Lake City Community College Earth Science, 11e

1
Lake City Community CollegeEarth Science, 11e

• Edward J. Tarbuck Frederick K. Lutgens

2
Plate TectonicsChapter 8

• Earth Science, 11e
• Stan Hatfield and Ken Pinzke
• Modified by Dr. Kane

3
Continental drift It started it all

• Alfred Wegener
• First proposed hypothesis, 1915
• Published The Origin of Continents and Oceans
• Continental drift hypothesis
• Supercontinent called Pangaea began breaking
  apart about 200 million years ago
• Continents "drifted" to present positions
• Continents "broke" through the ocean crust

4
Did you know?

• The Appalachian Mountain formed 300 million years
  ago during the formation of Pangaea

5
Pangaea approximately 200 million years ago
6
Continental drift an idea before its time

• Wegener's continental drift hypothesis
• Evidence used by Wegener
• Fit of South America and Africa
• Fossils match across the seas
• Rock types and structures match
• Ancient climates

7
Wegeners matching of mountain ranges on
different continents
8
Paleoclimatic evidence for Continental Drift
9
Was Wegener a visionary or a dreamer?

• Would you object or agree with Wegeners idea?
• If you had a chance what question would you ask
  Wegener?

10
What was missing?

• Main objection to Wegener's proposal was its
  inability to provide a mechanism

11
Then came Harry Hess

• Used fathometer to explore the ocean floor
• Discovered the ocean crust is made of basalt not
  granite
• Discovered the mid-ocean ridge
• Found that the seafloor grows from the mid ocean
  ridge (seafloor spreading)
• Found that the continental plates drift from the
  mid-ocean ridge over the mantle

12
Did Hess explain it all?

• Did Hess provide the mechanism to support
  Wegeners idea of Continental Drift?
• How?

13
Then came Vine and Matthews

• Used Paleomagnetic reversals to confirm seafloor
  spreading
• Used age of seafloor rocks to confirm seafloor
  spreading (seafloor rocks get older as you move
  away from the mid-ocean ridge)
• Discovered Polar Wandering

14
Paleomagnetic reversals recorded by basalt flows
at mid-ocean ridges
15
Apparent polar-wandering paths for Eurasia and
North America
16
The Unified Theory

• Unifying Continental Drift and Seafloor Spreading
  into on theory The Plate Tectonics Theory. It
  says
• The lithosphere is broken into plates that move
  over the Asthenosphere
• Whats the lithosphere?

17
Plate tectonics the new paradigm

• The lithosphere consists of several plates
• Plates are moving slowly over the mantle
• Largest plate is the Pacific plate
• Many plates are beneath the ocean
• Earthquakes, volcanoes, mountains are the results
  of plate motion

18
Directions and rates of plate motions
19
Plate Boundaries

• Plate boundaries
• All major interactions among plates occur along
  the 3 major plate boundaries
• - Convergent (destructive margin)
• - Divergent (constructive margin)
• - Transform Fault

20
A - Divergent plate boundaries

• Divergent plate boundaries (constructive margins)

• Continental rifts within a continent, i.e. East
  African rift
• Mid-Ocean ridges in the middle of ocean floor

21
Divergent Plate Boundary

• Divergent plate boundaries (continued)
• Two plates move apart
• Mantle material upwells to create new seafloor
• Ocean ridges and seafloor spreading
• Oceanic ridges develop along well-developed
  boundaries
• Along ridges, seafloor spreading creates new
  seafloor

22
Divergent boundaries are located mainly along
oceanic ridges
23
The East African rift a divergent boundary on
land
24
Types of Plate Boundaries

• Convergent plate boundaries (destructive margins)
• Plates collide, an ocean trench forms and
  lithosphere is subducted into the mantle, it
  melts and produces volcanic arcs

25
B - Convergent Plate Boundary

• Convergent plate boundaries (destructive margins)
• Three types of Convergent Plate Boundary
• Oceanic-continental convergence
• Denser oceanic slab sinks into the asthenosphere
• Pockets of magma develop and rise
• Continental volcanic arcs form
• Examples include the Andes mountains in South
  America,

26
An oceanic-continental convergent plate boundary
27
Plate Boundaries

• Convergent plate boundaries (destructive margins)
• Oceanic-oceanic convergence
• Two oceanic slabs converge and one descends
  beneath the other
• Often forms volcanoes on the ocean floor
• Volcanic island arcs forms as volcanoes emerge
  from the sea
• Examples include the Aleutian Islands in Alaska,

28
An oceanic-oceanic convergent plate boundary
29
Plate Boundaries

• Convergent plate boundaries (destructive margins)
• Continental-continental convergence
• When subducting plates contain continental
  material, two continents collide
• Can produce new mountain ranges such as the
  Himalayas

30
A continental-continental convergent plate
boundary
31
The collision of India and Asia produced the
Himalayas (before)
32
The collision of India and Asia produced the
Himalayas (after)
33
C - Transform Fault

• Transform Fault
• Plates slide past one another
• No new crust is created
• No crust is destroyed
• i.e. San Andreas Fault, California

34
Evidence for the plate tectonics model

• Paleomagnetism (ancient magnetism)
• Probably the most persuasive evidence
• Paleomagnetic records show
• Polar wandering (evidence that continents moved)
• Earth's magnetic field reversals
• Recorded in rocks as they form at oceanic ridges


35
Evidence for the plate tectonics model

• Earthquake patterns
• Associated with plate boundaries
• Deep-focus earthquakes along trenches provide a
  method for tracking the plate's descent
• Ocean drilling
• Deep Sea Drilling Project (ship Glomar
  Challenger)

36
Distribution of earthquake foci at plate
boundaries
37
Earthquake foci in the vicinity of the Japan
trench
38
Evidence for the plate tectonics model

• Ocean drilling (continued)
• Age of seafloor rocks
• Youngest are near the ridges
• Older are at a distance from the ridge
• Oldest Ocean floor rocks are 200 million years,
  much younger than the continent rocks

39
Evidence for the plate tectonics model

• Hot spots
• Rising plumes of mantle material
• Volcanoes can form over them
• e.g., Hawaiian Island chain
• Chains of volcanoes mark plate movement over a
  stationary hot spot

40
The Hawaiian Islands have formed over a
stationary hot spot
41
Evidence of Plate Tectonics Model

• Measuring plate motion
• By using hot spot tracks like those of the
  Hawaiian Island - Emperor Seamount chain
• Using space-age technology to directly measure
  the relative motion of plates
• Very Long Baseline Interferometry (VLBI)
• Global Positioning System (GPS)

42
Driving mechanism of plate tectonics

• No one model explains all facets of plate
  tectonics
• Earth's heat is the driving force
• Several models have been proposed
• Slab-pull and slab-push model
• Descending oceanic crust pulls the plate
• Elevated ridge system pushes the plate

43
Plate tectonics the new paradigm

• Driving mechanism of plate tectonics
• Several models have been proposed
• Plate-mantle convection
• Mantle plumes extend from mantle-core boundary
  and cause convection within the mantle
• Models
• Layering at 660 kilometers
• Whole-mantle convection
• Deep-layer model

44
Layering at 660 kilometers
45
Whole-mantle convection
46
Deep-layer model
47
End of Chapter 8
48
1 - What was the name of the Supercontinent?

• Gondwanaland
• Kalahari
• Pangaea
• Eurasia

49
2 - Whose idea was the Continental Drift?

• A. Einstein
• A. Wegener
• H. Hess
• Vine and Matthews

50
3 - Which one of these is not Wegeners Evidence
of Continental Drift?

• Fit of South America and Africa
• Fossils match across the seas
• Matching human remains in Europe and America
• Matching rock types and structures
• Ancient climates

51
4 - What example of plate boundary is the East
African Rift Valley?

• Continental-continental convergent
• Divergent
• Oceanic-continental convergent
• Oceanic-oceanic convergent

52
5 Ocean floor rocks get older as you move
____the ridge

• Towards
• Away from
• Parallel
• None of these
• No relation whatsoever

53
6 - This is an example of a. Oceanic-oceanicb.
Ocean-continent convergence
54
7 - Polar Wandering is

• Migration of Polar bears
• Another evidence of Global Warming
• Migration of the North Pole
• None of the above

55
9 Plate Tectonics Theory states

• Earth crust is broken into plates
• Earth lithosphere is broken into plates
• Earth mantle is broken into plates

56
10 What two continents match?

• Africa and America
• America and Europe
• Africa and South America
• India and Asia

57
11 When did the Supercontinent break?

• 300 million years ago
• 200 million years ago
• 150 million years ago
• 4.6 billion years ago

58
12 Age of the oldest seafloor rocks

• 4.5 billion years ago
• 200 million years ago
• 300 million years ago
• None of these

59
13 The San Andreas Fault is an example of

• Convergent margin
• Divergent margin
• Mid-Ocean ridge
• Continental Island Arc
• None of the above

60
14 - The Andes Mountains are an example of

• Volcanic Island arc
• Continental Volcanic arc
• Convergent margin
• None of the above
• b and c

61
15 - The African Rift Valley is an Example of

• Continental volcanic arc
• Convergent margin
• Divergent margin
• None of these
