Goldilocks: Efficiently Computing the HappensBefore Relation Using Locksets

1
Goldilocks Efficiently Computing the
Happens-Before Relation Using Locksets

• Tayfun Elmas1, Shaz Qadeer2, Serdar Tasiran1
• 1Koç University, Istanbul, Turkey
• 2Microsoft Research, Redmond, WA

FATES/RV06 August 15-16, Seattle, WA
2
Our goal

• Continuous runtime monitoring of concurrent Java
  programs
• Target Race conditions
• Criteria
• Efficiency Tolerable impact on performance
• Precision Prevent false alarms
• The Java Memory Model (JMM) Manson et.al,
  POPL05
• Two accesses form a data race in an execution of
  a program if
• they conflict,
• they are from different threads and
• they are not ordered by happens-before (H-B).
• Exact H-B computation ? precise race detection

3
Existing dynamic approaches

• Vector-clock algorithms Mattern, 1989
• Vector clock For each thread and variable, a
  vector of logical clocks
• Vector has size T threads
• Vector updated at each synchronization operation
• Precise but inefficient in some cases
• O(T) computation at each synchronization
  operation
• Other algorithms use cheaper checks for
  well-protected variables
• Thread-local variables, variables protected by
  single locks
• Lockset algorithms Savage et.al.,
  1997
• Lockset A set of locks protecting access to
  variable d
• Lockset update rules specific to a
  synchronization discipline
• Efficient, intuitive, but imprecise
• False alarms Synchronization discipline violated
  but no race occurred
• Additional mechanisms to reduce false alarms
• State machines for object initialization, escape,
  thread-locality

4
Our work

• The Goldilocks algorithm
• Novel lockset-based method thatprecisely
  computes H-B
• As efficient as other lockset algorithms
• As precise as vector-clocks
• Uniformly captures all synchronization
  disciplines
• Our locksets contain locks, volatile variables,
  thread ids
• Theorem When thread t accesses variable d, there
  is no race
• iff
• Lockset of d at that point contains t
• Sound Detects all apparent races that occur in
  execution
• Precise Race reported ? Two accesses not ordered
  by H-B
• No false alarms
• No alarms about potential races in similar
  executions

5
Outline

• The Goldilocks algorithm
• Implementation
• Evaluation
• Conclusions

6
Example
T1 T2 T3
a IntBox()
class IntBox int x
L1
b IntBox()
acquire(L1)
L2
a.x
Global Variablesa, b IntBoxo1.x, o2.x int
release(L1)
acquire(L1)
acquire(L2)
tmp a
a b
b tmp
release(L1)
L1
release(L2)
acquire(L2)
L2
b.x
release(L2)
7
Eraser
a IntBox()
LS(o1.x) all locks
b IntBox()
acquire(L1)
T1
a.x
release(L1)
acquire(L1)
acquire(L2)
tmp a
T2
a b
b tmp
release(L1)
release(L2)
acquire(L2)
b.x
T3
release(L2)
8
The happens-before relation

• Happens-before in JMM ?hb
• Transitive closure of
• Program orders of threads ?p
• Synchronizes-with ?sw
• release(l) ?sw acquire(l)
• vol-write(v) ?sw vol-read(v)
• fork(t) ?hb (action of t)
• (action of t) ?hb join(t)

T1
a.x
T2
b.x
T3
9
Goldilocks intuition

• LS (Variables) ? ?(Threads ?? Locks ? Volatiles)
• Update rules maintain invariants
• Thread t ? LS(d) ? ? t is owner of d
• Accesses to d by t are race-free
• Lock l ? LS(d) ? acquire l to become
  owner of d
• Volatile v ? LS(d) ? read v to become owner of
  d
• When t accesses d Race-free iff (t ? LS(d))
• After t accesses d LS(d) t
• t is the only owner of d
• Other threads Must synchronize with t
• In order to become an owner of d

10
Lockset update rules

• Ownership transfer between threads
• LS(d) grows through synchronization actions
• release(l) by t
• For each variable d if (t ? LS(d)) ? (add l to
  LS(d))
• acquire(l) by t
• For each variable d if (l ? LS(d)) ? (add t to
  LS(d))
• volatile-write(v) by t
• For each variable d if (t ? LS(d)) ? (add v to
  LS(d))
• volatile-read(v) by t
• For each variable d if (v ? LS(d)) ? (add t to
  LS(d))
• fork(s) by t
• For each variable d if (t ? LS(d)) ? (add s to
  LS(d))
• join(s) by t
• For each variable d if (s ? LS(d)) ? (add t to
  LS(d))

11
Goldilocks
a IntBox()
LS(o1.x) ?
b IntBox()
acquire(L1)
T1
a.x
release(L1)
acquire(L1)
acquire(L2)
tmp a
T2
a b
b tmp
release(L1)
release(L2)
acquire(L2)
b.x
T3
release(L2)
12
Uniform handling of many scenarios

• Dynamically changing locksets
• Permanent/temporary thread-locality
• Container-protected objects
• Lockset of contained variable changesalthough
  variable is not touched
• Synchronization using wait/notify(All)
• No additional lockset update rules
• Synchronization using volatile variables
• Conditional branches on volatile variables
• Classes in java.util.concurrent package
• Semaphores, barriers, ...

13
Outline

• The Goldilocks algorithm
• Implementation
• Evaluation
• Conclusions

14
Implementation

• Naive implementation too inefficient
• acquire(l) by thread t
• For each variable d if (l ? LS(d)) ? (add t to
  LS(d))
• Implementation features
• Short-circuit checks before lockset computation
• Handle thread-locality, unique protecting
  lock,...
• Lazy evaluation of locksets
• Apply update rules at only variable access
• Keep synchronization actions in a global event
  list
• Order of events consistent with ?p and ?sw
• Implicit, shared representation of locksets
• Use temporary locksets only at access

15
Implementation in Kaffe

• In the Kaffe Virtual Machine
  http//www.kaffe.org
• Clean room implementation of JVM in C
• Full Java platform functionality
• Instrumented byte-code interpreter
• Functions executing instructions for
  synchronization, heap access
• Per thread checking
• Each thread checks its own actions
• Communication via global event list
• Applicable to multiprocessors
• Handle-Action (Thread t, Action ?)
• IF ? is a synchronization action
• Add ? to the global event list
• ELSE IF ? is an access to variable d
• IF all short-circuit checks fail
• Apply-Lockset-Rules(t, d)

16
Short-circuit checks

• Sufficient, constant time checks for H-B
• If any of them succeed No race
• ? No need for lockset computation
• Track owner thread
• For each variable d, keep the last accessor
  thread
• owner-thread(d) Current accessor thread
• Succeeds when d remains thread-local
• Track single unique lock
• For each variable d, guess a unique protecting
  lock
• single-lock(d) Random lock held by current
  accessor thread
• Succeeds as long as d is accessed while holding
  same lock

17
Lazy evaluation of locksets
18
Outline

• The Goldilocks algorithm
• Implementation
• Evaluation
• Conclusions

19
Evaluation

• Algorithms evaluated
• Goldilocks
• Eraser with state machines
• Vector-clocks
• Benchmarks
• Microbenchmarks Interesting, artificial programs
• Multiset Well-protected insertions, deletions,
  lookups of integers
• SharedSpot Contains variables each protected by
  a unique lock
• LocalSpot Contains thread-local variables
• Larger programs for performance comparison
• Raja, SciMark, Grande

20
Microbenchmarks

• Interesting cases Thread-locality, variables
  protected by single unique locks
• Short-circuit checks work
• Per-access cost increasesvery slowly with of
  threads

21
Large benchmarks

• Goldilocks much faster than vector clocks
• Performance comparable to Eraser
• Precision comes at little or no extra cost

22
Conclusions

• The Goldilocks algorithm A precise lockset-based
  characterization of the happens-before relation
• Sound Detects all apparent races
• Precise No false alarms
• Efficient Short-circuit checks Lazy evaluation
• Handles all synchronization disciplines uniformly
• Thread-locality, dynamically changing
  locksets,volatile variable-based
  synchronization, ...
• Applicable to both model checking runtime
  monitoring
• Future work
• Dynamic static methods based on Goldilocks
• Tolerable cost for continuous runtime monitoring
• Tight integration of static methods and Goldilocks
