GIS: An Integrated Solution Toward Meeting Oceanographic Data Challenges

1
ESRI Marine Data model Meeting the needs of the
coastal and marine GIS community
2
Objectives

• Overview of ESRI Marine Data Model
• Goals of ESRI 2002 Marine GIS Development
• Marine GIS user community needs?
• Discussion on Review of model and case studies

3
Purpose of Marine GIS data modelTo Provide a
framework for Marine GIS users to store, query
and analyze dataTo promote networking and data
sharing among Marine GIS User through
standardizationTo encourage the development of
tools for the marine GIS user community
4
Coordinated collection of scientific
data Geological, chemical,
biological, and physical High level
analyses of the processes interactions
A single integrated marine data modelwith
theme-based sub-models
5
Identifying marine data and parameters
Bathymetry Marine boundaries Coastlines Geophysic
al time Sub-bottom profiling Sidescan
sonar Magnetics Gravity Seismics Atmoshpheric
influences Sea state Sea surface
Temperature Salinity Sensor calibration
data Current meters Density Sediment
transport Wave activity
6
Defining marine elements
Images Locations of observations Submersible
ROV Tracklines Navigation points New
developments in data collection vehicles,
satellites, and methods
7
Marine Data Collection
Rutgers U. Coastal Ocean Observation Lab,
http//marine.rutgers.edu/cool/
8
New Data Types Integration of data
Standardization Availability
Examples and Case Studies
9
(No Transcript)
10
(No Transcript)
11
Planimetric View of Monterey Bay Bathymetric data
12
3D Scene of Monterey Bathymetry
13
3D Scene of Monterey Bay with known faults
14
Three and four Dimensional Analysis
Maximizing the use of available tools Making
placeholders for 3D data in the model
15
Marine Data model review and testing
Coastlines and Sea Level Change Raster layers
with adjusted base heights
16
(No Transcript)
17

• Representing dynamic marine data
• Feature locations change
• Multiple time variable data
• A dynamic and multivariable coastline

• Time duration areas
• Instantaneous points with multiple z values
• Tracking marine animal movement
• Bathymetrical layers

18
(No Transcript)
19
(No Transcript)
20
Continuing Initiatives

People Partners, end users
Lucas, A., 2000. Representation of variability in
marine environmental data, in Wright Bartlett
(eds.), Marine and Coastal Geographical
Information Systems, London Taylor Francis,
pp. 53-74.
21
The Future?

• Volumetric Data Model Refinement
• Marine GIS Development
• 3 and 4-D Data Access and Viewing
• Ideas and Questions

CONTACT US! Joe Breman ltjbreman_at_esri.comgt
