History

1

• History
• Company Philosophy
• Capabilities
• Product Line Offering
• Sales Marketing Programs
• Website Overview
• Water-Works Demonstration
• Current Projects Installations
• Comments, Questions Answers

2
AMP 101 INTRO

• AMP History

3
Company History

• Timeline
• 1873 American Marsh Conception
• Steam Pumps
• Production of simplex and duplex steam pumps
• Hundreds of models
• Many patents

4
Company History

• 1915
• Centrifugal Pumps
• AMP innovator in bringing centrifugal technology
  from Russia to the United States

• Utilize hydraulic engineers with years of steam
  pump experience to exploit this new technology

• Develop literally hundreds of models
• AMP takes the lead in Centrifugal Technology in
  the United States

• 1919
• Sales exceed 1M annually

5
Company History

• Late 1930s
• War Powers Act
• AMP supplied steam and centrifugal pumps to
  nearly all Navy shipping vessels

• AMP manufactured self-primer pumps to Army

6
Company History

• 1949
• AMP is one of the Largest Pump Companies in the
  world

• Employed several hundred people
• Vast Sales Marketing department
• Vast Engineering department
• Competed in all markets
• Industrial
• Municipal
• Commercial

7
Company History

• 1950s
• Irrigation
• Fire
• Boiler Feed
• Circulating
• Industrial
• Municipal

8
Company History

• 1960
• Frank Stallings purchased AMP
• Zero experience in Pumping Technology
• Some experience with a manufacturing company
• Moved the company from Battle Creek, MI to
  Lansing, MI

9
Company History

• 1960 to 1985
• AMP reaches all time low
• All profits were bled out of company
• Zero re-investment
• 1985 Demmer Corp purchases AMP
• 1985 to 1998
• Demmer purchased AMP not for product line but for
  building site

• AMP is pushed virtually into corner of Lansing,
  MI facility

• Zero re-investment

10
Company History

• 1998
• Charles Foust purchases AMP
• Charlie owns Clarksville Foundry
• Move AMP from Lansing, MI to Clarksville, TN
• All drawings (nearly 70,000)
• All patterns (nearly 250,000)
• Outdated machinery
• Existing stock
• 2001
• American-Marsh merges with J-Line
• Move AMP from Clarksville, TN to Collierville,
  TN

• All drawings (nearly 70,000)
• Existing stock

11
Company History

• Today
• Invested time money
• 14 Product Lines
• New end suction models
• New split case models
• New self-primer models
• Updating of manufacturing technology
• New Patterns
• New CNC machines
• Higher level of quality (castings), machining
• Updating of sales marketing
• New literature
• New website
• New cutaway pumps
• New advertising
• Newer distribution network/regional managers

12
Company History

• Today
• Company Organization
• Engineered Process Group (EPG)
• Municipal, Industrial Commercial Markets
• Horizontal Motor Group
• Mechanical Seal Group
• Coatings Group
• Water Systems Group (WSG)
• Irrigation, Agriculture, Plumbing, Commercial
  Markets

• Submersible Motor Group

13
AMP 101 INTRO

• Company Philosophy

14
AMP 101 INTRO

• Mission Statement
• To be an industry leading full line pump company
  providing quality products, personalized service
  and profitability to customers. We are founded
  upon striving to achieve fair business practices
  while growing intimate customer relationships by
  satisfying individual needs.
• Be fair, empathetic and responsive in servicing
  our customers.

• Respect and reinforce fellow employees and the
  power of teamwork.

• Relentlessly strive to improve what we do and how
  we do it.

• Continue to earn and be worthy of our customers
  trust.

15
AMP 101 INTRO

• Capabilities
• Emergency Stock
• Three Service/Distribution Centers
• Dedicated AMP rigs and trailers
• Full Product Line Offering
• Optional Metallurgy
• 2M Testing Facility
• Vast Engineering Staff Inside Support

16
AMP 101 INTRO

• Product Line

17
AMP 101 INTRO

• Product Line
• 200 Series Gear Pumps

18
AMP 101 INTRO

• Product Features Benefits
• 200 Series Gear Pumps (GH)
• 4 Models
• 1-1/2 to 4 Discharge
• Flows to 400 GPM
• Heads to 289 Feet
• Temperatures to 450F

19
AMP 101 INTRO

• Product Features Benefits
• 200 Series Helical Gear GH (Flex-Coupled)
• 4 Models
• 1-1/2 to 4 Discharge
• Flows to 400 GPM
• Heads to 289 Feet
• Temperatures to 450F
• Bi-directional
• Self-priming
• Heavy wall section
• Packed or mechanical seal construction
• Optional integral relief valve

20
AMP 101 INTRO

• 200 Series Helical Gear (GH)

21
AMP 101 INTRO

• Product Line
• 300 Series End Suction

22
AMP 101 INTRO

• Product Features Benefits
• 300 Series End Suction (REF REC)
• 91 Models
• 1 to 12 Discharge
• Flows to 9,000 GPM
• Heads to 450 Feet
• Temperatures to 250F

23
AMP 101 INTRO

• Product Features Benefits
• 300 Series End Suction REF (Flex-Coupled)
• 47 Models
• 1-1/4 to 12 Discharge
• Flows to 9,000 GPM
• Heads to 450 Feet
• Temperatures to 250F
• Back pull-out
• Heavy wall section, centerline discharge casing
• Integral foot on casing
• Integral seal flush
• Two single row, oil lubricated bearings
• Six power frames cover all 47 models (Kit
  Program)

• Enclosed high efficiency impellers with back pump
  out vanes

• Ground polished 416 stainless steel shaft
• Standard Carbon/Silicon-Carbide/EPDM mechanical
  seal

• Standard front case wear rings, optional impeller
  wear rings

• Hydraulically balanced impeller

24
AMP 101 INTRO

• 300 Series End Suction (REF)

25
AMP 101 INTRO

• Product Features Benefits
• 300 Series End Suction REC (Close-Coupled)
• 44 Models
• 1 to 12 Discharge
• Flows to 9,000 GPM
• Heads to 450 Feet
• Temperatures to 250F
• Back pull-out
• Heavy wall section, centerline discharge casing
• Integral foot on casing
• Integral seal flush
• Ground polished 416 stainless steel shaft
• Standard Carbon/Silicon-Carbide/EPDM mechanical
  seal

• Standard front case wear rings, optional impeller
  wear rings

• Hydraulically balanced impeller
• Enclosed high efficiency impellers with back pump
  out vanes

• Heavy section casing
• Stocked C-Face motors

26
AMP 101 INTRO

• 300 Series End Suction (REC)

27
AMP 101 INTRO

• Product Line
• 310 Series Inline End Suction

28
AMP 101 INTRO

• Product Features Benefits
• 310 Series Inline End Suction (REI)
• 43 Models
• 2 to 14 Discharge
• Flows to 9,000 GPM
• Heads to 450 Feet
• Temperatures to 250F

29
AMP 101 INTRO

• Product Features Benefits
• 310 Series Inline End Suction (REI)
• 33 Models
• 2 to 14 Discharge
• Flows to 9,000 GPM
• Heads to 450 Feet
• Temperatures to 250F
• Back pull-out
• Heavy wall section, centerline discharge casing
• Integral foot on casing
• Integral seal flush
• Enclosed high efficiency impellers with back pump
  out vanes

• Ground polished 416 stainless steel shaft
• Standard Carbon/Silicon-Carbide/EPDM mechanical
  seal

• Standard front case wear rings, optional impeller
  wear rings

• Hydraulically balanced impeller
• Stocked C-Face motors

30
AMP 101 INTRO

• 310 Series Inline End Suction (REI)

31
AMP 101 INTRO

• Product Line
• 320 Series Vertical Sump

32
AMP 101 INTRO

• Product Features Benefits
• 320 Series Sump (SREM)
• 50 Models
• 1 to 12 Discharge
• Flows to 9,000 GPM
• Heads to 450 Feet
• Temperatures to 250F

33
AMP 101 INTRO

• Product Features Benefits
• 320 Series Sump - SREM
• 50 Models
• 1 to 12 Discharge
• Flows to 9,000 GPM
• Heads to 450 Feet
• Temperatures to 250F
• Enclosed impellers
• Pump setting flexibility
• Lineshaft bearing options
• Low cost
• Efficient
• Compact
• Duplex orientation

34
AMP 101 INTRO

• 320 Series Sump (SREM)

35
AMP 101 INTRO

• Product Line
• 330 Series Non-Clog

36
AMP 101 INTRO

• Product Features Benefits
• 330 Series Non-Clog (NKS, WS SNC)
• 36 Models
• 1-1/2 to 6 Discharge
• Flows to 2,800 GPM
• Heads to 180 Feet
• Temperatures to 200F

37
AMP 101 INTRO

• Product Features Benefits
• 330 Series Non-Clog - NKS WS
• 12 Models
• 1-1/2 to 6 Discharge
• Flows to 2,800 GPM
• Heads to 180 Feet
• Temperatures to 200F
• Two-vane open enclosed, non-clogging impeller
• Back pull out design
• Heavy section casing
• Optional stuffing box
• Lineshaft bearing options
• Pump setting flexibility
• Duplex orientation

38
AMP 101 INTRO

• 330 Series Non-Clog (NKS WS)

39
AMP 101 INTRO

• Product Features Benefits
• 330 Series Submersible Non-Clog SNC
• 16 Models
• 1-1/2 to 6 Discharge
• Flows to 2,800 GPM
• Heads to 180 Feet
• Temperatures to 100F
• Two Impeller Options
• Semi-Open
• Enclosed
• Heavy Wall Section, Centerline Discharge Casing
• Oil Lubricated, Double Mechanical Seals
• Seal Chamber Moisture Probe
• Stainless Steel Shaft
• Epoxy Coating on Entire Pump Surface
• Dry Motor Design with Auto-Cut Motor Protection
• Motor Winding Thermal Protection
• Optional Easy Lift GRS Guide Rail System

40
AMP 101 INTRO

• 330 Series Submersible Non-Clog (SNC)

41
AMP 101 INTRO

• 330 Series Non-Clog (NK, W SNC)
• Solids Passing Capability
• Pump Size Solids Diameter
• 1-1/2 1-1/4
• 2 1-1/2
• 2-1/2 2
• 3 2-1/2
• 4 3
• 5 4
• 6 5

42
AMP 101 INTRO

• Product Line
• 340 Series Double Suction HSC

43
AMP 101 INTRO

• Product Features Benefits
• 340 Series Double Suction Split Case (HD, XHD)
• 97 Models
• 1-1/2 to 44 Discharge
• Flows to 85,000 GPM
• Heads to 550 Feet
• Temperatures to 300F

44
AMP 101 INTRO

• Product Features Benefits
• 340 Series Double Suction Split Case HD
• 38 Models
• 2 to 32 Discharge
• Flows to 30,000 GPM
• Heads to 550 Feet
• Temperatures to 300F
• Heavy Section Casing
• Case Wear Rings
• Extra Deep Stuffing Boxes
• Integral Stuffing Box Flush
• Standard Packed Stuffing Boxes (Optional
  Mechanical Seals)

• Purge Grease, Cartridge Type Bearings
• Bronze Shaft Sleeves Standard
• 420 Stainless Steel Shaft
• Optional Impeller Wear Rings
• Easy Replacement Of Bearings w/o Removing Entire
  Shaft Assembly

• Thru-Bore Line Bore

45
AMP 101 INTRO

• 340 Series Double Suction (HD)

46
AMP 101 INTRO

• Product Features Benefits
• 340 Series Double Suction Split Case - XHD
• 29 Models
• 8 to 48 Discharge
• Flows to 85,000 GPM
• Heads to 400 Feet
• Temperatures to 300F
• Heavy Section Casing
• Case Wear Rings
• Extra Deep Stuffing Boxes
• Standard Packed Stuffing Boxes (Optional
  Mechanical Seals)

• Purge Grease, Cartridge Type Bearings
• Ease Of Service Or Inspection
• Bronze Shaft Sleeves Standard
• 420 Stainless Steel Shaft
• Optional Impeller Wear Rings
• Easy Replacement Of Bearings w/o Removing Entire
  Shaft Assembly

47
AMP 101 INTRO

• 340 Series Double Suction (XHD)

48
AMP 101 INTRO

• Product Line
• 380 Series Multi-Stage HSC

49
AMP 101 INTRO

• Product Features Benefits
• 380 Series Multi-Stage Split Case (HH, HJ , HK,
  OSMH HT)

• 39 Models
• 1-1/2 to 8 Discharge
• Flows to 4,800 GPM
• Heads to 2,100 Feet
• Temperatures to 500F

50
AMP 101 INTRO

• Product Features Benefits
• 380 Series Multi-Stage Split Case - HH
• 9 Models
• 1-1/2 to 4 Discharge
• Flows to 900 GPM
• Heads to 950 Feet
• Temperatures to 400F
• Heavy Section Casing
• Opposed Impellers
• Extra Deep Packed Stuffing Boxes (Optional
  Mechanical Seal)

• Bronze Shaft Sleeves
• Purge Grease, Cartridge Type Bearings (Optional
  Ring Oiled)

• 420 Stainless Steel Shaft
• Labyrinth Case Wear Rings

51
AMP 101 INTRO

• 380 Series Multi-Stage Split Case (HH)

52
AMP 101 INTRO

• Product Features Benefits
• 380 Series Multi-Stage Split Case - HJ
• 4 Models
• 4 to 8 Discharge
• Flows to 4,800 GPM
• Heads to 1,100 Feet
• Temperatures to 400F
• Heavy Section Casing
• Opposed Impellers
• Extra Deep Packed Stuffing Boxes (Optional
  Mechanical Seal)

• Thru-Bore Line Bore With Removable/Replaceable
  Stuffing Boxes

• Bronze Shaft Sleeves
• Purge Grease, Cartridge Type Bearings (Optional
  Ring Oiled)

• 420 Stainless Steel Shaft
• Case wear rings

53
AMP 101 INTRO

• 380 Series Multi-Stage Split Case (HJ)

54
AMP 101 INTRO

• Product Features Benefits
• 380 Series Multi-Stage Split Case - HK OSMH
• 6 Models
• 1-1/2 to 5 Discharge
• Flows to 1,400 GPM
• Heads to 2,100 Feet
• Temperatures to 500F
• Extra-Heavy Duty Section Casing
• Opposed Impellers
• Extra Deep Packed Stuffing Boxes (Optional
  Mechanical Seal)

• Bronze Shaft Sleeves
• Ring Oiled Bearings
• Stainless Steel Shaft
• Tongue Groove Case Wear Rings
• Impeller Wear Rings
• Water Cooling Jackets Standard On Stuffing Boxes
  Bearing Housings


55
AMP 101 INTRO

• 380 Series Multi-Stage Split Case (HK)

56
AMP 101 INTRO

• 380 Series Multi-Stage Split Case (OSMH)

57
AMP 101 INTRO

• Product Features Benefits
• 380 Series Multi-Stage - HT
• 16 Models
• 6 to 10 Bowl Assemblies
• Flows to 2,500 GPM
• Heads to 2,500 Feet
• Temperatures to 400F
• Heavy Section Casing
• Vitreous Enamel Lining
• Cost Effective
• High Efficiency Enclosed Impellers
• Pump Setting Flexibility
• Alternate Materials Available
• Fabricated Steel Suction Head
• Mechanical Seal Is Under Suction Pressure
• High Pressure Discharge Flange
• Flanged, O-Ringed Bowls Standard

58
AMP 101 INTRO

• 380 Series Multi-Stage (HT)

59
AMP 101 INTRO

• Product Line
• 450 Series Regenerative Turbine

60
AMP 101 INTRO

• Product Features Benefits
• 450 Series Regenerative Turbine (VF)
• 10 Models
• 1 to 2 Discharge
• Flows to 70 GPM
• Heads to 900 Feet
• Temperatures to 300F

61
AMP 101 INTRO

• Product Features Benefits
• 450 Series Regenerative Turbine - VF
• 7 Models
• 1 to 2 Discharge
• Flows to 70 GPM
• Heads to 900 Feet
• Temperatures to 300F
• Low Flow, High Head
• 416 Stainless Steel Shaft
• Constant Flow, Variable Head
• Single Stage Versus Other Two Stage Designs
• Grease Lubricated Bearings
• Can Handle Up To 20 Of Entrained Air
• Floating Impeller Design
• Low NPSHr Impellers
• Replaceable Seal Chamber and Channel Rings

62
AMP 101 INTRO

• 450 Series Regenerative Turbine (VF)

63
AMP 101 INTRO

• Product Line
• 460 Series Process

64
AMP 101 INTRO

• Product Features Benefits
• 460 Series OSD Process - ANSI
• 30 Models (4 Low Flow Models)
• 1 to 8 Discharge
• Flows to 7,400 GPM
• Heads to 985 Feet, suction pressures to 300 PSI
• Temperatures to 500F

65
AMP 101 INTRO

• Product Features Benefits
• 460 Series OSD Process - ANSI
• 30 Models (4 Low Flow Models)
• 1 to 8 Discharge
• Flows to 7,400 GPM
• Heads to 985 Feet, suction pressures to 300 PSI
• Temperatures to 500F
• Heavy Section Casing
• Solid Carbon Steel Shaft (Optional Shaft Sleeve)
• Standard Reverse Vane Impeller (Optional
  Semi-Open Impeller)

• Micro-Millimeter Thrust Bearing Adjustment
• Centerline Discharge With Heavy Wall Casing
• CBL, CBS, FML, FMS FMI Seal Chambers
• Standard Lip Seals With Optional Labyrinth
  Bearing Isolators

• Reduced L/D Ratios To Maximize Seal Life

66
AMP 101 INTRO

• 460 Series Process OSD (ANSI)

67
AMP 101 INTRO

• Product Features Benefits
• 460 Series Process OSO Hot Oil
• 30 Models (4 Low Flow Models)
• 1 to 8 Discharge
• Flows to 7,400 GPM
• Heads to 985 Feet, suction pressures to 300 PSI
• Temperatures to 800F
• Heavy section casing
• Solid carbon steel shaft
• 416 stainless steel shaft sleeve
• Impeller pump out vanes
• Hydraulically balanced impeller
• Double row, deep groove, oil lubricated bearings
• Impeller and case wear rings
• Centerline support for high temperature
  applications

• Optional water cooled bearing pedestal
• Optional water cooled seal chamber box

68
AMP 101 INTRO

• 460 Series Process (OSO)

69
AMP 101 INTRO

• Product Line
• 470 Series Stamped Stainless Steel

70
AMP 101 INTRO

• Product Features Benefits
• 470 Series Stamped Stainless Steel
• 19 Models
• 4, 6, 8, 10 12 Diameter Pumps
• Flows to 1100 GPM
• Heads to 2100 Feet

71
AMP 101 INTRO

• Product Features Benefits
• 470 Series Stamped Stainless Steel
• 9 Models (4 Low Flow Models)
• 4 Diameter Pumps
• Flows to 90 GPM
• Heads to 2000 Feet
• All 300 Stainless Steel Construction
• Internal No-Spin" Replaceable Stainless Steel
  Check Valve

• Stainless Steel Wear Ring Reduces Wear From High
  Thrust

• Fabricated Stainless Steel Impellers Diffusers


• Hexagonal Shaft Constructed Of 410/431 Stainless
  Steel

• Corrosion Resistant Construction "No Lead "

72
AMP 101 INTRO

• 470 Series 4 Stamped Stainless Steel

73
AMP 101 INTRO

• Product Features Benefits
• 470 Series Stamped Stainless Steel
• 10 Models
• 6, 8, 10 12 Diameter Pumps
• Flows to 1100 GPM
• Heads to 2000 Feet
• All 300 Stainless Steel Construction
• Internal No-Spin" Replaceable Stainless Steel
  Check Valve

• Stainless Steel Wear Ring Reduces Wear From High
  Thrust

• Fabricated Stainless Steel Impellers Diffusers


• Hexagonal Shaft Constructed Of 410/431 Stainless
  Steel

• Corrosion Resistant Construction "No Lead "

74
AMP 101 INTRO

• 470 Series 6, 8, 10 12 Stamped Stainless
  Steel


75
AMP 101 INTRO

• Product Line
• 480 Series Vertical Turbine

76
AMP 101 INTRO

• Product Features Benefits
• 480 Series Vertical Turbine
• 7 Models
• 4 to 42 Bowl Assemblies
• Flows to 30,000 GPM
• Heads to 2,310 Feet
• Temperatures to 400F

77
AMP 101 INTRO

• Product Features Benefits
• 480 Series Vertical Turbine
• Short Set, Deep Set, Fabricated Can
• 4 to 42 Bowl Assemblies
• Flows to 30,000 GPM
• Heads to 2,310 Feet
• Temperatures to 400F
• Open Line Shaft Standard
• Enclosed Line Shaft (Optional)
• 304 SS Lineshaft Bearing Sleeves Standard
• Semi-Open Or Enclosed Impellers
• Pump Setting Flexibility
• Alternate Materials Available
• Vortex Suppressors Available
• Thrust Stand Option
• Cast Iron Or Fabricated Discharge Heads

78
AMP 101 INTRO

• Product Features Benefits
• 480 Series Vertical Turbine
• Axial Mixed Flow
• 12 to 36 Bowl Assemblies
• Flows to 50,000 GPM
• Heads to 200 Feet
• Temperatures to 400F
• Open Line Shaft Standard
• Enclosed Line Shaft (Optional)
• 304 SS Lineshaft Bearing Sleeves Standard
• Axial or mixed Impellers
• Pump Setting Flexibility
• Alternate Materials Available
• Vortex Suppressors Available
• Cast Iron Or Fabricated Discharge Heads

79
AMP 101 INTRO

• Product Features Benefits
• 480 Series Vertical Turbine
• Submersible
• 4 to 20 Bowl Assemblies
• Flows to 10,000 GPM
• Heads to 2,310 Feet
• Temperatures to 400F
• Enclosed Impellers
• Pump Setting Flexibility
• Alternate Materials Available

80
AMP 101 INTRO

• Product Line
• 490 Series Self Primer

81
AMP 101 INTRO

• Product Features Benefits
• 490 NOVO Series Self Primer (ST, SP, LS, AD)
• 26 Models
• 1-1/2 to 12 Discharge
• Flows to 6,400 GPM
• Heads to 240 Feet
• Temperatures to 180F

82
AMP 101 INTRO

• Product Features Benefits
• 490 NOVO Series Self Primer - ST
• 5 Models (Solids To 3)
• 3 to 10 Discharge
• Flows to 3,400 GPM
• Heads to 130 Feet
• Temperatures to 180F
• Suction Lift To 24 Feet
• High Resistance To Abrasion
• Oversized Front Inspection Of Impeller
• Coated Front Rear Wear Plate For Long Life
• Large Solids Passing Capability
• Jack Screws On Power Frame
• Impeller Adjustment on Front Cover Plate
• Replacement Of Suction Valve With Out
  Disconnecting Suction Piping

• Oversized Filling Port
• Oil Lubricated, Hard Faced (T/Si-C) Mechanical
  Seal

• Oil Lubricated Bearing Housing

83
AMP 101 INTRO

• 490 NOVO Self Primer (ST)

84
AMP 101 INTRO

• Product Features Benefits
• 490 NOVO Series Self Primer - SP
• 12 Models (Solids To 3)
• 1-1/2 to 12 Discharge
• Flows to 6,400 GPM
• Heads to 150 Feet
• Temperatures to 180F
• Suction Lift To 24 Feet
• High Resistance To Abrasion
• Easy Inspection Of Impeller
• Heavy Duty Wear Plate For Long Life
• Large Solids Passing Capability
• Jack Screws On Power Frame
• Oversized Filling Port
• Externally Lubricated, Hard Faced (T/Si-C)
  Mechanical Seal

• Many Driver Options (Electric, Gasoline
  Diesel)


85
AMP 101 INTRO

• 490 NOVO Self Primer (SP)

86
AMP 101 INTRO

• Product Features Benefits
• 490 NOVO Series Self Primer - LS
• 4 Models (Solids To 1-1/2)
• 1-1/2 to 4 Discharge
• Flows to 500 GPM
• Heads to 70 Feet
• Temperatures to 175F
• Suction Lift To 24 Feet
• High Resistance To Abrasion
• Cost Effective
• Solids Passing Capability
• Externally Lubricated, Hard Faced (T/Si-C)
  Mechanical Seal

• Many Driver Options (Electric, Gasoline
  Diesel)


87
AMP 101 INTRO

• 490 NOVO Series Self Primer (LS)

88
AMP 101 INTRO

• Product Features Benefits
• NOVO AD Series Diaphragm
• 5 Models (Solids To 3)
• 3 to 4 Discharge
• Flows to 240 GPM
• Heads to 50 Feet
• Temperatures to 175F
• Suction Lift To 24 Feet
• Can Run Dry Indefinitely
• Anything That Can Pass Through The Inlet Will
  Pass Through The Pump

• Can Be Base Mounted Or Trailer Mounted
• Cleanout On The Discharge Standard
• Many Driver Options (Electric, Gasoline
  Diesel)

• Simplex Duplex

89
AMP 101 INTRO

• NOVO AD Series Diaphragm (Pump)

90
AMP 101 INTRO

• Product Line
• 900 Series Electric Motors

91
AMP 101 INTRO

• Product Features Benefits
• 900 Series Electric Motors
• 53 Models
• Horizontal, Vertical Submersible
• Sizes to 125 HP
• Voltages from 230, 380 460 Volt

92
AMP 101 INTRO

• Product Features Benefits
• 900 Series Submersible Motors
• 9 Models
• 4 Diameter Motors
• Sizes to 7-1/2 HP
• Voltages from 230 to 460 Volt
• 3 Conductor Construction
• All 300 Stainless Steel Exterior Construction
• Specifically Designed Thrust Bearing To Withstand
  High Axial Thrust Loads Stainless Steel

• 3 Bearing Shoes Ensure Greater Protection
• Higher Power Factor And Greater Motor Efficiency


• Larger Shaft Diameter For Better Power
  Transmission

• Mechanical Seal Provides Extra Protection

93
AMP 101 INTRO

• 900 Series 4 Submersible Electric Motors

94
AMP 101 INTRO

• Product Features Benefits
• 900 Series Submersible Motors
• 11 Models
• 6 8 Diameter Motors
• Sizes to 125 HP
• Voltages from 230 to 460 Volt
• 3/6 Conductor Construction
• Nickel Plated End Bell Exterior Construction
• Optional All 316 Stainless Steel End Bell
  Construction

• Specifically Designed Thrust Bearing To Withstand
  High Axial Thrust Loads Stainless Steel

• 6 Bearing Shoes Ensure Greater Protection
• Higher Power Factor And Greater Motor Efficiency


• Larger Shaft Diameter For Better Power
  Transmission

• Mechanical Seal Provides Extra Protection

95
AMP 101 INTRO

• 900 Series 6 8 Submersible Electric Motors

96
AMP 101 INTRO

• Product Features Benefits
• 900 Series Horizontal Vertical Motors
• 28 Models
• TEFC Enclosures
• Sizes to 125 HP
• Voltages from 230 to 460 Volt
• Heavy Duty Cast Iron Housings
• T-Frame or C-Face Constructions
• Higher Power Factor And Greater Motor Efficiency


• Larger Shaft Diameter For Better Power
  Transmission

97
AMP 101 INTRO

• 900 Series Horizontal Vertical Electric
  Motors


98
AMP 101 INTRO

• Sales Marketing Programs
• New Regional Managers
• Distributor/Representative Network
• Distribution/Service Centers
• Tradeshows

99
AMP 101 INTRO

• Current Projects Installations
• Metro Water District
• Eastern Municipal Water District
• Chino Valley
• Los Angeles Department of Water Power
• Mohave County, Arizona

100
AMP 101 INTRO

• Website Information

101
AMP 101 INTRO

• Water-Works Demonstration
• Software Selection

End Suction Example 3000 GPM_at_ 100 Feet - 1800 RP
M 8x10-13 RE System Head Curve 3000 GPM _at_ 100 F
eet Split Case Example 3000 GPM_at_ 100 Feet - 1
800 RPM 10x10-12 HD System Head Curve 3000 GPM
_at_ 100 Feet Vertical Turbine Example 3000 GPM_at_
100 Feet - 1800 RPM 14W 2-stage System Head Cur
ve 3000 GPM _at_ 100 Feet
102
AMP 101 INTRO

• Comments, Questions Answers
