Digital

1

• Digital
• Paging
• Microphone

For use in Paging and Evacuation System
2
Digital Paging Microphone

• Not just a paging system!

• Designed as an AUTOMATION TOOL
• with high security requirements
• (EN60849)

• Built to perform in the
• most difficult environments

• All push buttons are programmable
• with configuration software

3
Digital Paging system
ARJ - 3

• All units are connected in a
• bus-topology network

• The system is programmable with
• the configuration tool

ARJ - 3

• Up to 200 units

ARJ - 3
ARJ - 3
AUDAC DATABUS
4
Digital Paging System

• Swiching Line Level

ARJ - 3
Music Source
Power Amps
ARJ - 3

• Different amplifier for
• Each zone

ARJ - 3
100V Line
ARJ - 3
AUDAC DATABUS
AUDIO (Line Level)
AUDIO (100V LINE)
5
Digital Paging System

• Switching 100V

• using 2 amps
• 1 for music
• 1 for paging

ARJ - 3
Music Source
Power Amps
ARJ - 3
Music Source
ARJ - 3
100V Line
100V Line
ARJ - 3
AUDAC DATABUS
AUDIO (Line Level)
AUDIO (100V LINE)
6
Digital Paging System

• Control
• Other devices

ARJ - 3
Music Source
ARJ - 3
Power Amps
Window Blinds
ARJ - 3
Music Source
100V Line
Electrical Door Contact
ARJ - 3
AUDAC DATABUS
AUDIO (Line Level)
AUDIO (100V LINE)
Other Devices
Volume Control (E.C.)
100V Line
7
APM - Paging Microphone
APM 01
APM 04
APM 08
APM 16
Custom Build APM

• Freely programmable control and paging microphone

• Gives a warning by failure

• A led indicator gives you the
• microphone status level low, normal, high

• Led for warning that another user with higher
• priority is busy on the bus

• Different switch functions Zoneselection,
• Toggle on/off, Push and hold, Power up delay

8
ARU Relay unit
ARU 16
ARU 04
ARU 08

• These are actor units with features that allow
• Switching and routing possibilities

• Delay switching to start amplifier rack

• Switching from line level to 100 volt speakers

• All contacts of the onboard relays are available
• on the connectors, to give you the freedom to

• create all your personal requirements

9
AVD Voltage distributor
AVD 16
AVD 04
AVD 08

• Simple version of the ARU

• Has the most features of a ARU, but is
• different in the connections.

• Used for distributing simple routing,
• like 24 volt to activate volume-controls,
• or simple speaker-line distribution

10
ARJ RJ45 Junction Box
ARJ - 3
This junction box with data bus input, data
bus output and link to the APM unit gives you
the possibility to link from one APM to the
other without having 2 data cables coming direct
to the APM unit
11
Audac Configuration Manager

• Custom configuration tool

• Freely available software (www.audac.be)

• an RS-485 adapter allows you to connect your PC
• to the AUDAC databus

• Designed according to the Wizard principal,
• so that none of the steps can be overlooked
• during configuration

• Documentation possibility

12
Audac Paging System

• Simple in use

• efficient

• Flexible and versatile

• A complete paging system to fulfil all your
• Paging needs

• Especially designed for use in dispatch and
• evacuation installations

• User friendly, estethic, reliable
• and good functionality
