models for access control, mostly
    variations of some basic models and it is
    confusing for a software developer to select an
    appropriate model for her application
  • Access control models generally represent a few
    types of security policies, e.g. rights are
    assigned to roles, and provide a formalization
    of these policies using some ad hoc notation
  • Four basic access control models are commonly
    used and they may be extended to include other
    aspects
  • Access control models can be defined for
    different architectural levels, including
    application, database systems, operating systems,
    and firewalls
  • Some of them apply to any type of systems while
    some are specialized, e.g. for distributed
    systems.

4
Model dimensions
  • Access control models fall into two basic
    categories mandatory models (MAC), where users
    rights are defined by administrators and data may
    be labeled to indicate its sensitivity, and
    discretionary (DAC), where users may administer
    the data items they create and own
  • In a MAC model users and data are classified by
    administrators and the system applies a setoff
    built-in rules that users cannot circumvent
  • In a DAC model, there is no clear separation of
    use and administration users can be owners of
    the data they create and act as their
    administrators
  • Orthogonal to this classification, there are
    several models for access control to information
    that differ on how they define and enforce their
    policies

5
Basic models for access control
  • The Multilevel model organizes the data using
    security levels. This model is usually
    implemented as a mandatory model where its
    entities are labeled indicating their levels.
    This model is able to reach a high degree of
    security, although it can be too rigid for some
    applications.
  • The Access Matrix describes access by subjects
    (actors, entities) to protected objects (data,
    resources) in specific ways (access types). It is
    more flexible than the multilevel model and it
    can be made even more flexible and precise using
    predicates and other extensions. It is
    intrinsically a discretionary model in which
    users own the data objects and may grant access
    to other subjects. This model is usually
    implemented using Access Control Lists (lists of
    the subjects that can access a given object) or
    Capabilities (tickets that allow a process to
    access some objects).
  • Role-Based Access Control (RBAC), collects users
    into roles based on their tasks or functions and
    assigns rights to each role. RBAC has been
    extended and combined in many ways.
  • Attribute-Based Access Control (ABAC). This model
    controls access based on properties of subjects
    or objects. It is used in environments where some
    subjects may not be pre-registered

6
Many variants
  • While these basic models may be useful for
    specific domains or applications, they are not
    flexible enough for the full range of policies
    present in some of these applications
  • A large variety of ad hoc RBAC variations that
    have been proposed most of which add specialized
    policies to a basic RBAC
  • For example, some models have added content or
    context-dependent access, delegation, role
    hierarchies, task-based access, and relationships
    between role entities
  • All these models effectively incorporate a set of
    built-in access control policies and cannot
    handle situations not considered by these
    policies

7
Confusion for the designer
  • All these models present a bewildering set of
    options to the designer, who has problems
    deciding which model to use
  • The result in practice is that only basic models
    are used and the power of more advanced models is
    thus lost
  • We try to clarify this panorama here through the
    use of patterns
  • We use pattern diagrams to make clear the pattern
    space and help in their selection
  • A subproduct is the analysis of which patterns
    are available for use and which need to be
    written
  • Pattern maps are also useful to perform
    semi-automatic model transformations

8
What is a pattern?
  • A requirement for a pattern is that the solution
    it describes has been used in at least three real
    systems
  • This is consistent with the idea of patterns as
    best practices
  • However, a pattern can also describe solutions
    that have not been used (or have been used only
    once) but appear useful for several situations
  • Because of this, we include here both types
    good practices patterns and useful solutions
    patterns
  • We consider more important their genericity

9
Structure of models
  • Access control models have two aspects a
    definition of a set of rules specifying the valid
    accesses (some of them may be implicit), and an
    enforcement mechanism that intercepts access
    requests from users or processes and determines
    if the request is valid
  • The main difference between models is on the way
    they define their rules, so it makes sense to
    separate the enforcement mechanism
  • For each type of models we provide separate
    patterns for rules and only one pattern for
    enforcement.

10
Organizing the models
  • Pattern diagrams can help the designer in the
    selection of an appropriate model
  • Starting from a basic Authorization (Access
    Matrix) pattern we can add elements
  • The basic access matrix defines rights for
    individual subjects to access resources

11
Access matrix authorization rules
  • Basic rule ( s, o, t ) , where s is a subject
    (active entity), t is an access type, and o is an
    object
  • Extended rule ( s, o , t , p, f) , where p is a
    predicate (access condition or guard) and f is a
    copy flag
  • This, and the other models, can be described by
    patterns

12
Authorization/Access Matrix
13
Patterns derived from the Access Matrix
14
Reference Monitor
  • Each request for resources must be intercepted
    and evaluated for authorized access
  • Abstract concept, implemented as memory access
    manager, file permission checks, CORBA adapters,
    etc.

15
(No Transcript)
16
Analyze elements of the access matrix
  • Understand function of each element subject,
    object, access type
  • Consider administrative approaches (MAC and DAC)
  • Start from a general pattern that defines
    structure of authorization rules Policy-Based
    Access Control

17
(No Transcript)
18
  • We can expand each branch of the big pattern to
    focus on some specific aspects and analyze better
    the pattern relationships
  • The initial pattern diagram could have been
    obtained in this way

19
Policies and sessions
20
Growing models from simpler models
  • Each pattern can be augmented with new features
    to produce a new variety of models
  • The next figure shows the basic RBAC pattern,
    where users are assigned to roles and roles are
    given rights
  • The NIST standard adds the concept of session and
    a simple role hierarchy
  • The next figure shows a model of RBAC beyond the
    NIST standard where in addition we have
    object/resource hierarchies where the hierarchies
    are recursive (described by the Composite pattern)

21
(No Transcript)
22
NIST model with composite hierarchies
23
A more advanced RBAC model
24
Distributed systems
  • The nature of distributed systems implies that a
    subject does not need to be known in advance by
    the system in order to request access to a
    resource
  • The use of credentials including attributes may
    be sufficient to trust a subject.
  • In the next diagram, traditional models, such as
    the Access Matrix and RBAC (Role-Based Access
    Control), are represented along with
    Attribute-Based Access control and Policy-Based
    Access control
  • All of the models use a Reference Monitor to
    enforce access decisions
  • ACL (Access Control List) and Capability are
    implementation-oriented patterns they implement
    the Access Matrix or RBAC model
  • For web services, XACML (eXtensible Access
    Control Markup Language) Access Control
    Evaluation implements the Attribute-Based Access
    control pattern and the Policy-Based Access
    control pattern, and the XACML Policy Language
    implements the Policy-Based Access control
    pattern
  • The SAML Authorization Assertion is a kind of
    Capability.

25
Patterns for distributed systems
26
More complex models
  • With these basic units we can compose more
    complex, implementation-oriented AC systems
  • Policy-based access control defines access
    evaluation based on general policies stored in
    some repository
  • Depending on the objects, rights are defined by
    administrators or users, the policies may define
    a MAC or DAC model, respectively
  • Policy-based access control uses a reference
    Monitor for its enforcement functions and a
    Policy pattern that defines the general structure
    of each policy
  • Policy-based access control may be specialized to
    implement models such as the Access Matrix, RBAC,
    or ABAC by convenient adaptation of the policy
    structure.

27
Policy-Based access control
  • The Policy-Based Access Control pattern decides
    if a subject is authorized to access an object
    according to policies defined in a central policy
    repository.
  • Context We consider centralized or distributed
    systems with a large number of resources
    (objects). A large number of subjects may access
    those objects. Some rules are defined to control
    access to objects. The rules defined by the
    organization are typically designed by different
    actors (technical, organizational, legal, etc),
    and each set of rules designed by a specific
    policy designer can concern overlapping sets of
    objects and/or subjects. We assume that access
    requests come from authenticated subjects.

28
(No Transcript)
29
Models through analogies
  • We can build security models through analogies
    when two standards or regulations have similar
    types of policies
  • We can convert a HIPAA model into a
    Sarbanes/Oxley model

30
(No Transcript)
31
Moving to SOX
  • The Patient record can become a Financial record,
    the Patient becomes an Investor, the doctor is
    now a Broker
  • This approach simplifies the task of building
    pattern catalogs and makes it easier for users to
    remember what patterns to use in a given
    situation.

32
A SOX model
33
Conclusions
  • We can navigate the pattern diagram because
    patterns are composable, i.e. adding a feature
    (perhaps embodied by another pattern) produces a
    new pattern with extra features
  • Using this approach we could not only clarify the
    relationships of AC models but it lead us also to
    discover the need for new security patterns
    Subject, Object, Labeled security, DAC, MAC
  • In order to apply this approach one needs
  • A good catalog of security patterns to
    let designers find
  • the required solution to each security
    restriction
  • A classification of patterns according to
    their security
  • concerns and architectural level
Write a Comment
User Comments (0)
About PowerShow.com
