Investigation on the Convection Pattern

1
Investigation on the Convection Pattern
of Liquid Steel in the Continuous Casting
Tundish by Theoretical Analysis, Water
Model Experiment and CFD Simulation
D. Y. Sheng Lage Jonsson
Process Metallurgy Department,
MEFOS, S 97125, Lulea, Sweden
Tel [phone]
Fax [phone]
Email sheng_at_mefos.se
PHOENICS User Conference
2
Process Introduction
Function of Tundish
Tradition
1, Steel distribution vessel
Modern
2, Inclusion removal
3, Alloy trimming
4, Superheat control
5, Homogenisation
Tundish Metallurgy
PHOENICS User Conference
3
Problem Arisement
Two different opinions
The steel flow in tundish is
Objective
1, Forced Convection System?
OR
2, Mixed Convection System?
PHOENICS User Conference
4
CFD Causes to This Study !
Two different flow pattern are on my screen
Is this
true ?
PHOENICS User Conference
5
Theoretical Consideration
(1) Even one degree temperature difference in the
tundish,
buoyancy can not be ingored.
(2) Water model can be used to simulate the
convection pattern
due to similar of this dimensionless number.
PHOENICS User Conference
6
Water Model Experiment
1
1
l
a
d
l
e
(
1
)
t
h
e
r
m
o
c
o
u
p
l
e
I
n
t
e
r
f
a
c
e
c
a
m
e
r
a
t
u
n
d
i
s
h
(
2
)
M
i
c
r
o
c
o
m
p
u
t
e
r
o
u
t
l
e
t
(
3
)
MEFOS
PHOENICS User Conference
7
Temperature, (æ)
b
a
Time, (s)
c
d
8
CFD Simulation
Modeling description


1.

3-D
Navier-Stokes equations.

2.
S
tandard k-
e
two equations model

3.
F
ree surface is
k
ept at a fixed level.

4.
Fluid flow and temperature are coupled
PHOENICS 3.1, Sun Enterprise 4000,
6 CPU 350 MHz
MEFOS
PHOENICS User Conference
9
Hotter Incoming (1)
MEFOS
PHOENICS User Conference
10
Cooler Incoming (1)
MEFOS
PHOENICS User Conference
11
Schematic of flow pattern
a, equal temperature inlet
b, hotter inlet
c, cooler inlet
MEFOS
PHOENICS User Conference
12

CFD model
Physical model
No.6
No.10
Temperature, (K)

Time, (s)
No.9
No.4
13
(No Transcript)
14
Hotter Incoming (2)
MEFOS
PHOENICS User Conference
15
Cooler Incoming (2)
MEFOS
PHOENICS User Conference
16
Future work
(1) Turbulence model of the transition region
(2) Use the CFD model for real tundish simulation
(3) Considersing the heat loss surrounding and
additional heat source
(4) Time dependent inlet temperature variation
will be considered.
PHOENICS User Conference
17
Conclusion
(1) Dimensionless number Gr/Re
2
can be used to
set up thermal similarity between water
model
and actual tundish
(2) Thermal buoyancy driven flow is obvious in
the
non-isothermal water model
(3) CFD simulation keeps good agreement with
mesurement
(4) The tundish is a mixed convection system
PHOENICS User Conference
