High Altitude Training College of Aviation

1
High Altitude Training College of Aviation

• Glenn Harmon, Aerospace Physiologist,
• Asst Professor of Aeronautical Science

2
High Altitude Training

• Purpose Demonstrate the symptoms and effects of
  hypoxia and recovery using airline-style oxygen
  masks.
• Hypoxia Lack of oxygen in the blood or brain
  caused by low atmospheric pressure or content
  resulting in impairment or unconsciousness.
• Is Hypoxia Awareness/Training Needed?

3
Hypoxia Accidents
4
High Altitude Training

• Military Training
• FAA Oxygen Requirements
• Civilian and Airline Training
• DOT/FAA Study

5
High Altitude TrainingERAUs Vision

• Hypobaric Chamber.
• ROBD
• Normobaric Enclosure

6
ERAUs Lab Design
COA 132B
7
ERAU Suppliers
8
High Altitude TrainingNormobaric Lab
9
Typical Profile40-50 Minutes

• Lab start-up and ascent to altitude e.g. 25,000
  ft.
• Students briefed on Objectives, Ops, mask usage
• Enter - Don O2 masks, Comm, pulse oximeters
• Review symptoms/discussion/accident recap
• Select studs to remove mask, begin tasks
• Studs identify 2-3 symptoms - 8-12 min recover
  on O2
• Student feedback
• Subjective objective symptoms
• Exit lab debrief

10
Instructor Training
11
Symptoms of Hypoxic Hypoxia

• Tunnel vision, visual acuity, focus SUBJECTIVE
• Euphoria, dizziness, tingling, headache
• Fatigue, loss of coordination, slurred speech
• Cyanosis, rapid breathing
• Incapacitation
• Death OBJECTIVE

Menu
12
Participation in the High Altitude Lab

• At least 18 years of age.
• Hold at least a 2nd class FAA medical or
  equivalent.
• Medical Screening
• For health and safety reasons, you must notify an
  instructor if you are currently experiencing any
  of the symptoms or conditions below
• _______ Dizziness, fainting spells,
  unconsciousness or seizures
• _______ Eye or vision trouble (except corrective
  lens)
• _______ Heart or vascular trouble, or anemia
• _______ Upper respiratory infection, asthma or
  bronchitis
• _______ Chest pain or shortness of breath
• _______ Diabetes
• _______ Medications not approved for flight
• _______ Recent surgery
• _______ Pregnancy or you have other health
  concerns

13
Normobaric Technology
Shaun Wallace, Altitude Guru
14
Colorado Altitude Training

• Normobaric Hypoxic Systems for Aviators

Shaun Wallace
15
Simulating Altitude
Humans respond to Partial Pressure of
Oxygen Atmospheric X O2 content ()
PPO2 Pressure
x
Hypobaric Hypoxia
x
Normobaric
Hypoxia
16
Air Separation Technology
No need for cylinders of nitrogen or other gasses
Self re-generating expected life gt20,000 hours
use
Minimal maintenance or running costs
17
Creating Hypoxic Environments
Dilution with hypoxic air
18
Creating Hypoxic Environments
Oxygen extraction method
19
Technology The CAT Controller
Single point of control for altitude system

• Input
• On/Off
• Desired Altitude
• Feet/Meters

• Measures
• Barometric Pressure
• Oxygen Content
• CO2 level

• Activates
• Air Units
• Intake Selector
• Alarms

• Displays
• Desired Altitude
• Current Effective Altitude
• CO2

20
Enclosure Options Tent FAAs portable system
21
Enclosure Options Modular System ERAUs
Modular Enclosure System
22
High Altitude Training
Questions?
Discussion?
