Computer Networking

1
Computer Networking
Yishay Mansour (mansour at cs.tau.ac.il)
Teaching Assistant Hillel Avni
2
Course Information

• Lectures Sunday 4 7
  Orenstein 111
• Exercises Wednesday 11 12, 12 1 Super
  Center 315 ????? ??

Web site http//www.cs.tau.ac.il/research/hille
l.avni/courses/comnet10.html
Books

• A Top-down Approach to Computer Networking /
  Kurouse-Ross

• An Engineering Approach to Computer Networking /
  Keshav
• Computer Networks / Tanenbaum
• Data Networks / Bertsekas and Gallager

3
Practical Information
Homework assignment Mandatory Both
theoretical and programming
Grades Final Exam 60 theory exercises
20 Programming exercises 20
4
Motivation

• Todays economy
• manufacturing, distributing, and retailing goods
• but also creating and disseminating information
• publishing
• banking
• film making.
• part of the information economy
• Future economy is likely to be dominated by
  information!

5
Information?

• A representation of knowledge
• Examples
• books
• bills
• CDs DVDs
• Can be represented in two ways
• analog (atoms)
• digital (bits)
• the Digital Revolution
• convert information as atoms to information as
  bits
• use networks to move bits around instead of atoms

6
The Challenges

• represent all types of information as bits.
• move the bits
• In large quantities,
• everywhere,
• cheaply,
• Securely,
• with quality of service,
• .

7
Todays Networks are complex!

• hosts
• routers
• links of various media
• applications
• protocols
• hardware, software

Tomorrows will be even more!
8
Internet Physical Infrastructure

• Residential access
• Cable
• Fiber
• DSL
• Wireless

• The Internet is a network of networks
• Each individually administrated network is called
  an Autonomous System (AS)

• Campus access, e.g.,
• Ethernet
• Wireless

8
9
This courses Challenge

• To discuss this complexity in an organized way,
  that will make todays computer networks (and
  their limitations) more comprehensive.
• identification, and understanding relationship of
  complex systems pieces.
• Problems that are beyond a specific technology

10
Early communications systems

• I.e. telephone
• point-to-point links
• directly connect together the users wishing to
  communicate
• use dedicated communication circuit
• if distance between users increases beyond the
  length of the cable, the connection is formed by
  a number of sections connected end-to-end in
  series.

11
Data Networks

• set of interconnected nodes exchange information
• sharing of the transmission circuits
  "switching".
• many links allow more than one path between every
  2 nodes.
• network must select an appropriate path for each
  required connection.

12
Qwest backbone
http//www.qwest.com/largebusiness/enterprisesolut
ions/networkMaps/preloader.swf
13
Networking Issues - Telephone

• Addressing - identify the end user
• phone number 1-201-222-2673 country code city
  code exchange number
• Routing - How to get from source to destination.
• Telephone circuit switching Based on the phone
  number.
• Information Units - How is information sent
• telephone Samples _at_ Fixed sampling rate. not self
  descriptive! have to know where and when a sample
  came

14
Networking Issues - Internet

• Addressing - identify the end user
• IP addresses 132.66.48.37, Refer to a host
  interface network number host number
• Routing- How to get from source to destination
• Packet switching move packets (chunks) of data
  among routers from source to destination
  independently.
• Information Units - How is information sent.
• Self-descriptive data packet data metadata
  (header).

15

• Telephone networks support a single, end-to-end
  quality of service but is expensive to boot

Internet supports no quality of service but is
flexible and cheap
Future networks will have to support a wide range
of service qualities at a reasonable cost
16
History 1961-1972 Early packet-switching
principles

• 1961 Kleinrock - queuing theory shows
  effectiveness of packet-switching
• 1964 Baran - packet-switching in military
  networks
• 1967 ARPAnet conceived by Advanced Research
  Projects Agency
• 1969 first ARPAnet node operational

• 1972 ARPAnet demonstrated publicly
• NCP (Network Control Protocol) first host-host
  protocol
• first e-mail program
• ARPAnet has 15 nodes

17
History 1972-1980 Internetworking, new and
proprietary nets

• 1970 ALOHAnet satellite network in Hawaii
• 1973 Metcalfes PhD thesis proposes Ethernet
• 1974 Cerf and Kahn - architecture for
  interconnecting networks
• late70s proprietary architectures DECnet, SNA,
  XNA
• late 70s switching fixed length packets (ATM
  precursor)
• 1979 ARPAnet has 200 nodes

18
Cerf and Kahns internetworking principles

• minimalism, autonomy - no internal changes
  required to interconnect networks
• best effort service model
• stateless routers
• decentralized control

Defines todays Internet architecture
19
History 1980-1990 new protocols, proliferation
of networks

• 1983 deployment of TCP/IP
• 1982 SMTP e-mail protocol defined
• 1983 DNS defined for name-to-IP-address
  translation
• 1985 FTP protocol defined
• 1988 TCP congestion control

• new national networks CSnet, BITnet, NSFnet,
  Minitel
• 100,000 hosts connected to confederation of
  networks

20
History 1990 - commercialization and WWW

• early 1990s ARPAnet decommissioned
• 1991 NSF lifts restrictions on commercial use of
  NSFnet (decommissioned, 1995)
• early 1990s WWW
• hypertext Bush 1945, Nelson 1960s
• HTML, http Berners-Lee
• 1994 Mosaic, later Netscape
• late 1990s commercialization of WWW

21
Demand and Supply

• Huge growth in users
• The introduction of the web
• Faster home access
• Better user experience.
• Infrastructure
• Significant portion of telecommunication.
• New evolving industries
• Although, sometimes temporary setbacks

22
Internet Users
23
Penetration around the Globe (2009)
http//www.internetworldstats.com/stats.htm
24
Users around the Globe (2002/5/9)
25
Technology Modem speed
26
Todays options

• Modem 56 K
• ISDN 64K 128K
• Frame Relay 56K
• Today High Speed Connections
• Cable, ADSL, Satellite.
• All are available at
• 5Mb (2005)
• 30 Mb (2009)

OBSOLETE
27
Coming soon (1999)
28
Today (2005)
29
Why do we need Standards

• Networks (and other media) support communication
  between different entities
• Need agreement to ensure correct, efficient and
  meaningful communication

30
Various Organizations Issue Standards

• IEEE (Institute for Electrical and Electronic
  Engineers)
• IETF (Internet Engineering Task Force)
• ITU (International Telecommunications Union)
• ISO (International Organization for
  Standardization)
• W3C (World Wide Web Consortium)

31
Protocol Layers

• A way for organizing structure of network

• Or at least our discussion of networks

• The idea a series of steps

32
Protocol Layering

• Necessary because communication is complex
• Intended primarily for protocol designers
• Divides the problem into intellectually
  manageable pieces
• Provides a conceptual framework that can help us
  understand protocols
• Think of layering as a guideline, not a rigid
  specification
• Understand that optimizations may violate strict
  layering
• Should be invisible to users

33
Mail system functionality
34
How do we Communicate?
Hollywood, California

• Send a mail from Alice to Bob
• Alice in Champaign, Bob in Hollywood
• Example
• US Postal Service

Bob
Champaign, Illinois
Alice
35
What does Alice do?
Alice 200 Cornfield Rd. Champaign, IL 61820
Bob 100 Santa Monica Blvd. Hollywood, CA 90028

• Bobs address (to a mailbox)
• Bobs name in case people share mailbox
• Postage have to pay!
• Alices own name and address
• in case Bob wants to return a message
• In case the mail has to be returned.

36
What does Bob do?
Alice 200 Cornfield Rd. Champaign, IL 61820
Bob 100 Santa Monica Blvd. Hollywood, CA 90028

• Install a mailbox
• Receive the mail
• Get rid of envelope
• Read the message

37
Layers
Person delivery of parcel Post office counter
handling Ground transfer loading on trucks
Airport transfer loading on airplane Airplane
routing from source to destination
Peer entities

• each layer implements a service
• via its own internal-layer actions
• relying on services provided by layer below

38
Advantages of Layering

• explicit structure allows identification
  relationship of complex systems pieces
• layered reference model for discussion
• modularization eases maintenance updating of
  system
• change of implementation of layers service
  transparent to rest of system

39
Protocols

• A protocol is a set of rules and formats that
  govern the communication between communicating
  peer
• set of valid messages - syntax
• meaning of each message - semantics
• Necessary for any function that requires
  cooperation between peers

40
Protocols

• A protocol provides a service
• For example the post office protocol for
  reliable parcel transfer service
• Peer entities use a protocol to provide a service
  to a higher-level peer entity
• for example, truck drivers use a protocol to
  present post offices with the abstraction of an
  unreliable parcel transfer service

41
Protocol Layers

• A network that provides many services needs many
  protocols
• Some services are independent, But others depend
  on each other
• A Protocol may use another protocol as a step in
  its execution
• for example, ground transfer is one step in the
  execution of the example reliable parcel transfer
  protocol
• This form of dependency is called layering
• Post office handling is layered above parcel
  ground transfer protocol.

42
Open protocols and systems

• A set of protocols is open if
• protocol details are publicly available
• changes are managed by an organization whose
  membership and transactions are open to the
  public
• A system that implements open protocols is called
  an open system
• International Organization for Standards (ISO)
  prescribes a standard to connect open systems
• open system interconnect (OSI)
• Has greatly influenced thinking on protocol stacks

43
ISO OSI reference model

• Reference model
• formally defines what is meant by a layer, a
  service etc.
• Service architecture
• describes the services provided by each layer and
  the service access point
• Protocol architecture
• set of protocols that implement the service
  architecture
• compliant service architectures may still use
  non-compliant protocol architectures

44
The seven Layers
There are only 5 !!
Application
Intermediate system
End system
End system
45
The seven Layers - protocol stack
data
TH
Network
Data Link
DHdataDT
Physical
bits

• Session and presentation layers are not so
  important, and are often ignored

46
?????? ??????
????? X ?????? ????? ??? ?????? ????? X ???? ???
?????
Destination
Source
Application
Application
Identical message
Transport
Transport
Identical message
Network
Network
Identical message
Data-Link
Data-Link
Network
47
Postal network

• Application people using the postal system
• Session and presentation chief clerk sends some
  priority mail, and some by regular mail
  translator translates letters going abroad.
• Transport layer mail clerk sends a message,
  retransmits if not acked
• Network layer postal system computes a route and
  forwards the letters
• datalink layer letters carried by planes,
  trains, automobiles
• physical layer the letter itself

48
Internet protocol stack

• application supporting network applications
• ftp, smtp, http
• transport host-host data transfer
• tcp, udp
• network routing of datagrams from source to
  destination
• ip, routing protocols
• link data transfer between neighboring network
  elements
• ppp, ethernet
• physical bits on the wire

49
Protocol layering and data
source
destination
message
application transport network Link physical
segment
datagram
frame
50
Physical layer L1

• Moves bits between physically connected
  end-systems
• Standard prescribes
• coding scheme to represent a bit
• shapes and sizes of connectors
• bit-level synchronization
• Internet
• technology to move bits on a wire, wireless link,
  satellite channel etc.

51
Datalink layer L2

• (Reliable) communication over a single link.
• Introduces the notion of a frame
• set of bits that belong together
• Idle markers tell us that a link is not carrying
  a frame
• Begin and end markers delimit a frame
• Internet
• a variety of datalink layer protocols
• most common is Ethernet
• others are FDDI, SONET, HDLC

52
Datalink layer (contd.)

• Ethernet (broadcast link)
• end-system must receive only bits meant for it
• need datalink-layer address
• also need to decide who gets to speak next
• these functions are provided by Medium ACcess
  sublayer (MAC)

• Datalink layer protocols are the first layer of
  software
• Very dependent on underlying physical link
  properties
• Usually bundle both physical and datalink in
  hardware.

53
Network layer L3

• Carries data from source to destination.
• Logically concatenates a set of links to form the
  abstraction of an end-to-end link
• Allows an end-system to communicate with any
  other end-system by computing a route between
  them
• Hides idiosyncrasies of datalink layer
• Provides unique network-wide addresses
• Found both in end-systems and in intermediate
  systems

54
Network layer types

• In datagram networks
• provides both routing and data forwarding
• In connection-oriented network
• separate data plane and control plane
• data plane only forwards and schedules data
  (touches every byte)
• control plane responsible for routing,
  call-establishment, call-teardown (doesnt touch
  data bytes)

55
Network layer (contd.)

• Internet
• network layer is provided by Internet Protocol
  (IP)
• found in all end-systems and intermediate systems
• provides abstraction of end-to-end link
• segmentation and reassembly
• packet-forwarding, routing, scheduling
• unique IP addresses
• can be layered over anything, but only
  best-effort service

56
Network layer (contd.)

• At end-systems
• primarily hides details of datalink layer
• segments and reassemble
• detects errors

• At intermediate systems
• participates in routing protocol to create
  routing tables
• responsible for forwarding packets
• schedules the transmission order of packets
• chooses which packets to drop

57
Transport layer L4

• Reliable end-to-end communication.
• creates the abstraction of an error-controlled,
  flow-controlled and multiplexed end-to-end link
• (Network layer provides only a raw end-to-end
  service)
• Some transport layers provide fewer services
• e.g. simple error detection, no flow control, and
  no retransmission

• Internet
• TCP provides error control, flow control,
  multiplexing
• UDP provides only multiplexing

58
Transport layer (contd.)

• Error control
• GOAL message will reach destination despite
  packet loss, corruption and duplication
• ACTIONS retransmit lost packets detect,
  discard, and retransmit corrupted packets detect
  and discard duplicated packets
• Flow control
• match transmission rate to rate currently
  sustainable on the path to destination, and at
  the destination itself
• Multiplexes multiple applications to the same
  end-to-end connection
• adds an application-specific identifier (port
  number) so that receiving end-system can hand in
  incoming packet to the correct application

59
Session layer

• Not common
• Provides full-duplex service, expedited data
  delivery, and session synchronization
• Internet
• doesnt have a standard session layer

60
Session layer (cont.)

• Duplex
• if transport layer is simplex, concatenates two
  transport endpoints together
• Expedited data delivery
• allows some messages to skip ahead in end-system
  queues, by using a separate low-delay transport
  layer endpoint
• Synchronization
• allows users to place marks in data stream and to
  roll back to a prespecified mark

61
Presentation layer

• Usually ad hoc
• Touches the application data
• (Unlike other layers which deal with headers)
• Hides data representation differences between
  applications
• characters (ASCII, unicode, EBCDIC.)
• Can also encrypt data
• Internet
• no standard presentation layer
• only defines network byte order for 2- and 4-byte
  integers

62
Application layer

• The set of applications that use the network
• Doesnt provide services to any other layer

63
?????? ??????
Destination
Source
VoIP
Application
Email(smtp)
ftp
UDP
Transport
TCP
Network (IPv4)
Network
Ethernet
Data-Link
WiFi
Modem
Network
64
?????? ??????
Destination
Source
app3
app1
app2
UDP
TCP
Network (IPv4)
Ethernet
WiFi
Modem
Network
65
Discussion

• Layers break a complex problem into smaller,
  simpler pieces.
• Why seven layers?
• Need a top and a bottom ? 2
• Need to hide physical link so need datalink ? 3
• Need both end-to-end and hop-by-hop actions so
  need at least the network and transport layers ?
  5

66
Course outline
