Title: End of Semester Presentation


1
End of Semester Presentation
  • May 06, 2005
  • TTA Rolling Team
  • ChangSup Keum
  • JungHo Kim
  • SeonAh Lee
  • ShinYoung Ahn

2
Contents
  • Introduction
  • Activities (Spring 2005)
  • Reflection
  • Future Work

3
I. Introduction
  • Rolling Team Goal Role
  • Customer Overview
  • Business Context

4
Rolling Team Goal Role
  • Team Goal
  • Learning Team challenge, practice and master new
    techniques
  • Smart Team work effectively and efficiently
  • Satisfying Stakeholders hit all major deadlines
  • Team Role (Spring 2005)
  • Mentors David Root, Jim Tomayko

Seonah Lee Team Leader Requirement
Shinyoung Ahn Planning Manager Risk
Changsup Keum Process Manager Development
Jungho Kim Support Manager Configuration
5
Customer Overview
  • TTA (Telecommunication Technology Association)
  • Establishes IT standards
  • Tests and certifies IT products
  • TTA tests many kinds of IT / Telecom products
  • Wireless LANs, broadband technologies,
    CORBA-based platforms
  • Specifies test cases in Tree and Tabular Combined
    Notation (TTCN), an international standard
    for test specification
  • Why does TTA initiate this studio project?
  • TTA is using a commercial tool to translate from
    TTCN to C code
  • However, the C code generated by the tool is
    unreadable
  • Macros, Insufficient comments, Incomprehensible
    identifiers

6
Business Context Diagram
  • Test Engineers need to review and modify the
    Abstract Test Suite (ATS) before making an
    Executable Test Suite (ETS)

Test Equipment
PC / Windows
Executable Test Suite
Test Case in TTCN
Standard
Test Case in C
101010111
int test (int b) return
(verdict)
TestGen
LT!GetX LT?PDU
Legend
Data In/Out
Manual Conversion
Hardware Environment
External Entity
System
Standard
Data File
7
II. Activities (Spring 2005)
  • Project Management
  • Risk Management
  • Architecture Design
  • Implementation
  • Measurement

8
Project Management Spring Semester Tasks
Spring 2005
Jan
Feb
Mar
Apr
May
Team Building
Implementation Plan for Summer
Test Plan
Management Document Update
Management
TSP Study
Architecture Inspection
SRE Seminar
Design Review
ATAM Seminar
QAW
Architectural Design
Detailed Design Document
Design
Architectural Design
Jflex JavaCC Seminar
Semantic Analyzer
Lexical Analyzer
Symbol Table
Testing
1st Iteration
Syntax Analyzer
Code Generator
MOSP
EOSP
Start
Deliverables
Modified Task
Planned Task
Delayed Task
Unplanned Task
Management Project, Risk, Configuration, Quality
QAW Quality Attribute Workshop
9
Risk Management SRE
  • Risk Elicitation
  • Mini SRE with Gil Taran
  • 14 Risks are elicited
  • Multi voting for prioritization
  • Three Top Risks

Making the translation program converting TTCN
BNF to source code for JavaCC
10
Architecture Design Drivers
  • Functional Requirements
  • TestGen shall accept TTCN-MP test case and
    generate an test suite written in ANSI C
  • Quality Attributes
  • Usability TestGen shall produce ANSI C code that
    can be understood and modified by a test engineer
  • Modifiability TestGen shall be extensible to
    satisfy test cases in a variety of protocols in
    the future
  • Constraint
  • TestGen shall be executable on a personal
    computer
  • TestGen shall be able to run on MS-Windows

11
Architecture Design Utility Tree Scenario
  • Usability, Modifiability, Performance

I Importance D Difficulty
12
Architecture Design C C View (Data-Shared
Style)
TestGen System
13
Architecture Design Sequence Diagram
TestGen System
Semantic
Parser
Main Controller
Code_Gen
Tree
Symbol
C_code
TTCN-MP
Test Engineer
START
1. Parsing
2. Read test case file
3. File data
4. Generate symbols
5. Generate abstract syntax tree
6. Return control
7. Check Semantic
8. Check symbols
9. Symbols
10. Generate decorated tree
11. Return control
12. Generate C code
13. Get tree
14. Tree data
15. Generate C code
16. Return control
END
14
Architecture Design Module View (Decomposition
S.)
Parser
SymbolTable
ParseException
SymTab
SymTabEntry
ltltinterfacegtgt TtcnTreeConstants
TypeEntry
VariableEntry
TtcnParser
ltltinterfacegtgt TtcnConstants
VariableTable
TypeTable
Semantic
TtcnTolkenManager
Token
Semantic Main
Definition NodeAnalyzer
SimpleCharStream
TokenMgrError
Semantic Error
Expression NodeAnalyzer
TestGen
ltltinterfacegtgt Semantic Visitor
CodeGenerator
Statement NodeAnalyzer
CodeMain
CodeFormatter
Tree
OverviewGenerator
LogGenerator
ASTActualPar
ltltinterfacegtgt Node
DeclarationGenerator
TransRules
ASTAttach

ConstraintGenerator
ltltinterfacegtgt TtcnParseVisitor
SimpleNode
ASTValue
DynamicGenerator
ASTTtcnSpec
15
Architecture Design Code_Gen (Alternatives
Analysis)
Rule Manager
Rule_Data
Managing mapping rules between TTCN Specification
and C code
Rule_Mgr
Overview
Modifiability, Usability
Declaration
Code_Main
Code_Format
Constraint
Code Formatter
Dynamic
Beautifying the C code for a test engineer to
understand easily
Modifiability, Usability
16
Implementation Creating a Skeletal System
Generated by JavaCC
Skeletal System
17
Implementation Status of Skeletal System
  • A skeletal system was created based on the
    architecture
  • TestGen system will be developed incrementally
    based on the skeletal system
  • Parser
  • Developed by JavaCC
  • Create JavaCC input file which specifies tokens
    grammars
  • tcnParser.jjt 4400 LOC
  • Generated code by JavaCC 30045 LOC
  • Coding completed, not fully tested
  • Semantic Analyzer (status class design
    completed)
  • 5 classes designed
  • Code Generator (status dynamic part implemented)
  • The most important component in our system
  • 3098 LOC are created

18
Analysis Reverse Engineering
options SANITY_CHECKtrue DEBUG_PARSERfalse D
EBUG_TOKEN_MANAGERfalse LOOKAHEAD2 MULTI
true VISITORtrue NODE_DEFAULT_VOID
true NODE_PACKAGE "parser" PARSER_BEGIN(Ttc
nParser) package parser import
java.util. public class TtcnParser
public static void main(String args) throws
ParseException TtcnParser parser
parser new TtcnParser(System.in) try
ASTTestCase n parser.TestCase()
TtcnParserVisitor v new DynamicGen()
n.jjtAccept(v,null) System.err.println("T
TCN-MP file processed successfully.")
catch(ParseException e)
System.out.println(e.toString())
PARSER_END(TtcnParser)
19
Metrics
Metrics
Result
Category
Product
Defect density Defects / KLOD Software
Architecture Document 270 lines were reviewed
8 major defects were discovered
29.6 Defects / KLOD
Process
Process Compliance given grades / total grades
Project Management (4/6) Risk Management
(3/3) Development Process (2/3) Quality
Assurance (6/6) Configuration Management(7/9)
81
Project
Schedule Deviation actual time / planned
time SeonAh Lee (249.9) ChangSup Keum (236.7)
JungHo Kim (163.3) ShinYoung Ahn
(191.0) Actual time (840.9) Planned time (16
12 4 768)
110
20
Effort Measurement
  • Time spent this semester 841 hours

21
IV. Lesson Learned
  • What is Good So Far
  • What Could Go Better

22
What is Good So Far
  • QAW
  • We wrote and prioritized the quality attribute
    scenarios
  • We refined scenarios after QAW session
  • We should had finished the QAW before starting
    architecture design
  • ATAM
  • We finalized the architectural design and elicit
    sensitivities, tradeoffs, and risks
  • We refined the architecture and gathered more
    risks in ATAM
  • ATAM is useful to clarify the customers
    expectations regarding the output of the our
    system.

23
What is Good So Far
  • SRE
  • We identified the risks and evaluating the risks
    more systematically
  • Detailed Task Plan
  • Plan manager notified the detail progress to team
    member
  • Skeletal System
  • It can check the architectural structure
  • It provided the base information for
    implementation plan
  • Reverse Engineering of Skeletal System
  • It was good for knowledge transfer

24
What Could Go Better
  • Process
  • We used famous processes without selection
    criteria
  • We just pursued famous processes in selecting a
    process
  • Selection criteria was not based on team goals
  • Process was changed this semester
  • ACDM was chosen because it is well fit into our
    team goal
  • ACDM is quite similar to our as-is process
  • We will keep the ACDM next semester

25
What Could Go Better
  • Analysis before Decision
  • We did not capture the characteristics, advantage
    and disadvantage
  • We did not find alternatives, comparing two
    candidates
  • We did not valuate the usefulness based on our
    goals
  • Active Discussion and Communication
  • We believed that frequent meeting was
    unproductive
  • Experts knowledge did not propagate well
  • We sometimes missed the best way that could be
    resulted from discussion

26
IV. Future Work
  • Implementation Test Plan
  • Plan Summary

27
Implementation Test plan
CG Code Generator
1st week
2nd week
3rd week
4th week
5th week
6th week
7th week
8th week
9th week
10th week
11th week
12th week
Implement
CG Dynamic Part V1
CG Dynamic Part V2
CG Declaration Part
CG Constraint Part
CG Overview Part
Semantic Analyzer
Lexical/Syntactic
Adaptive Library
Test
Define Test Criteria
Create Test Suite
Unit Test V1
Unit Test V2
Integration test
Acceptance test
Kick-Off
Finalize Test Criteria
MOSP
Milestone
Complete Integration test
EOSP
28
Plan Summary
  • Implementation
  • This is based on the skeletal system
  • Two iterations
  • Iteration I Basic functions
  • Iteration II Advanced functions
  • Test
  • Acceptance test criteria should be defined with
    client
  • Unit test Integration Test
  • Acceptance Test
  • Acceptance Test 1st (7/25)
  • Acceptance Test 2nd (8/1)
  • Acceptance Test 3rd (8/3)

29
Questions
?
30

Thank You !
