Corporate Presentation

1
Corporate Presentation

• March 2004

2
Agenda

• About Optimal Corporation
• Mission Statement
• Design Challenges
• Optimal Solutions
• Customer Commitment
• Summary

3
About Optimal Corporation

• Founded 1995, 24 employees
• Technology driven, first products 2000
• Headquarters San Jose, California
• Sales offices Taipei, Taiwan and Shin-Yokohama,
  Japan
• World-class management team and BOD

4
Optimal Mission
To provide industry-leading, innovative Signal
Integrity solutions for high-speed IC, Package
and PCB designs
5
Todays IC/Package Design Challenges

• At 0.15um and below, chip complexity skyrockets
• Integration
• Logic and memory
• Analog and digital
• Phase lock loop control essential
• Operating frequencies soar
• On chip speeds to 15 GHz
• I/O speeds to 3 GHz
• Signal Power Integrity A major challenge
• Chip designer must anticipate system issues
• Chip ? Package ? PCB ? System
• No integrated tools to meet the above SI/PI
  challenges

Optimal A comprehensive solution
6
Optimal Solutions

• Optimal provides the first-ever complete signal
  integrity design flow solution from IC to Package
  to PCB

7
Optimal Solutions

• PakSi
• Advanced 3D simulation and analysis tools
• Electrical, Thermal-Mechanical, Solder Joint
  Fatigue
• O-Wave
• Advanced 3D full-wave simulation, extraction and
  analysis tools
• SIDEA
• A one-stop shop of Signal Integrity Design
  Assistants
• PowerGrid
• DC and high frequency Power Integrity tool
  dealing with IR drop and ground bounce noise

Optimal Stability, Accuracy, Performance
8
PakSi E3D Quasi-Static Simulation, Extraction
Analysis

• Unique quasi-static FEM solver capable of whole
  package extraction including power and ground
  planes

9
PakSi TM, PakSi SJFAdvanced 3D
Thermal-Mechanical Analysis

• A complete thermal/mechanical/solder joint
  fatigue simulation tool from package to PCB

10
O-Wave Innovative Technologies

• The only FEM solver to use the state-of-the-art
  Multi-Grid AV preconditioning technique
• Uses the latest Krylov adaptive frequency
  expansion algorithm

S Parameters
O-Wave High Performance, Precision Accuracy
11
Accurate, Speedy and Memory Efficient

• O-Wave solves large cases with efficiency,
  precision accuracy AND has significantly smaller
  memory requirement

12
How do we know the simulated or
measuredS-parameters are correct?

• SIDEA WB Convert corrects passivity errors in
  simulated or measured data

Criterion Eigenvalues of Re(Y)gt0
13
PowerGrid

• Fast IR drop (DC) and ground bounce (AC)
  simulators for package and PCB power integrity
  analysis

14
Efficiency and Ease of Use
From CAD database to SI analysis in one
continuous flow
8 programs in one place
15
Optimal Product Families

• Unified engines for all products
• Optimal Signal Integrity

Signal Power Integrity
PakSi
O-Wave
SIDEA
Power Grid
Solver Engines (Quasi-Static, Full-Wave)
16
Integrated Design Flow

• Most advanced full-wave solver engine available
  today
• Homogeneous approach

Signal Power Integrity
IC
Package
PCB
System
Solver Engines
17
Customer Commitment

• Stability
• Extensive QA cycles prior to releases for total
  customer satisfaction
• Accuracy
• Simulated results compare well with known
  solutions or measurements
• Performance
• Innovative algorithms to reduce design cycle time
  and improve time to market
• Ease-of-use
• Fully-automated turn-key solutions designed for
  both senior and junior engineers alike

18
Customer Testimonials

• We, at Intel, are impressed with the accuracy of
  the PakSi-E software. PakSi is a very fast
  simulator and is much faster than its
  competitors.
• Ilya Gurevich, Assembly Process Development
  Engineer, Intel Corporation
• We, at Agere, use Optimals PakSi-E software for
  complete package parasitic extraction of all
  designs including very high pin count. Weve
  designated Pak-Si-E as our current tool in the
  design flow for full package parasitic
  extraction.
• Ramani Tatikola, Ph.D., Member of Technical
  Staff, Agere Systems
• We have successfully matched PakSi-E's simulated
  data to actual TDR-measured data within 95
  correlation. Add into the mix the company's
  history of top-notch customer support, we were
  immediately sold on the product.
• Daniel Kim, Senior Electrical Characterization
  Package Engineer, Xilinx, Inc.
