DOBES Workflow

1
DOBES Workflow

• Paul Trilsbeek
• DOBES training week
• June 2007

2
Archiving workflow
The sequence of actions that are required to get
a piece of recorded material into the archive.
3
Video workflow (MPI)
Recording
Capturing (DV)
Transcoding (MPEG1 2, WAV)
DMF
Sessions
Cutting (MPEG1 2, WAV)
Transcribing/ Annotating
Metadata
Archiving
4
Video workflow (alternative)
Recording
Capturing (DV)
Cutting (DV)
Sessions
Transcoding (MPEG1 2, WAV)
Transcribing/Annotating Metadata creation
Archiving
5
Workflow People involved

• DOBES teams (you)
• DOBES Corpus Manager (me)
• MPI Digiteam (Nick Wood, Bas Roset)

6
Digital Master File (DMF)

• The MPI Digiteam captures every tape they receive
  entirely. We call this entire recording the
  Digital Master File or DMF.
• Based on this DMF, the DOBES team can determine
  the time codes of those parts that they want to
  archive, the so-called Sessions.

7
Specifying Sessions

• A Session in terms of the IMDI corpus is a
  resource bundle, generally a piece of video or
  audio (in several formats) accompanied by an
  annotation file and optionally some other
  information files.
• When we talk about Sessions in relation to
  cutting media, we mean the piece of audio or
  video that you would want to archive in the
  corpus as one linguistically meaningful unit
  (one interview, one story, one song, )

8
Specifying Sessions

• Audio and Video Sessions can also consist of
  several fragments merged together to one file.
• In order to cut or put together these Sessions,
  the Archive needs to receive an IMDI file with
  the exact time code specifications based on the
  Digital Master File (DMF).

9
Video workflow Who does what?
What part of the workflow can be done by who?
10
Video workflow Who does what?

• 3 common scenarios
• all capturing, transcoding and cutting done by
  the MPI Digiteam.
• first version in MPEG1 done by the DOBES team (in
  the field), MPEG2 version done by the MPI
  Digiteam.
• all capturing, transcoding and cutting done by
  the DOBES team.

11
Video workflow Scenario 1

• the DOBES team sends tapes to the DOBES Archive.
• the MPI Digiteam captures the tapes and sends
  entire captured files (DMF) to the DOBES team.
• the DOBES team determines timecodes for the
  sections that need to be cut (Sessions) and sends
  these in IMDI metadata files to the Corpus
  Manager.
• the MPI Digiteam cuts Sessions and sends them to
  the DOBES team.

12
Video workflow Scenario 1

• advantage less work for the DOBES team.
• disadvantage the DOBES team has to wait for
  DMFs and Sessions to be sent by the MPI Digiteam.

13
Video workflow Scenario 2

• the DOBES team does the capturing, cutting, and
  transcoding process in the field to create MPEG1,
  writing down all time codes while capturing and
  cutting.
• after returning, the DOBES team sends the tapes
  and all time code information in IMDI files to
  the DOBES Archive.
• the MPI Digiteam creates MPEG2, MPEG1 and WAV
  versions for archiving with exactly the same time
  codes.

14
Video workflow Scenario 2

• advantages the DOBES team can already start
  working with the media right away in the field.
• disadvantages more work to be done in the field
  not all field circumstances may allow for this
  scenario time code administration during the
  whole process is very important

15
Video workflow Scenario 3

• the DOBES team does whole capturing, transcoding
  and cutting process and sends final Sessions in
  MPEG2, MPEG1 and WAV (according to MPI
  specifications) with IMDI metadata to the DOBES
  Archive, or uploads them to the Archive using
  LAMUS.

16
Video workflow Scenario 3

• Advantages the DOBES team can already start
  working with the media right away.
• Disadvantages all the work has to be done by the
  DOBES team higher chance of errors during the
  whole process not all field circumstances may
  allow for this scenario.

17
Video workflow general

• Every team has different field circumstances and
  requirements, a suitable workflow scenario should
  be agreed upon between the Corpus Manger and each
  team.
• When doing parts yourself, send examples and
  communicate with the Corpus Manger in an early
  stage, instead of processing a large batch of
  tapes and discovering that something is wrong in
  the end.

18
Video workflow general

• continuous time code on a video tape (no gaps or
  jumps) prevents problems during capturing use
  the end search or equivalent function on your
  camera before recording a new scene and do not
  re-use tapes.
• do not use long play mode and 12-bit sound on DV
  cameras.

19
Video workflow general

• there are hundreds of settings for MPEG encoding
  and different encoders have different qualities
  use tools recommended by the MPI and settings
  files provided by the MPI.

20
Audio workflow

• For tape or disc based recorders workflow is
  similar to video workflow, only no transcoding
  needed (linear PCM WAV is the archiving format).
• Flash memory based recorders no capturing
  needed. Files can be copied directly to the
  computer, after which the Sessions can be cut.
• HiMD recorders files can be copied to the
  computer using SonicStage software.

21
Audio workflow

• HiMD Flash recorders use Linear PCM recording
  mode, no compressed audio (mp3 / ATRAC).

22
Tape labeling

• When sending tapes to the MPI, always label them
  using the DOBES tape labeling conventions (see A4
  guide) with a unique code for your project (talk
  to corpus manager), e.g. AWSDVDP24Jun0301 stands
  for Aweti, Sebastian Drude, Video, DV, PAL,
  recorded on the 24th of June 2003, tape number
  01.
• Label the tape itself, not (only) the box.

23
Time codes

• Please use the correct forms when writing down
  timecodes
• For video sources HHMMSSFF (hours, minutes,
  seconds, frames). Frames are the smallest
  possible step within a video file. PAL video has
  25 frames in one second, NTSC has 30 (or 29.97).
• For audio sources HHMMSSSSS (hours, minutes,
  seconds, milliseconds).
• Even if you dont need this degree of accuracy,
  fill in the remaining digits with zeros. (e.g.
  011458000).

24
Specifying time codes in IMDI

• Specify Session start and end time codes in
  ResourcesSource.
• For merged fragments, specify multipe sources.
  Specify the order in which they should be merged
  in a Description field.
• For merged fragments from one source, specify the
  source multiple times with different time codes.
  Specify the order in which they should be merged
  in a Description field.

25
Specifying time codes in IMDI
26
Further workflow

• after IMDI Metadata descriptions and media
  Sessions are ready, this material can already be
  archived. This can be done by the DOBES Corpus
  Manager, or by the DOBES team itself, using
  LAMUS.
• Annotations for the Sessions can be uploaded
  using LAMUS in a later stage.

27
Conclusions

• There is not one definite workflow, one will
  have to be worked out and agreed upon for between
  every project and the Corpus Manager.
• As technology advances, more and more can be done
  directly in the field. Flash memory and hard disk
  recording devices will simplify the workflow
  significantly.
