Title: HandsOn Calibration


1
Hands-On Calibration
  • Ron Maddalena
  • July 13, 2007

2
Preliminaries
  • Change directory cd /home/scratch/sdscal
  • Start GBTIDL
  • Access data
  • filein,T_TCAL14MAR07.acs.raw.fits
  • summary
  • Note For 8 GHz receiver, used observing
    technique of OffOn with, for example, scan 6 an
    observation toward blank sky and scan 7 toward
    3C286. Used 4 windows
  • Note For 12 GHz, dual feed receiver, used
    observing technique of NOD. Source in feed 1 for
    scan 31, in feed 2 for scan 32. Used 2 windows.
  • getps,6,ifnum0
  • Try different windows to see whats different
  • header
  • Record elevation, UT date and time
  • getnod,42,ifnum0
  • For the adventurous
  • .compile getscalquad.pro

3
Typical Position-Switched Calibration Equation
4
Putting it all together
Remove AveragingSolve for Tcal
5
What Do We Need?
  • ? from graph, assume gain is elevation
    independent
  • Ap from dish diameter
  • Calculate Air Mass from elevation of observation
  • S from a catalog (e.g., Ott et al 1994, AA, 284,
    331)
  • Table pp 333-334
  • Functional fit p. 335
  • Note that S will vary significantly across wide
    bandwidths
  • t from weather models
  • At Linux prompt, type cleo forecasts

6
What Do We Need?
  • t from weather models
  • At Linux prompt, type cleo forecasts
  • Select Curves tab
  • Enter date and UT of the observations
  • Enter frequency range for the receiver (e.g.,
    7-11 GHz, 11-16 GHz)
  • May want to select Write Out Results to create
    an ASCII file of results
  • Click on Process
  • Read opacities off of graph

7
What again are we calculating?
8
How to Calculate (RefOn-RefOff)/(Sig-Ref)
  • Use the commands emptystack, select
    avgstack, copy, subtract, divide, and
    scale
  • Emptystack
  • Clears anything that peviously has been done with
    the stack
  • Select,scan6,calF,ifnum0,plnum0,fdnum0
  • Finds all data that meet this selection criteria
  • Avgstack
  • Averages together the data found by Select and
    places into Data Container (DC) zero
  • Copy,0,9
  • Moves the results to another DC for later use
  • DC 9 will now contain RefOff
  • Repeat for scan6, calT, place into DC 8 to
    create RefOn
  • Repeat for scan7, calF, place into DC 7 to
    create SigOff
  • Repeat for scan7, calT, place into DC 6 to
    create SigOn

9
How to Calculate (RefOn-RefOff)/(Sig-Ref)
  • Summary
  • DC 9 contains RefOff
  • DC 8 contains RefOn
  • DC 7 contains SigOff
  • DC 6 contains SigOn
  • Create Sig and place into DC 10
  • Add,7,6,10
  • Scale,0.5,10
  • Similarly create Ref and place into DC 11
  • Create Sig-Ref and place into DC 12
  • Subtract,10,11,12
  • Similarly create RefOn-RefOff and place into DC
    13
  • Create (RefOn-RefOff)/(Sig-Ref) and place into DC
    14
  • Divide,13,12,14
  • Show,14

10
What again are we calculating?
  • Finally, scale DC 14 by ?, S, to determine
    Tcal. For example, using fictitious values
  • scale, 0.51234/222, 14
  • scale, 1/1.38e-16exp(-0.12/sin(33180/!pi)), 14
  • etc.
  • show,14

11
Check for non-linearity
  • If system is linear, than
  • (SigOn-SigOff) (RefOn-RefOff ) 0
  • Model the response curve to 2nd order
  • Pout B Pin C Pin2
  • Our observations provide
  • Pout Refoff when PinTsys
  • Pout Refon when PinTsysTcal
  • Pout Sigoff when PinTsysTA
  • Pout Sigon when PinTsysTATcal
  • Its easy to show that
  • C (Sigon- Sigoff )-(Refon- Refoff)/(2TATcal)
  • Try to estimate a value for C using subtract,
    divide and scale
  • Things are really a bit more complicated since we
    really measure Pout and want to determine Pin .
    Must invert 4 simultaneous linear equations.

12
Now for the real easy way
  • Getscal,7,6,ifnum0,plnum0,fdnum0,tau0.05,
    ap_eff0.55,smth1
  • Show,13 (Tcal, assuming linearity)
  • Show,3 (Tcal, assuming non-linearity)
  • Show,15 (Tsys, assuming linearity)
  • Show,5 (Tsys, assuming non-linearity)
  • Show,11 (Source flux)
