New Features in Paradyn and Dyninst

1
New Features in Paradyn and Dyninst

• Matt LeGendre
• legendre_at_cs.wisc.edu

Ray Chen rchen_at_cs.umd.edu
2
Dyninst 5.2 Release

• API additions
• Slicing
• Parallel Language Instructions
• Platform/Feature Expansion
• 64-bit AIX binary support
• 32-bit PowerPC Linux
• Beta Binary Rewriter
• Optimizations
• Code layout optimizations
• New liveness-based tramp code generation

3
Release History

• Source lines of code for 5.2 release

4
Release History

• Source lines of code over time

5
Binary Rewriter Beta

• Static binaries
• Dynamic binaries (but not inter-library calls)
• System V Elf Platforms
• Linux, Solaris, BG/L
• x86, SPARC, PPC, IA-64
• Documentation available upon request

6
Code Optimizations

• Code layout optimizations
• New fix point code generation
• Improved instrumentation layout
• Register liveness analysis
• Track all GPRs on x86-64, Power
• Track flags register on x86

7
SymtabAPI 2.0

• Released in December 2007
• New Features
• Debug Information
• Line information
• Local variables
• Types
• Address mapping
• Binary generation

8
Slicing Interface

• Additions to BPatch_function class
• getControlDependenceGraph()
• getDataDependenceGraph()
• Control/data dependence graph that includes the
  parameter instruction, its successors, and
  predecessors
• getSlice()
• Union of control dependence graph and data
  dependence graph

9
Slicing Interface

• New classes
• BPatch_dependenceGraphNode class
• Returned from all four slicing functions
• Contains list of incoming and outgoing edges
• BPatch_dependenceGraphEdge class
• Directed edge between above graph nodes
• All graphs built on demand
• No unnecessary runtime overhead

10
Parallel Language Instruction Interface

• Additions to BPatch_image class
• getParRegions()
• Provides access to parallel regions
• Returns vector of BPatch_parRegion
• New BPatch_parRegion class
• Provides parallel language construct abstraction
• Generic interface functions
• getStartAddress()
• getEndAddress()
• getInstructions()
• getClause()

11
Parallel Language Instruction Interface

• getClause() to access region information
• Every region has Region_Type key
• OMP_PARALLEL, OMP_DO_FOR, etc
• 15 types for OpenMP constructs
• Other language regions easily added
• Region specific keys
• OMP_DO_FOR
• CHUNK_SIZE
• NUM_ITERATIONS
• ORDERED
• SCHEDULE

12
Annotations

• Public interface outside components
• Included from Annotatable.h
• Already used extensively internally
• DyninstAPI
• SymtabAPI

Annotateltclass T, class Sgt(T , S ,
name_t) VectorltSgt getAnnotations(T , name_t)
13
Annotations

• DyninstAPI
• BPatch_function class
• Parameter type lists
• Return types
• Dependency graphs (data, control, program)
• Internal instruction class
• Register read/write sets

14
Annotations

• SymtabAPI
• Symbol class
• Filename
• Symbol table name
• Local variable type lists
• Module class
• Line information
• User defined type collections
• Symtab class
• User specified
• Functions, Regions, Types, Symbols

15
DyninstAPI 6.0

• New APIs
• StackwalkerAPI
• InstructionAPI
• Extended Functionality
• Machine learning gap parsing
• Full binary rewriter support
• 64-bit PowerPC Linux support
• SymtabAPI serialization
• Convenient Features
• Autoconf build system

16
(No Transcript)
17
Extra Funtime Stats

• Repository history by size
