Fracture Control of Steel Structures 2003

1
Fatigue Crack Propagation
Fracture Control of Steel Structures 2003
Chitoshi Miki
Lecture 6
2
The Significance of Discussions on The Crack
Propagation
The life of structural components may be governed
by the sub-critical crack propagation.
3
1. Crack Propagation Tests
CT
CCT
4
1. Crack Propagation Tests
CT
5
Crack Size-Number of Load Cycles
?s3
?s2
?s1
Crack Length, a
For the same length
Number of Cycles, N
6
Crack Size-Number of Load Cycles
l3
l2
l1
Crack Length, a
?s
For the same
l3
gtl2
gtl1
Number of Cycles, N
7
Application of Stress Intensity Factor Range, ?K
Log (da/dN)
by Paris and Erdogan
Log ?K
8
Plastic Zone Development at Crack Tip
?
9
Plastic Zone Development at Crack Tip
?
10
Plastic Zone Development at Crack Tip
11
Crack Propagation Threshold, ?Kth
Log (da/dN)
Log ?Kth
Log ?K
12
Effective Stress Range, ?seff
R0.5
R0
R-1.0
?seff
smax
s
seff
Crack Closure
smin
Time
?K
13
Effective Stress Intensity Factor Range, ?Keff
K
Log (da/dN)
Kmax
?Keff
Crack Closure
Kop
Kmin
Time
Log ?Keff
14
Fatigue Crack Closure
Plasticity-induced Closure
Roughness-induced Closure
Oxide-induced Closure
No Closure Welded Joints because of tensile
residual stress
15
Variation of Fatigue Crack Growth
16
Fatigue Striations
Constant Loading
TEM
SEM
Random Loading
TEM
17
Ductile and Brittle Striations
Ductile Striations
TEM
Brittle Striations
TEM
18
Change of Fracture Surface Appearance
19
2. da/dN-K for Fatigue Propagation Life
Prediction
Fatigue Propagation Life
Initial Crack Size
Final Crack Size
20
Fatigue Propagation Life Prediction
JSSC
C
m
?Kth
Conservative
Mean
OK
Conservative Estimation
