1Formal Methods
2Why formal methods?
- Informal methods are open to interpretation and
ambiguity, and often incomplete and inconsistent. - Formal methods have some basis in mathematics and
allow us to reason about the system we are
building. - They help us accurately capture our intent so
that it is precise and clear to others. - There are lots of different formal methods.
- Like programming languages, each formal methods
has strengths and weaknesses. - Like programming languages, some formal methods
are tailored to a specific problem domain, e.g.,
real-time systems requiring a discussion of
temporal semantics. - Formal methods are used to specify aspects of the
software system behavior, data relationship,
temporal semantics
3Why arent they used everywhere?
- Formal methods are controversial. Their advocates
claim that they can revolutionize software
development. Their detractors think that they are
impossibly difficult. Meanwhile, for most people,
formal methods are so unfamiliar that it is
difficult to judge the competing claims.
Anthony Hall, 1990. - We will gain an appreciation of formal methods
over the next few lectures to understand their
impact on software engineering in the years to
come.
4Formal methods - limitations
- Formal methods have not become mainstream
software development techniques as once
predicted. - Other SE techniques have been successful at
increasing software quality, so the need to
formalism has decreased. - Economic pressures make time-to-market a key
driver, rather than a low error count. Formal
methods do not reduce time to market. - Formal methods are had to scale to large software
systems. - Scope of formal methods is limited not well
suited to specifying and analyzing user
interfaces and user interactions. - Formal methods have limited practical
applicability.. - Principle benefit is reduction in number of
errors. Main area of applicability is critical
systems.
5Deficiencies of informal methods
- Natural language (English) is an example of an
informal method. - It is often ambiguous, incomplete, insufficient,
and contains contradictions and mixed levels of
abstractions. - We often try to address these deficiencies by
supplementing the natural language description
with diagrams. - These diagrams often lack structure and have
similar deficiencies to natural language. - Coupled with sloppiness in analysis and design,
poor attention to detail and the lack of thorough
reviews, the use of informal methods can lead to
a software disaster.
6Problems
- Contradiction sets of statements that are in
variance with each other. They are often written
by different people and separated by many pages
in the specification. They are therefore
difficult to detect. - Ambiguity statements that can be interpreted in
a number of ways. They usually do not appear
ambiguous to the author. - The operator identity consists of the operator
name and password the password consists of six
digits. It should be displayed on the security
VDU and deposited into the login file when an
operator logs into the system. - What does it refer to the operator or the
password?
7Problems
- Vagueness often occurs because the
spoecification document is bulky. Achieving a
high level of precision consistently is an almost
impossible task. - The interface to the system used by the radar
operators should be user-friendly. - The above statement contains no useful
information! - Incompleteness missing details such as a
failure to specify what should occur in certain
conditions. - The system should maintain the hourly level of
the reservoir from depth sensors in the
reservoir. These values should be stored for the
past six months. - The function of the AVERAGE command is to display
on a PC the average water depth for a particular
sensor between two times. - What happens if the user specifies a period
greater than six months?
8Problems
- Mixed levels of abstraction leads to difficulty
in seeing the overall functional architecture of
a system. - For example, if the following statements were
intermixed - The purpose of the system is to track the stock
in a warehouse. - When the loading clerk types in the withdraw
command he or she will communicate the order
number, the identity of the item to be removed,
and the quantity removed. The system will respond
with a confirmation that the removal is
allowable. - This leads to a lack of clarity.
9Elevator problem
- Let us define the elevator problem as
- We need to move n elevators between m floors.
- Each elevator has a set of m buttons, one for
each floor. These illuminate when pressed and
cause the elevator to visit the corresponding
floor. The illumination is cancelled when the
corresponding floor is visited by the elevator - Each floor, except the first floor and the top
floor has two buttons, one to request an
up-elevator, and one to request a down-elevator.
These buttons illuminate when pressed. The
illumination is cancelled when an elevator visits
the floor and then moves in the desired
direction. - When an elevator has no requests, it remains at
tis current floor with its doors closed.
10Finite state machines
- In each of the n elevators, there are m buttons
one for each floor. These are called elevator
buttons (EB). - One each floor there are two buttons to request
an up and down elevator. These are called floor
buttons (FB). - Let EB(e, f) denote the button in elevator e that
is pressed to request floor f. - EB(e, f) can be in two states
- EBON(e, f) Elevator Button (e, f) ON.
- EBOFF(e, f) Elevator Button (e, f) OFF.
- If the button is on and the elevator arrives at
floor f, then the button is turned off. If the
button is off, and it is pressed, then the button
comes on. - These two events are
- EBP(e, f) Elevator Button (e, f) Pressed.
- EAF(e, f) Elevator e Arrives at Floor f.
11Finite state machines
EBP(e, f)
EBOFF(e, f)
EBON(e, f)
EAF(e, f)
- The state transition diagram for an elevator
button is given above. - We introduce a predicate
- V(e, f) Elevator e is Visiting floor f.
- A predicate is a boolean function.
- If elevator button (e, f) is off (current state)
and elevator button (e, f) is pressed (event) and
elevator e is not visiting floor f (predicate),
then the button is turned on. - EBOFF(e, f) ? EBP(e, f) ? V(e, f) ? EBON(e, f)
12Finite state machines
- If the elevator is visiting floor f when button
(e, f) is pressed, then nothing happens. - If the elevator arrives at floor f and the button
is on, then it is turned off. - EBON(e, f) ? EAF(e, f) ? EBOFF(e, f)
- Now we consider the floor buttons.
- FB(d, f) denotes the button on floor f that
requests an elevator traveling in direction d. - Each button has two states
- FBON(d, f) Floor Button (d, f) is ON.
- FBOFF(d, f) Floor Button (d, f) is OFF.
13Finite state machines
- If the button is on and an elevator arrives at
floor f traveling in direction d, then the button
is turned off. - If the button is off, and it is pressed, then the
button comes on. - These events are
- FBP(d, f) Floor Button (d, f) Pressed
- EAF(1..n, f) Elevator 1 or or Elevator n
Arrives at floor f. - Note a..b to denote disjunction. We use P(a,
1..n, b) to denote - P(a, 1, b) ? P(a, 2, b) ? ? P(a, n, b)
FBP(d, f)
FBOFF(d, f)
FBON(d, f)
EAF(1..n, f)
14Finite state machines
- We define predicate S as follows
- S(d, e, f) Elevator e is visiting floor f and
the direction in which it is about to move is
either up (d U), down (d D), or no requests
are pending (d N) - This predicate is actually a state.
- The transition rules for floor buttons is then
- FBOFF(d, f) ? FBP(d, f) ? S(d, 1..n, f) ?
FBON(d, f) - FBON(d, f) ? EAF(1..n, f) ? S(d, 1..n, f) ?
FBOFF(d, f), dD?U - V(e, f) can be defined in terms of S(d, e, f)
- V(e, f) S(U, e, f) ? S(D, e, f) ? S(N, e, f)
15Finite state machines
- Three elevator states can be defined
- M(d, e, f) Elevator e is Moving in direction d
(floor f is next) - S(d, e, f) Elevator e is Stopped (d-bound) at
floor f - W(e, f) Elevator e is Waiting at floor f (door
closed) - Other interesting events include
- DC(e, f) Door Closed for elevator e at floor f
- ST(e, f) Sensor Triggered as elevator e nears
floor f - RL Request Logged (button pressed)
- Rules governing movement are
- S(U, e, f) ? DC(e, f) ? M(U, e, f1)
- S(D, e, f) ? DC(e, f) ? M(D, e, f-1)
- S(N, e, f) ? DC(e, f) ? W(e, f)
16Finite state machines
M(U, e, f1)
M(D, e, f)
ST(e, f)
DC(e, f)
RL
RL
S(U, e, f)
S(N, e, f)
S(D, e, f)
DC(e, f)
DC(e, f)
RL
W(e, f)
RL
RL
ST(e, f)
M(D, e, f-1)
M(U, e, f)
17Finite state machines
- The finite state machine is more precise than a
natural language or graphical representation. - It is almost as easy to understand
- It doesnt scale well to problems with many
states. - Finite state machines do not handles the concept
of time. For this one has to use an extension of
finite state machines called a statechart,
18Petri nets
- A major problem with specifying concurrent
systems is dealing with timing. - The problem manifests itself in many ways
- Synchronization
- Race conditions
- Deadlock
- Timing problems can be a result of poor design or
implementation, which are in turn a result of
poor specification. - Petri nets are a powerful technique for
sepcifying and designing systems with potential
timing problems. - Petri nets were invented by Carl Adam Petri in
1962.
19Petri nets - introduction
- A Petri net consists of 4 parts a set of places
P a set of transitions T an input function I
and output function O. - The set of places P p1, p2, p3, p4
- The set of transitions T t1, t2
- The input functions for the transitions are
- I(t1) p2, p4
- I(t2) p2
- The output functions for the transitions are
- O(t1) p1
- O(t2) p3, p3
p2
t2
t1
p3
p1
p4
20Petri nets - introduction
- More formally, a Petri net is a 4-tuple, C (P,
T, I, O) - P p1, p2, , pn is a finite set of places, n
0, - T t1, t2, , tm is a finite set of
transitions, m 0 P T are disjoint. - I T ? P? is the input function, a mapping from
transitions onto bags of places. - O T ? P? is the output function, a mapping from
transitions onto bags of places. - The marking of a Petri net is the assignment of
tokens to that Petri net.
21Petri nets - introduction
p2
t2
t1
p3
p1
p4
- The Petri net above contains 4 tokens.
- The marking can be represented by the vector (1,
2, 0, 1). - Transition t1 is enables (ready to fire) because
there are tokens in p2 and p4. - If the transition fires, 1 token is removed from
p2 and p4, and 1 token is added to p1. - Note that the number of tokens if not conserved.
22Petri nets - introduction
- Petri nets are nondeterministic. If more than 1
transition could fire, one is selected
arbitrarily. - In the previous slide, both t1 and t2 are
enabled. If t1 fires, the resultant marking
becomes (2, 1, 0, 0). - Formally a marking M of a Petri net C (P, T, I,
O), is a function from the set of places P to te
set of non-negative integers - M P ? (0, 1, 2, )
- A marked Petri net is then a 5-tuple (P, T, I, O,
M).
23Petri net - introduction
- An extension to a Petri net is an inhibitor arc.
- A transition is enabled if there is a token on
each of its (normal) input arcs, and no token on
any inhibitor input arcs. - Transition t1 is enabled below.
p2
t2
t1
p3
p1
p4
24Petri nets elevator problem
- There are n elevators installed in a building
with m floors. - Each floor is represented by a place, Ff, 1 f
m. - An elevator is represented by a token.
- A token in Ff denotes that an elevator is at
floor f. - Constraint
- Each elevator has a set of m buttons one for
each floor. - These are illuminated when pressed, cause the
elevator to travel to that floor, and turned off
when the elevator arrives at that floor. - Additional places are needed to model this.
- The elevator button for floor f in elevator e is
denoted EBf, e with 1 f m, 1 e n - For the sake of simplicity we suppress the
subscript e denoting the elevator.
25Petri nets elevator problem
- A token in EBf denotes that the elevator button
for floor f is illuminated. - Assume that EBf is not initially illuminated.
- Note that the button is illuminated the first
time it is pressed and subsequent presses do
nothing (until elevator arrives that the correct
floor). - Assume that the elevator is currently at floor g.
EBf is pressed
Elevator in action
Ff
EBf
Fg
26Petri nets elevator problem
- Each floor has two buttons (except the bottom and
top floors) to represent an up-elevator and a
down-elevator. These buttons illuminate when
pressed, and are cancelled when an elevator
traveling in the right direction arrives at the
floor. - The floor buttons are represented by places FBdf
and Fbuf - The situation when an elevator reaches floor f
from floor g with one or both buttons illuminated
is given by
FBuf is pressed
Elevator in action
Ff
FBuf
Fg
FBdf is pressed
Ff
FBdf
Elevator in action
27Petri nets elevator problem
- When an elevator has no requests in needs to
remain on the same floor. - This is easily achieved,
- If there are no requests, no Elevator in action
is enabled.
28Petri nets - properties
- Petri nets have some additional useful
properties. - It is possible to prove that the system has no
deadlocks or livelocks. - They can be used to perform a proof of
correctness. - The system is simple and can be implemented as
part of a tool.
29Z
- Z is a popular formal specification language.
- See Schach page347 for a discussion on the
pronunciation of Z (zed). - Use of Z requires knowledge of set theory,
functions and discrete mathematics, including
first-order logic. - Like the earlier formal systems examined, there
are several variants of Z. - In its simplest form a Z specification consists
of 4 sections - Given sets, data types, and constants
- State definitions
- Initial state
- Operations
- It uses standard set and logic operators ?, ?, ?
- It uses some additional symbols such as ?, ?, ?.
30Z
- Given sets
- A Z specification begins with a list of given
sets. These are sets that need not be defined in
detail. - The names of given sets appears in brackets,
e.g., Button to represent the set of buttons in
the elevator problem. - State definition
- A Z specification consists of a number of
schemata. - Each schemata consists of a group of variable
declarations and a list of predicates that
constrain the values of the variables. - A schemata S is defined as
S
declarations predicates
31Z
- For the elevator problem, there are four subsets
of Button - floor buttons
- elevator buttons
- buttons (the set of all buttons in the elevator
problem) - pushed (the set of buttons that have been pushed
and are therefore on). - The symbol P denotes powerset (the set of all
subsets of a given set).
Button_State
floor_button elevator_button P
Button buttons P Button pushed P
Button floor_button ? elevator_button
Ø floor_button ? elevator_button buttons
32Z
- Initial state
- The abstract initial state describes the state of
the system when it is first turned on. - For the elevator problem the initial state is
- Button_init ? Button_State' pushed' Ø
- This is a vertical schema definition (as opposed
to a horizontal one). - The initial state above tells us that when the
elevator is first turned on, the set pushed is
initially empty that is, all buttons are off.
33Z
- Operations
- If a button is pushed for the first time, then
that button is turned on and added to the set
pushed. - The ? in the first line of the schema tells us
that operation changes the state of Button_State. - The operation has one input variable, button?.
The ? symbol denotes an input variable, whereas
the ! symbol denotes an output variable.
Push_Button
?Button_State button? Button (button? ? buttons)
? (((button? ? pushed) ? (pushed' pushed ?
button?)) ? ((button? ? pushed) ? (pushed'
pushed)))
34Z
- The predicate part of the operation consists of a
group of preconditions that must hold before the
operation is invoked, and a group of
postconditions that must hold after the operation
is complete. - If the operation is invoked without the
preconditions being satisfied, then unspecified
(read unpredictable) results occur. - pushed' denotes an updated value of pushed.
35Z
- When an elevator arrives at a floor, if the
corresponding floor button is on, then it must be
turned off, similarly for the corresponding
elevator button. - The symbol \ denotes set difference
- The solution below is an oversimplification on
that it does not distinguish between up and down
floor buttons.
Floor_Arrival
?Button_State button? Button (button? ? buttons)
? (((button? ? pushed) ? (pushed' pushed \
button?)) ? ((button? ? pushed) ? (pushed'
pushed)))
36Z
- Z is fairly widely used and has been employed on
some large scale projects. - Easy to find faults in Z specifications,
especially during inspections of the
specification, and inspection of the design
and/or code against the formal specification. - Need to be precise when using Z, resulting in
fewer ambiguities, contradictions and omissions
than an informal specification. - Can use Z to perform a formal proof of
correctness. - Professionals with high school math can be taught
to write Z specifications (although more
mathematical sophistication is required to do the
proof). - Use of Z decreases software cost by decreasing
overall development time. - Natural language specifications (for the customer
for example) derived from a Z specification has
fewer problems than a natural language
description written from scratch without a formal
description to act as a guide.
37Z, Petri nets and beyond
- Z, like Petri nets, is still undergoing
development. - Researchers are constantly extending Z and Petri
nets to provide greater functionality, power and
flexibility. - There are temporal versions of Z which allow the
predicates to cover time dependant semantics. - There are many other formalisms including
- Anna
- Gist
- VDM
- CSP
- Hoare axiomatics
- Operational semantics
- Denotational semantics
- Larch
- OBJ
- Lotos
38Formal methods
Cost
Validation
Design and Implementation
Validation
Design and Implementation
Specification
Specification
With formal methods
Without formal methods
39Conclusion
- Even if you dont think formalism is needed for
your project, it often helps to think in terms of
a formalism to ensure that the informal (natural
language) specification you write is as clear as
possible. - Formalisms often allow us to mathematically check
specific properties of the specification. - They can sometimes be used to automatically
generate parts of the software system. - Petri nets and Z are probably the two most
popular formalisms at the present.
