CRM and Information Visualization

1
CRM and Information Visualization

• Gürdal Ertek, Ph.D.
• Tugçe Gizem Martagan

2
Customer Relationship Management (CRM)
3
What is CRM?

• The approach of identifying, establishing,
  maintaining, and enhancing lasting relationships
  with customers.
• The formation of bonds between a company and its
  customers.

4
Strategies in CRM for Mass Customization

• Prospecting (of first-time consumers)
• Loyalty
• Cross-selling / Up-selling
• Win back or Save

5
(No Transcript)
6
(No Transcript)
7
The Marketing PerspectiveCAMPAIGN
MANAGEMENTRECENCY FREQUENCY MONETARY VALUE
METHODCUSTOMER VALUE METRICS
8
Campaign Management The Marketing Perspective

• Developing effective campaigns
• Effectively predicting the future
• Retaining existing customers
• Acquiring new customers

9
Campaign Management The Cap Gemini Model
KNOW Understand market and consumers needs and
preferences Exploit customer intelligence, Perfo
rm segmentation
TARGET ( Offer is developed ) Define market
strategies Use channel integration
SERVICE Retain customers by Loyalty
programs Communication Service forces
SELL Acquire customers Use sales force
effectively Develop marketing programs
10
Campaign Management The Marketing Perspective

• The marketing manager...
• Defines objectives
• Identifies customers
• Defines communication strategies
• Designs/improves products/offers/services/promotio
  ns
• Tests the impacts of her decisions
• Revises her decisions for maximum effectiveness

11
Campaign ManagementStep 1 Define Objectives
Targeting Existing Customers Retention Strategy
Creating Loyalty?
Increasing the satisfaction level?
Cross-selling or Up-selling?
Targeting New Customers Acquisition Strategy
Target customers that show characterstics
similar to existing groups of customers
12
Campaign ManagementStep 2 Identify Customers

• Perform SEGMENTATION
• Define the right customers
• Use information of past transactions as key for
  making predicting future ones
• Define the segments and their characteristics
• Develop customized marketing strategies for the
  different segments

13
Campaign ManagementStep 3 Communication
Strategies

• Which message should be transmitted?
• Which channel should be used?

14
Campaign ManagementStep 4 Design the Products,
Offers, Services and Promotions

• Analyze the price, time period, risks, marketing
  costs
• Define the product / offer / service / promotion
  and its general structure
• Identify effective use of sales and communication
  channels

15
Campaign ManagementStep 5 Test the Impacts

• Impacts of the decisions have to be tested and
  and assessed on a sample

16
Campaign ManagementStep 6 Revise the Decisions

• Make revisions to the targeted offer / service /
  promotions
• Finally apply the decisions to the whole segment
  or population

17
(No Transcript)
18
(No Transcript)
19
RFM Method(Recency, Frequency, Monetary Value )

• Recency
• When was the last customer interaction?
• Frequency
• How frequent was the customer in its interactions
  with the business?
• Monetary value of the interactions

20
RFM Method(Recency, Frequency, Monetary Value )

• Marketing Problem
• A firm has sent e-mail to 30,000 of its existing
  customers, announcing a promotion of 100. 458 of
  them responded (1.52 of the customers)
• Is there any relation between the responding
  customers and their historical purchasing
  behaviours?

21
RFM MethodRecency Coding

• 30,000 customers are sorted in descending order
  with respect to their most recent purchases
• Sorted data is divided into 5 equal groups, each
  of them containing 6,000 people
• Recency codes are assigned Top group has code 5,
  bottom group has code 1

22
RFM MethodRecency Coding

• Recency Results
• According to analysis based on customer recency,
  the group having the highest recency group has
  also the highest response rate
• Remark
• (3.10 2.00 1.50 0.62 0.38) / 5
  1,52 which is the response rate
• Strict Rule Ones who have purchased recently are
  much more willing to buy new products than others
  purchasing in the past

23
RFM MethodFrequency Coding

• Sort the 30,000 customers with respect to
  frequency metrics.
• Frequency metrics Average number of purchases
  made by customer in a time period t
• Sort customers in descending order with respect
  to their purchase frequency.
• Assign them to 5 groups, top 20 in the first
  frequency group.
• Assign frequency codes such that the top group
  has code 5 and the bottom group has code 1.

24
RFM MethodFrequency Coding

• Frequency Results
• It is observed that highest response rate is from
  the customers having highest frequency
• Frequent people respond better than less frequent
  ones but differences between groups are less than
  the ones in the recency
• The lowest frequency group always contains new
  customers
• That is why it is named RFM

25
RFM MethodMonetary Value Coding

• The same process as recency and frequency coding
• Sorting is done with respect to monetary value
  metric
• Monetary value metric is the average amount
  purchased in a time period t
• At the end of the monetary value coding, assign
  monetary value codes M 1,...,5 to groups
  according to their groups.

26
RFM MethodMonetary Value Coding

• Frequency Results
• It is observed that highest response rate is from
  the customers having highest monetary value
• Unlike the recency case,
• there are not big differences between groups

27
RFM Method Putting the Codes Together

• At the end of the monetary coding firm obtain R F
  M metrics for customers. Each customer belongs to
  one of 125 possible combinations of the RFM
  values

Database
R
1
2
3
4
5
F
21
22
23
24
25
M
231
232
233
234
235
28
RFM MethodSTEPS

• Create 3 digits RFM codes cells
• All cells having the same number of customers in
  them
• RFM values are used to define group of customers
  that marketing campaign should target or should
  avoid
• Used for identifying customers having high
  probability to respond to campaigns
• 555s response rate gt 552s gt 543s gt541....
• Increase the response rate
• Increase profitability

29
Customer Value Metrics

• Critical measures used to define customer worth
  in knowledge-driven and customer-focused
  marketing

30
Customer Value MetricsSize of Wallet

• Size of wallet
• Assumption Firms prefer customers with large
  size of wallet in order to retain large revenues
  and profits

Sales to focal customer by firm j
31
Customer Value MetricsIndividual Share of
Wallet (SW)

• A proportion expressed in terms of percentage,
  calculated among buyers
• Measured at individual level
• A measure of loyalty
• Can be used in future predictions
• Different from the market share, which also
  considers customers with no purchase
• Individual share of wallet

Sales to focal customer by firm j
32
Customer Value Metrics

• Share of wallet and size of wallet should be
  analyzed together because...

33
Customer Value MetricsTransition Matrix

• Shows expected share of wallet from multiple
  brands
• Depicts consumers willingness to buy over time
• Transition probability from B to A, than from A
  to C 1020 2

34
The Engineering PerspectiveDATA MINING
35
Data Mining

• Collection, storage, and analysis of typically
  huge amounts of- data
• Data readily resides in the companys data
  warehouse
• Data cleaning is almost inevitable

36
Data Mining

• Goals of Data Mining
• Developing deeper understanding of the data
• Discovering hidden patterns
• Coming up with actionable insights
• Identifying relations between variables, inputs
  and outputs
• Predicting future patterns

37
Data Mining Steps

• Data selection
• Data cleaning
• Sampling
• Dimensionality reduction
• Data mining methods

38
Data MiningMethods

• Exploratory Data Analysis
• Segmentation
• Cluster Analysis
• Decision Trees
• Market Basket Analysis
• Association rules
• Information Visualization
• Prediction
• Regression
• Neural Network
• Time Series Analysis

39
Information Visualization

• Data mining algorithms...
• Can only detect certain types of patterns and
  insights
• Are too complex for end users to understand

40
Information Visualization

• A field of Computer Science which has evolved
  since the 1990s.
• Before 1990s Graphical methods for data analysis
  to pave the way for statistical methods
• After 1990s
• Computer hardware has advanced with respect to
  memory, computational power, graphics
  calculations
• Software has advanced with respect to user
  interfaces
• Data collection systems have advanced (barcodes,
  RFID, ERP)

41
Information Visualization

• The analyst does not have to understand complex
  algorithms.
• Almost no training required.
• There are no limits to the types of insights that
  can be discovered.

42
Case StudiesAnalysis of Supermarket Sales Data
43
The Data
44
Frequent Itemsets
45
Frequent Itemsets
46
Association Rules
47
Case StudiesAnalysis of Spare Parts Sales Data
48
The Data
Assumption Each customer gives at most one order
each day.
49
Determining Top ProductsPivot Table for
Determining REVENUE_SUM
50
Determining Top ProductsPivot Table for
Determining COUNT (Frequency)
51
Determining Top ProductsScatter Plot
52
Seasonality of Top Products
. . .
53
Seasonality of Top CustomersPivot Table
54
Determining Top CustomersPareto Curve (ABC
Analysis)
Revenue
55
Seasonality of Top CustomersStarfield
Visualization
56
Case StudiesAnalysis of ÖSS 2004 Data
57
The Data
58
Pareto Squares
L
Y(L)
s
H
T
Y5(H)
59
Pareto SquaresModel Definitions
60
Pareto SquaresOptimization Model
61
General Insights
62
Benchmarking Highschools
63
Benchmarking Departments
64
Relationship Management
65
References

• Berry, M. J. A., Linoff, G. S. (2004) Data Mining
  Techniques. Wiley Publishing.
• Ertek, G. Visual Data Mining with Pareto Squares
  for Customer Relationship Management (CRM)
  (working paper, Sabanci University, Istanbul,
  Turkey)
• Ertek, G., Demiriz, A. A framework for
  visualizing association mining results (accepted
  for LNCS)
• Hughes, A. M. Quick profits with RFM analysis.
  http//www.dbmarketing.com/articles/Art149.htm
• Kumar, V., Reinartz, W. J. (2006) Customer
  Relationship Management, A Databased Approach.
  John Wiley Sons Inc.
• Spence, R. (2001) Information Visualization. ACM
  Press.
