Title: Bytton GPRSEDGE


1
Bytton GPRS/EDGE Main features and applications
2
Content
  • Overview
  • Connections and Ports
  • Optional modules
  • Main Features
  • VPN Tunneling
  • Web based interface
  • Back-up security features
  • Cellular Network features
  • Bytton Typical Applications
  • Benefits

3
Bytton GPRS/EDGE - overview
  • Professional router for advanced M2M applications
  • High secure data transfer for professional
    systems
  • 2 variants of equipment single or dual SIM
    capability (back-up purpose between 2 cellular
    networks)
  • Quad Band GPRS/EDGE coverage 850/900/1800/1900
    MHz
  • Advanced VPN module including
  • GRE
  • IPSec
  • L2TP
  • PPTP, PPTPD
  • Plastic or metal case used specially in
    industrial environments and for special safety
    requirements

plastic case
metal case
4
Connections Ports
SIM slot
  • 4 x LAN - RJ45 connectors Ethernet 10/100
    Base-T
  • 1 x WAN RJ45 connector Ethernet 10/100 Base-T
  • 2 x USB2.0 connectors
  • 1 or 2 SIM slots depending on the version used
  • 1 SMA male antenna for mobile connections 1 SMA
    male antenna for Wi-Fi module
  • 1 x DB9 or DB25 serial interface optional
  • 1 FXS 1 FXO only one simultaneous active
    optional
  • Wi-Fi embedded module up to 256 terminals
    connected - optional

Power Supply connector
Mobile antenna
WiFi antenna
2 x USB2.0 connectors
FXO connector
5 x Ethernet connectors 4xLAN 1xWAN
FXS connector
Note The figure above describes the usual
connectors for Bytton GPRS /EDGE with 1 SIM -
WiFi voice module included , without serial
interfaces
5
Optional modules
  • Analogue Voice
  • 1 FXS interface POTS connection
  • 1 FXO interface Analogue PBX connection
  • Call status display on the web based GUI
  • Wi-Fi module
  • 802.11 b/g compatible module
  • Access Point, Station or Bridge operation
  • 2.4 GHz frequency band supported
  • RS232 serial interfaces
  • DB9 or DB25 serial connector
  • XOT protocol supported X.25 over TCP/IP
  • Connection of serial devices ATM, POS,
    Concentrators
  • GPS module
  • Special applications such as car fleet management
  • 20 channels available
  • Velocity up to 500m/s and up to 5G acceleration

6
Main Features I
  • Proprietary software platform Linux based
  • NAT Traversal and built-in firewall
  • Static and Dynamic Routing through RIPv.1,
    RIPv.2, OSPF, BGP
  • Integrated Ethernet switch (4 ports) with
    management and Layer 2 QoS according with 802.1p,
    802.1q
  • Secured web based (https) administration and
    configuration interface
  • Remote management through
  • HTTPS
  • SSH
  • Telnet
  • CLI
  • SNMP

7
Main Features II
  • Advanced SMS module
  • Send and Receive SMS from web interface
  • SMS 2 Group send the same SMS to several mobile
    numbers
  • SMS info about equipment status connectivity,
    signal level
  • AT Commands for cellular module
  • DHCP DNS Server, Proxy DNS client, Dynamic DNS
  • POTS and PBX analogue voice through FXS and FXO
    interfaces
  • Local time synchronization using NTP protocol
  • Status display through optical indicators (LEDs)
    associated to each interface
  • PPP and PPPoE connectivity

8
VPN Tunneling
  • VPN tunnels used IPSec, GRE, L2TP (server
    tunnel), PPTP (client tunnel), PPTPD (server
    tunnel)
  • GRE tunnels used for the transport of multicast
    packages and non-IP traffic
  • IP Sec tunnels
  • Network to Network, Gateway to Gateway, Road
    Warrior
  • DES, 3DES, AES encryption protocols
  • Encapsulation into IP packets - ESP protocol
  • Identity authentication of peers through
    symmetrical Pre Shared Key (PSK) or non
    symmetrical Public RSA key
  • Automatic key negotiation and services
    establishment through IKE mechanism
  • MD5 and SHA1 authentication algorithms
  • Diffie Hellman algorithm used to securely
    exchange the keys that encrypt data
  • IKE lifetime setting top establish the duration
    of keying channel of a connection before being
    renegotiated
  • Perfect Forward Secrecy (PFS) - the decryption of
    a key has no impact on the security of other keys

9
Web based interface
  • HTTPS web secured access
  • Several menus for configuring system parameters
  • LAN WAN configuration
  • Routing settings
  • SIM card parameters
  • Web or IP camera connection
  • Voice SMS sections

10
Back-up security features
  • Multiple fail-over possibilities SIM card 1, SIM
    card 2, external USB modem or fixed Ethernet
    lines
  • MAC address filtering, DMZ (Demilitarized Zone)
  • SPI and DoS - intrusion protection
  • Authentication using PAP and CHAP protocols
  • VPN and IP Tunneling protocols
  • Secure HTTPS access to configuration pages
  • Secure SSH remote management

11
Cellular network features
  • Quad Band GPRS / EDGE coverage
    850/900/1800/1900 MHz
  • Download Data Transfer Rates
  • GPRS 85.6 Kbps
  • EDGE 236.8 Kbps
  • Upload Data Transfer Rates
  • GPRS 59.2 Kbps
  • EDGE 118.4 Kbps
  • GPRS/EDGE Multi Slot Class 12
  • Power Class
  • GSM/GPRS/EDGE 850/900 MHZ GSM Power Class 4,
    EDGE E2
  • GSM/GPRS/EDGE 1800/1900 MHZ GSM Power Class
    1/EDGE E2

12
Bytton Typical Applications
  • Bytton GPRS/EDGE equipment can be used in
    different types of applications specially in M2M
    environment
  • ATM Banking connect banks ATM network
  • Professional back-up mission critical
    applications
  • Lottery and Betting secured connection for
    lottery and betting terminals
  • Retail interconnects POS terminals
  • Telemetry data acquisition and secured transfer
    to processing facility
  • Wireless video surveillance used in sites where
    fixed lines are not available
  • Customized and special applications GPS
    surveillance, mobile internet

13
ATM Banking
  • Bytton GPRS/EDGE used to transmit ATM data to
    central location

GPRS/EDGE
GRE IPSec VPN
GRE IPSec VPN
ETH
ETH or RS232
Bank HQ
TOPEX Bytton GPRS/EDGE
FXS
ATM location with surveillance and customer
support phone
14
Professional Back-up
  • Bytton offers a complete professional backup
    solution, allowing for secure connectivity of
    internet access, voice services for companies
    that require an always-on connection

15
Lottery Betting
  • Data acquisition from different branches
    regarding tickets and other commercial activities
    X.25 traffic tunneled through the IP network

16
Retail
  • Secured connection for POS and card readers
    terminals

17
Telemetry
  • Secured data transfer from remote locations to
    the processing facility, where useful information
    can be extracted from the data received remotely

18
Wireless Video Surveillance
  • Transfer of video stream from sites with no fixed
    line Internet for instance construction site

19
Fleet management
  • Allows the localization and transmission of info
    related to the geographic position through
    integrated GPS module
  • Bytton receives through GPS module the exact
    location of the monitored vehicle and transfer
    the info through the GPRS/EDGE network to the
    central location

NOC
TOPEX Bytton
back-up link
20
Customized solutions
  • Every customer is unique, thats why Topex Bytton
    can be customized to match the customers specific
    requirements.
  • AC and heating applications - temperature
    conditions based on the occupancy information in
    a hotel. TOPEX router connects to the hotel
    controller and sends the information to the
    management center delivering this way reliable
    information about the conditions in the hotel.
  • Medical applications - collecting information
    from dispersed Blood Banks or Nurse Stations and
    sending them to the Management Center
  • Street Lamp Project - In cities with street lamps
    with integrated PCB (printed circuit board), the
    information on each pillar is sent to the
    Intelligent Concentrator Head End (ICHE). Then,
    connected to the wireless router, all data is
    sent to the Electricity Provider that collects
    the information from the ICHE units around the
    city. Information gathered can include power
    consumption, bulb life expectation or failure.

21
Bytton GPRS/EDGE benefits
  • Secured communication through IPSec, GRE, L2TP,
    PPTP, PPTPD tunnels
  • Dual SIM version assuring real time back-up
    between 2 different GPRS/EDGE networks
  • Multiple back-up possibilities dual SIM
    capabilities, external USB modem, fixed Ethernet
    connection
  • Powerful management support
  • Interconnection of several devices such as
    lottery and betting terminals, POS, ATM machines
  • Advanced web based administration and
    configuration interface
  • Replacement of equipments installed and
    configured at customer premises switch, router,
    GPRS modem
