PAC Server

1
PAC Server Suite
MedPac Systems www.medpacsystems.com sastradhar_at_me
dpacsystems.com Ph 919902261450
2
Deployment Scenario
Satellite Diagnostic Center
Radiology Center
Work Station
Modlity1
Dicom Pac Server
DICOM gateway
Http Client
Modlity2
Internet
Dicom Printer
Modlity3
Report Viewer Station
Modality
3
What Medpac Systems Offers

• Dicom gateway and Dicom Pac server
• Medpac Systems offers a solution, not just
  hardware or software
• Work flow customization as per deployment
  scenario
• Complete web based system
• Web based technical support for zero down time
• Linux Platforms, so high scalable performance and
  reliability

4
Dicom Gateway

• Dicom 3.0 support
• 500GB Disk Space
• Compress Dicom images to be sent to PAC server
• Multiple network interface for Load sharing and
  Redundancy
• Report viewing and printing
• VPN support
• Work list and HL7 support

5
Dicom Pac Server

• Dicom 3.0 compliant
• 2 6TB with Raid 5 support (No loss of data when
  a disk dies)
• Supports upto 50lakh Dicom images
• Support for web based Clients
• Support of Dicom Work stations
• Customizable work flow
• Based on Linux High performance, free from
  viruses
• Web based support

6
Flow Control in Pac Server
Image Study in Pac
Controller
Radiologist
Report Generator
Referring Doctor
