Unit 6, Part 2 Notes

1
Unit 6, Part 2 Notes

• Photosynthesis and Respiration

2
Energy

• E Energy
• Energy is the ability to do work
• Chemical Energy is stored in bonds
• Solar Energy is from the sun, radiant energy
• Light and Heat
• Heat Energy is also thermal energy this is how
  we lose most of our energy
• Mechanical Energy energy of movement

3
Metabolism

• Metabolism is the total of all chemical reactions
  in the body
• Exothermic Reaction releases heat during the
  reaction
• Endothermic Reaction uses/absorbs heat during
  the reaction
• Both types are going on at the same time in our
  bodies.

4
Energy Transformation

• ATP adenosine triphosphate
• Store Energy in CELLS
• ADENOSINE adenine ribose
• TRIPHOSPHATE 3 phosphate groups
• Energy is stored in the phosphate bonds

5
Energy Transformation

• ATP is called the "currency" of the cell
• ATP is a small packet of Energy that can be used
  a little at a time, like coins
• ATP is constantly reused and recycled
• You cant buy things without , cells cant
  work/move without Energy from ATP

6
Energy Transformation

• ATP is hydrated to form ADP (adenosine
  diphosphate)
• reaction is hydrolysis, H2O is added and
  phosphate is released
• when the phosphate bond breaks, the Energy stored
  there is released

7
Energy Transformation

• The removed phosphate is recycled to another ADP
  molecule to make ATP
• reaction is dehydration synthesis
• Energy is stored in the new phosphate bonds

8
Photosynthesis

• How do organisms make ATP to be able to use it?
• From the energy stored in GLUCOSE
• Photosynthesis turns solar Energy into chemical
  Energy

9
Photosynthesis

• Chlorophyll pigments in chloroplasts use solar E
  to convert CO2 and H2O into O2 and E storing
  carbohydrates (glucose)
• Done by green plants, protists like algae, and
  some bacteria
• CO2 H2O ? C6H12O6 O2
• (opposite of cellular respiration)

10
Photosynthesis

• Two Reactions during Photosynthesis
• Light reaction needs light H2O and makes ATP
  and oxygen
• These go to the Calvin Cycle
• Coverts Sunlight into Chemical Energy
• Dark reaction (Calvin Cycle) needs ATP, CO2 and
  H2O produces C6H12O6 and ADP
• Uses the products of the Light Reaction to
  produce sugars (stored chemical energy)

11
Photosynthesis

• Chloroplasts
• Grana - stacks of folded thylakoid membrane
• Light Reaction
• Stroma - gel-like fluid
• Dark Reaction

12
(No Transcript)
13
Cellular Respiration

• Turns chemical Energy (glucose) into usable
  Energy (ATP)
• Cells get Energy from breaking the bonds of
  glucose molecules
• Occurs in the mitochondria of ALL organisms
  (except Monera)

14
Cellular Respiration

• Animals get glucose molecules from eating
• Plants and some protists and bacteria get glucose
  from photosynthesis
• Cellular Respiration
• C6H12O6 O2 ? CO2 H2O ATP
• (opposite of photosynthesis)

15
A Road Map for Cellular Respiration
Cytosol
Mitochondrion
High-energy electrons carried mainly by NADH
High-energy electrons carried by NADH
Glycolysis
Krebs Cycle
2 Pyruvic acid
Electron Transport
Glucose
16
Cellular Respiration

• Cellular Respiration has 2 PARTS that NET 38 ATP
• 1. Glycolysis - glucose splitting
• makes 4 ATP total, but only NETS 2 ATP
• THIS IS ALWAYS THE FIRST STEP
• 2. Aerobic/Oxidative Respiration
• OR
• 2. Anaerobic Respiration/Fermentation

17
Cellular Respiration

• Glycolysis
• 1. occurs in the cytoplasm
• 2. no O2 is needed for this part
• 3. E in the form of 2 ATP are used to break 1
  glucose
• 4. releases 4 ATP and 2 pyruvic acid or pyruvate
  molecules are formed
• 5. 1 glucose yields 4 ATP, but 2 are needed to
  start the process (therefore, there is a net gain
  of 2 ATP)

18
Cellular Respiration

• Aerobic/Oxidative Respiration
• 1. occurs with O2 in the mitochondria
• 2. aerobic respiration makes a total of 36 ATP
• 3. it occurs in 2 steps

19
Cellular Respiration

• Aerobic/Oxidative Respiration
• 1st Step Krebs Cycle or citric acid cycle
  (series of reactions) (MAKES 2 ATP)
• 1. 1 pyruvate from glycolysis goes from
  cytoplasm to mitochondria
• 2. 2 carbons leave in the form of 2 CO2
  molecules
• 3. 3 molecules of NAD are converted to NADH
  (NADH nicotinamide adenine dinucleotide)
• 4. 1 molecule of FAD is converted to FADH2
• (FADH2 flavin adenine dinucleotide)
• 5. 1 molecule of GDP or GFP converted to GTP to
  make ATP
• 6. for each glucose there are 2 turns through
  the Krebs Cycle

20
Cellular Respiration

• Aerobic/Oxidative Respiration
• 2nd Step - Electron transport chain (MAKES up to
  34 ATP)
• 1. high E e- from NADH and FADH2 are passed to
  series of enzymes in the mitochondrial membrane
• 2. _at_ the end of the chain, an enzyme combines
  electrons from the chain
• 3. with H ions from the cells fluid and O2 to
  form H2O.
• 4. O2 is the final electron acceptor, therefore
  O2 is necessary for obtaining E from NADH and
  FADH2

21
Adding up the ATP from Cellular Respiration
Cytosol
Mitochondrion
Glycolysis
2 Acetyl- CoA
Krebs Cycle
2 Pyruvic acid
Electron Transport
Glucose
Maximum per glucose
by ATP synthase
by direct synthesis
by direct synthesis
22
Cellular Respiration

• Anaerobic Respiration/Fermentation
• occurs right after glycolysis only if there is NO
  OXYGEN available
• alcoholic fermentation - used to make wine, beer,
  breads
• lactic acid fermentation - occurs in muscles when
  lactic acid builds up muscles don't work well
  cramps last even after exercise stops because
  its made faster than its broken down

23
Sunlight energy
Ecosystem
Photosynthesis (in chloroplasts)
Carbon dioxide
Glucose
Oxygen
Water
Cellular respiration (in mitochondria)
for cellular work
Heat energy
24
(No Transcript)
25
ATP Summary
26
ATP Summary
27
ATP Summary
28
ATP Summary
29
ATP Summary
30
ATP Summary
31
ATP Summary
32
ATP Summary
33
ATP Summary
34
ATP Summary
35
ATP Summary
36
(No Transcript)
37
Unit 6, Part 2 Notes

• Photosynthesis and Respiration
