From Facial Features to Facial Expressions

1
From Facial Featuresto Facial Expressions

• A.Raouzaiou, K.Karpouzis and S.Kollias

Image, Video and Multimedia Systems
LaboratoryNational Technical University of Athens
2
Outline

• The concept of archetypal expressions
• FAPs-based description and estimation of FAPs
• Expression synthesis using profiles
• Synthesis of intermediate emotions

3
Archetypal Expressions
Also termed universal because they are recognized
across cultures
Source F. Parke and K. Waters, Computer Facial
Animation, A K Peters
4
Archetypal Expressions (cont.)
Description of the archetypal expressions through
muscle actions
Action Units (AUs) - FACS
Translation of facial muscle movements into FAPs
e.g. sadness close_t_l_eyelid, close_t_r_eyelid,
close_b_l_eyelid, close_b_r_eyelid,
raise_l_i_eyebrow, raise_r_i_eyebrow,
raise_l_m_eyebrow, raise_r_m_eyebrow,
raise_l_o_eyebrow, raise_r_o_eyebrow
Creation of FAPs vocabulary for every archetypal
expression
5
FAPs-based description

• Discrete features offer a neat, symbolic
  representation of expressions
• Not constrained to a specific face model
• Suitable for face cloning applications
• MPEG-4 compatible
• Based on feature points, not complete features

6
FAPs-based description (cont.)
Two issues should be addressed

• choice of FAPs involved in profiles formation
• definition of FAP intensities

7
Expression synthesis

• Choice of FAPs is based on psychological data
• Intensities are derived from expression database
  images

8
Estimation of FAPs

• Absence of clear quantitative definition of FAPs

• It is possible to model FAPs through FDP feature
  points movement using distances s(x,y)

e.g. close_t_r_eyelid (F20) - close_b_r_eyelid
(F22) ? D13s (3.2,3.4) ? f13 D13 - D13-NEUTRAL
9
Sample FAP vocabulary
Sadness close_t_l_eyelid(F19),
close_t_r_eyelid(F20 ), close_b_l_eyelid (F21),
close_b_r_eyelid(F22), raise_l_i_eyebrow(F31),
raise_r_i_eyebrow(F32 ), raise_l_m_eyebrow(F33),
raise_r_m_eyebrow(F34), raise_l_o_eyebrow(F35),
raise_r_o_eyebrow(F36)
10
Archetypal Expression Profiles
Profile set of FAPs accompanied by the
corresponding range of variation
11
Sample Profiles of Anger
A1 F422, 124, F31-131, -25, F32-136,-34,
F33-189,-109, F34-183,-105, F35-101,-31,
F36-108,-32, F3729,85, F3827,89 A2
F19-330,-200, F20-335,-205, F21200,330,
F22205,335, F31-200,-80, F32-194,-74,
F33-190,-70, F34-190,-70 A3 F19
-330,-200, F20-335,-205, F21200,330,
F22205,335, F31-200,-80, F32-194,-74,
F3370,190, F3470,190
12
Emotion representation
Emotions can be approached as points on a plane
defined by activation and evaluation
13
Intermediate Expression Profiles

• Same universal emotion category
• Animation of the same FAPs using different
  intensities
• Absence of expert knowledge for the (, )
  quadrant

worry lt fear lt terror
14
Intermediate Expression Profiles

• Different universal emotion categories
• In the same evaluation half-plane
• Averaging of FAPs used in universal emotions

15
Intermediate Expression Profiles

• Different universal emotion categories

afraid sad depressed
16
Conclusions

• FAPs provide a compact and established means of
  emotion representation
• Necessary input from psychological and
  physiological studies
• Universal emotions can be used to synthesize
  intermediate ones
• Useful for low-bitrate MPEG-4 applications

17
Extensions

• Verification Evaluation
• Initial results
• Acceptable performance for expression grading
• Intermediate expressions better results for the
  negative evaluation half plane
• Lack of linguistic rules for the (, -) quadrant

18
Extensions

• Personalized ECAs
• Detected facial feature points can be used to
  adapt a generic ECA head (FDP FPs)
• Intermediate emotions based on processing real
  data (FAP extraction)
• Processing real data ? temporal aspect of FAPs
