SAND EXTRUDITES: A NEW STYLE OF

1
SAND EXTRUDITES A NEW STYLE OF STRATIGRAPHIC
TRAP THEIR SIGNIFICANCE IN BASIN ANALYSIS
ANDREW HURST University Aberdeen, Dept. Geology
Petroleum Geology MADS HUUSE, MARIO VIGORITO,
DAVIDE DURANTI, JOE CARTWRIGHT
2
A SAND EXTRUDITE
3
SAND EXTRUDITES

• HOW ARE THEY RECOGNISED
• ARE THEY SIGNIFICANT RESERVOIRS
• HOW DO THEY FORM / ROLE IN BASIN EVOLUTION
• PROSPECTIVITY

4
SAND EXTRUDITES RECOGNITION
650m
TIME SLICE EOCENE, MORAY FIRTH
5
SAND EXTRUDITES RECOGNITION
Outer Moray Firth, Eocene
6
SAND EXTRUDITES RECOGNITION

• BEDDING CONCORDANT
• LOW RELIEF
• LATERALLY DISCONTINUOUS ??
• FED BY SAND INJECTITES

7
SAND EXTRUDITES RECOGNITION
VOLUND FIELD PRE-DISCOVERY
8
RECOGNITION NOT SAND EXTRUDITES
24/9-7B
Seismic (near offset amplitude data) through
wells N24/9-7B, 24/9-7 and 24/9-6 pink horizon
is top Balder Formation, red and blue horizons
are top and base of injection complex.
9
RECOGNITION NOT SAND EXTRUDITES
VOLUND FIELD, MARATHON/ LUNDIN
courtesy of Ewa Szarawarska
10
ARE THEY SIGNIFICANT RESERVOIRS
THE ABSENCE OF MIND MODELS !!
USE OF OUTCROP ANALOGUES TO CREATE NEW MODELS FOR
STRATIGRAPHIC TRAPS
11
ARE THEY SIGNIFICANT RESERVOIRS
MIOCENE SAND EXTRUDITES, N MONTEREY
BAY METRE-SCALE SAND EXTRUDITES
12
ARE THEY SIGNIFICANT RESERVOIRS
RED, WHITE BLUE BEACH, SANTA CRUZ
13
TAR-STAINED, BEDDED SANDSTONE, 1.5-3.5 M
THICK RED, WHITE BLUE BEACH, SANTA CRUZ
ARE THEY SIGNIFICANT RESERVOIRS
14
IDENITIFICATION OF RESERVOIR-SCALE FEATURES
HIGHLY DISRUPTED BASE, LOCALLY CONCORDANT TAR
SATURATED FED BY HIGH- LOW-ANGLE DYKES -
DIVERSE INTERNAL STRUCTURES BIOSILICEOUS UPPER
UNIT WITH CONCORDANT TOP
15
SUSTAINED FLOW _at_ ca. 0.4-0.6 ms-1 FROM
WNW COINCIDENT WITH HIGHLY DISRUPTED SEAFLOOR
16
ARE THEY SIGNIFICANT RESERVOIRS
17

• VENT DYKE IS PART OF A LINNEAR FRACTURE
• LOW-ANGLE LAMINAE/THIN BEDS PREDOMINATE
• BURROWS COMMON NEAR TOP

ASSOCIATION WITH SAND INJECTITES
18
LOCALLY BRECCIATED VENT AREA
19
ARE THEY SIGNIFICANT RESERVOIRS MULTIPLE
EXTRUSIONS
20
ARE THEY SIGNIFICANT RESERVOIRS AREAL
EXTENT Panoche Giant Injection Complex, U.
Cret-Paleocene, Great Valley, CA
21
ARE THEY SIGNIFICANT RESERVOIRS AREAL
EXTENT Panoche Giant Injection Complex, U.
Cret-Paleocene, Great Valley, CA
Cretaceous Marine Deposits
PGIC
Palaeocene-Miocene Marine Deposits
500 km2 of outcrop extrudite up to 15 m thick
22
ARE THEY SIGNIFICANT RESERVOIRS SUMMARY IN
DEEP-WATER CLASTIC SYSTEMS
BEDDING CONCORDANT LATERALLY EXTENSIVE MAY BE
STACKED UP TO 15 m THICK FED BY DYKES
ASSOCIATION WITH INJECTITES OVERALL FU BUT EVEN
GRAIN-SIZE DISTRIBUTION Internal
Structures LOW-ANGLE BEDDING (RADIAL CURRENT
FLOW), BURROWED, SOME X-BEDDING, SLUMPING,
MUD INTRACLASTS
23
SUDDEN RELEASE OF OVERPRESSURE AT DEPTH SEAL
FAILURE SAND FLUIDISATION PRESSURE
EQUILIBRATION LARGE EXTRUDITES REQUUIRE LARGE
AQUIFERS MINS/DAYS
24
HOW DO THEY FORM ROLE IN BASIN EVOLUTION
A MODERN TERRESTRIAL EXAMPLE OF SAND
EXTRUSION FROM WATSONVILLE, CA SAN ANDREAS
FAULT ZONE
PRESERVATION POTENTIAL IS DEPENDENT
ON SEAFLOOR/SURFACE CONDITIONS NO REWORKING
25
HOW DO THEY FORM BASIN EVOLUTION
26

27
SAND EXTRUDITES PROSPECTIVITY HIGH LATERAL
CONTINUITY SEISMICALLY RESOLVABLE
PERFECT STRATIGRAPHIC TRAPS ON MIGRATION
ROUTES OCCURRENCE OF SAND INJECTITES A
PRE-REQUISITE PERIODS OF OVERPRESSURE DURING
SHALLOW BURIAL LARGE AQUIFER VOLUME - SEISMICITY
(RAPIDITY) PARENT SANDS WITHIN THE SHALLOW
SECTION FOCUS ZONES/AREAS FOR SUBSURFACE
FLOW FACIES TECTONIC SETTING INDEPENDENT
28
CORRELATING CORRECTLY
29
CONCLUSIONS SAND EXTRUDITES
PERFECT STRATIGRAPHIC TRAPS WIDELY DEVELOPED,
RARELY RECOGNISED UNRECOGNISED IN
CORES SIGNIFICANT VOLUMES LARGE AREA,
THIN SIGNIFICANT TIME LINES RECORD PERIODS OF
SHALLOW OVERPRESSURE AN UNTESTED PLAY CONCEPT
