Title: Aggregated IP FEC <draft-swallow-mpls-aggregated-FEC-00.txt> swallow@cisco.com


1
Aggregated IP FECltdraft-swallow-mpls-aggregated-F
EC-00.txtgtswallow_at_cisco.com
2
Aggregated IP FEC
  • Problem MPLS requires PE to PE LSPs for PWE3 and
    VPN traffic
  • Routes cannot be aggregated
  • All routers have routes and LDP labels for all PE
  • draft-ietf-mpls-ldp-interarea-00.txt also deals
    with this problem

3
Aggregated-IPv4 FEC
  • New FEC Type
  • Semantics are the same as an IPv4 FEC except
  • Indication that the next label is a
    De-aggregation Label indicating a specific (/32)
    IP route
  • The de-aggregation label is to be interpreted in
    a context particular to this FEC
  • The de-aggregation labels are determined
    algorithmically

4
De-aggregation Labels
  • A de-aggregation label is derived as follows
  • AND the IP address with a 32 bit mask where the
    bits in the summary route are set to zeros and
    the low order bits are set to ones
  • Add 16 (to bypass reserved range)
  • Supports a /13 or longer prefix
  • Algorithmic derivation ensures that all ABRs
    advertising an Aggregated IP FEC have the same
    deaggregation labels

5
Label Distribution
  • A router which is summarizing IP routes may
    advertise an Aggregated-IPv4 FEC
  • The label must be non-null (no PHP)
  • Aggregated-IPv4 FECs must be distributed in
    downstream ordered mode

6
ILM for De-aggregation labels
  • For each aggregated-IPv4 there is a unique
    Incoming Label map (ILM)
  • The entries of the ILM must point to a next hop
    label forwarding entry which is one of
  • An IPv4/32 FEC
  • Another (more specific) aggregated-IPv4 FEC
    stacked upon a de-aggregation label

7
Routing Summarization Label Distribution (1)
10.10.0.1
10.10.0.2
10.10.1.1
10.10.2.2
  • Within Area 2 labels are distributed for IPv4/32
    routes
  • ABR2 advertises 10.10.2/24 into Area 0
  • ABR1 advertises 10.10.2/24 into Area 1
  • ABR2 selects a label for 10.10.2/24 and
    distributes it in LDP as a Aggregated-IPv4 FEC

8
Routing Summarization Label Distribution (2)
10.10.0.1
10.10.0.2
10.10.1.1
10.10.2.2
  • LDP propagates the Aggregated-IPv4 FEC throughout
    areas which have the route 10.10.2/24
  • ABR2 builds an ILM to be used in the context of a
    received label indicating Aggregated-IPv4 FEC
    10.10.2/24
  • For each /32 route covered by Aggregated-IPv4 FEC
    10.10.2/24 that has a label binding, ABR2
    algorithmically maps a label entry

9
Label OperationsL3-VPN Imposition
VPN Addr 192.169.0.22 Next Hop 10.10.2.2 Label
Stk 47
Aggregated- IPv4 FEC 10.10.2/24 Label 51
10.10.2.2
10.10.0.2
10.10.0.1
10.10.1.1
  • Sending to VPN Route 192.169.0.22, PE1 pushes VPN
    label 47
  • Selects Aggregated-IPv4 FEC 10.10.2/24 as longest
    match FEC matching BGP-NH
  • Algorithmically derives De-aggregation label 18
    and pushes onto stack
  • Push LDP label (11) for aggregated-IPv4 FEC
    received from IGP next hop

10
Label OperationsPop Swap at ABR2
VPN Addr 192.169.0.22 Next Hop 10.10.2.2 Label
Stk 47
Aggregated- IPv4 FEC 10.10.2/24 Label 51
10.10.2.2
10.10.0.2
10.10.0.1
10.10.1.1
36
47
47
  • ABR2 receives packet label stack 51/18/47
  • ABR2 pops label 51 and locates the indicated
    label space
  • ABR2 looks up label 18 and maps it to a label
    (36) received for the IPv4 FEC 10.10.2.2
  • Label processing from this point is exactly as
    current L3VPNs

11
Draw Backs
  • Requires processing two labels at ABR
  • There will be a performance penalty on some
    platforms
  • Others will take it in stride
  • Looses Next-Hop tracking
  • Were looking into ways of fixing that
  • Expect to have something for Vancouver

12
Benefits
  • Greatly reduces label distribution
  • LDP distributed host specific labels are only
    needed within the area of the destination PE
  • Conserves LFIB space
  • Note that PEs imposing these labels need not put
    them into the LFIB
  • Keeps LDP distributed labels coordinated with the
    IGP
